System Boot to UEFI BIOS Firmware Settings in Windows 11


  • Staff

This tutorial will show you how to boot to your motherboard's UEFI/BIOS firmware settings on a Windows 11 PC.

UEFI (Unified Extensible Firmware Interface) is a standard firmware interface for PCs, designed to replace BIOS (basic input/output system). This standard was created by over 140 technology companies as part of the UEFI consortium, including Microsoft. It's designed to improve software interoperability and address limitations of BIOS.

Windows utilizes the UEFI to support the handoff of system control from the SoC firmware boot loader to the OS. The UEFI environment is a minimal boot OS upon which Windows devices are booted and the OS runs.


Contents



EXAMPLE: ASUS UEFI BIOS






Option One

Press a Key on POST screen at Boot to Enter UEFI/BIOS


1 Boot the PC.

2 When you see the POST screen, press the key mentioned to enter UEFI BIOS settings. (see screenshot below)

If you do not see a POST screen, or if the screen goes by too fast to see it, check your manufacturer’s site for specific instructions.

The key you press will vary per manufacturer, so you may need to read your manual or check your manufacturer’s site for specific instructions.

Common keys used for different manufacturers:

ASRock: F2 or DEL
ASUS: F2 for all PCs, F2 or DEL for Motherboards.
Acer: F2 or DEL
Dell: F2 or F12
ECS: DEL
Gigabyte / Aorus: F2 or DEL
HP: Esc, F1, F10
Lenovo (Consumer Laptops): F2 or Fn + F2
Lenovo (Desktops): F1
Lenovo (ThinkPads): Enter then F
MSI: DEL for motherboards and PCs.
Microsoft Surface Tablets: Press and hold volume up button.
Origin PC: F2
Samsung: F2
Toshiba: F2
Zotac: DEL







Option Two

Boot to UEFI/BIOS from Advanced Startup (WinRE)


1 Boot to Advanced Startup (WinRE).

2 Click/tap on Troubleshoot. (see screenshot below)


3 Click/tap on Advanced options. (see screenshot below)


4 Click/tap on UEFI Firmware Settings. (see screenshot below)


5 Click/tap on Restart. (see screenshot below)





Option Three

Boot to UEFI/BIOS using Command


1 Open Windows Terminal (Admin), and select either Windows PowerShell or Command Prompt.

2 Copy and paste the command below you want to use into Windows Terminal (Admin), and press Enter. (see screenshot below)

(with message)
shutdown /r /fw

OR​

(instant without message)
shutdown /r /fw /t 0






Option Four

Boot to UEFI/BIOS on Surface devices








That's it,
Shawn Brink




Attachments

  • UEFI_Firmware_Settings.png
    965 bytes · Views: 139
  • Boot_to_UEFI-BIOS_Advanced_Startup-4.png
    6.4 KB · Views: 147
Last edited:
That's a quite an advanced BIOS menu you have. My Lenovo laptop is not that advanced. In fact, booting into the BIOS with pre-fab PC can often be difficult.


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    Graphics Card(s)
    NVIDA 1650 Ti
    Monitor(s) Displays
    Lenovo C32q-20
Hi @Brink, could you please confirm this question.
I currently have W11 installed on an Nvme with EFI GPT and CSM enabled. I should be able to switch CSM on and off with no issues?
To use Resizable BAR on my video I need to disable CSM but I don't want to reinstall W11 just for that reason.
Thank you for your help and support.

Last edited:

My Computer

System One

  • OS
    Windows 11 23H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    ME Hemi
    CPU
    Intel i7 11700K
    Motherboard
    Asus Prime Z590-A
    Memory
    Crucial 32GB DDR4 3200mhz
    Graphics Card(s)
    EVGA RTX 3070 FTW3 Ultra
    Sound Card
    Realtek S1220A 7.1 DTS:X Ultra
    Monitor(s) Displays
    Dell 32in 4K Asus 27in 1K
    Screen Resolution
    3840x2160 144Hz 1920x1080 60Hz
    Hard Drives
    10TB Nvme's & SSD's
    PSU
    EVGA 220G3750
    Case
    Antec 1200 w/8 fans
    Cooling
    Noctua NH-U12A
    Keyboard
    EVGA Z12
    Mouse
    Razer Deathadder v2
    Internet Speed
    GFiber 2GIG
    Browser
    MS Edge
    Antivirus
    Windows Security
    Other Info
    Linksys WRT1900ACS, SONY WH-XB910N,
    7 Altec Lansing speakers
Hi @Brink, could you please confirm this question.
I currently have W11 installed on an Nvme with EFI GPT and CSM enabled. I should be able to switch CSM on and off with no issues?
To use Resizable BAR on my video I need to disable CSM but I don't want to reinstall W11 just for that reason.
Thank you for your help and support.
Hey Richard, :alien:

I haven't tried it in W11 since UEFI is required. You could test. If the PC doesn't boot afterwards, you could just reboot back into BIOS/UEFI and undo it.
