Solved Cannot update Windows due to TPM being flagged red


Fretman

Member
Local time
5:07 AM
Posts
6
Visit site
OS
Windows 11
Win 11 (21H2) knows I have TPM 2.0 when I check these:
  • Device Manger -> Security Devices shows "Trusted Platform Module 2.0"
  • Windows 11 Health Check app says "TPM 2.0 enabled on this PC. TPM: TPM 2.0"
  • BIOS shows TPM enabled
  • tpm.msc says "The TPM is ready for use."
Yet, when I go to
Computer\HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows NT\CurrentVersion\AppCompatFlags\TargetVersionUpgradeExperienceIndicators\NI22H2
both UpgEx and UpgExU are flagged red. RedReason says Tpm. This tells me Windows thinks I have no TPM, right?

This prevents me from getting updated to 23H2, which I need for some software I have. I did a quick search of these forums and didn't find anything pertinent. How do I get Windows to rescan the TPM chip and update the registry?

Thank you!

Windows Build/Version
Windows 11 (21H2)

My Computer

System One

  • OS
    Windows 11
    Computer type
    PC/Desktop
    Manufacturer/Model
    Home built
    CPU
    Intel Core i9 9th Gen - Core i9-9900K Coffee Lake 8-Cor
    Motherboard
    ASRock Z390 Taichi
    Memory
    G.SKILL TridentZ Series 32GB (2 x 16GB) DDR4 2800 (PC4 22400) Desktop Memory Model F4-2800C14D-32GTZ
    Graphics Card(s)
    Intel UHD Graphics 630
    Sound Card
    RME Fireface UFX external soundcard
    Monitor(s) Displays
    Dell U2412M
    Screen Resolution
    1920x1200
    Hard Drives
    SAMSUNG 970 EVO M.2, SAMSUNG 860 EVO Series 2.5", WD hard drives
    PSU
    Seasonic Flagship PRIME 600 Titanium Fanless SSR-600TL 600W 80+ Titanium Full Modular ATX12V & EPS12V
    Case
    Fractal Design Define R5 Blackout Silent ATX Mid Tower
    Cooling
    Noctua NH-D15, Premium CPU Cooler with 2x NF-A15 PWM 140mm Fans
    Keyboard
    Editor Keys for Studio One
    Mouse
    wired MS mouse
    Internet Speed
    400Mbps
    Browser
    Brave
    Antivirus
    Windows Defender
    Other Info
    Silent PC for music writing/producing/mixing.
Hi, welcome.

Just for fun, run this anyway. See what happens. This should bring your PC to 23H2.




My Computers

System One System Two

  • OS
    Windows Pro 23H2 Build 22631.4249
    Computer type
    PC/Desktop
    Manufacturer/Model
    Sin-built
    CPU
    Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (4th Gen?)
    Motherboard
    ASUS ROG Maximus VI Formula
    Memory
    32.0 GB of I forget and the box is in storage.
    Graphics Card(s)
    Gigabyte nVidia GeForce GTX 1660 Super OC 6GB
    Sound Card
    Onboard
    Monitor(s) Displays
    4 x LG 23MP75 - 2 x 24MK430H-B - 1 x Wacom Pro 22" Tablet
    Screen Resolution
    All over the place
    Hard Drives
    Too many to list.
    OS on Samsung 1TB 870 QVO SATA
    PSU
    Silverstone 1500
    Case
    NZXT Phantom 820 Full-Tower Case
    Cooling
    Noctua NH-D15 Elite Class Dual Tower CPU Cooler / 6 x EziDIY 120mm / 2 x Corsair 140mm somethings / 1 x 140mm Thermaltake something / 2 x 200mm Corsair.
    Keyboard
    Corsair K95 / Logitech diNovo Edge Wireless
    Mouse
    Logitech G402 / G502 / Mx Masters / MX Air Cordless
    Internet Speed
    100/40Mbps
    Browser
    All sorts
    Antivirus
    Kaspersky Premium
    Other Info
    I’m on a horse.
  • Operating System
    Windows 11 Pro 23H2 Build: 22631.4249
    Computer type
    Laptop
    Manufacturer/Model
    LENOVO Yoga 7i EVO OLED 14" Touchscreen i5 12 Core 16GB/512GB
    CPU
    Intel Core 12th Gen i5-1240P Processor (1.7 - 4.4GHz)
    Memory
    16GB LPDDR5 RAM
    Graphics card(s)
    Intel Iris Xe Graphics Processor
    Sound Card
    Optimized with Dolby Atmos®
    Screen Resolution
    QHD 2880 x 1800 OLED
    Hard Drives
    M.2 512GB
    Other Info
    …still on a horse.
I'm willing to try, but the description of that file says I must first be on 22H2. I'm not even on that one yet. Where do I go to manually install the 22H2 update first?

Thank you!


My Computer

System One

  • OS
    Windows 11
    Computer type
    PC/Desktop
    Manufacturer/Model
    Home built
    CPU
    Intel Core i9 9th Gen - Core i9-9900K Coffee Lake 8-Cor
    Motherboard
    ASRock Z390 Taichi
    Memory
    G.SKILL TridentZ Series 32GB (2 x 16GB) DDR4 2800 (PC4 22400) Desktop Memory Model F4-2800C14D-32GTZ
    Graphics Card(s)
    Intel UHD Graphics 630
    Sound Card
    RME Fireface UFX external soundcard
    Monitor(s) Displays
    Dell U2412M
    Screen Resolution
    1920x1200
    Hard Drives
    SAMSUNG 970 EVO M.2, SAMSUNG 860 EVO Series 2.5", WD hard drives
    PSU
    Seasonic Flagship PRIME 600 Titanium Fanless SSR-600TL 600W 80+ Titanium Full Modular ATX12V & EPS12V
    Case
    Fractal Design Define R5 Blackout Silent ATX Mid Tower
    Cooling
    Noctua NH-D15, Premium CPU Cooler with 2x NF-A15 PWM 140mm Fans
    Keyboard
    Editor Keys for Studio One
    Mouse
    wired MS mouse
    Internet Speed
    400Mbps
    Browser
    Brave
    Antivirus
    Windows Defender
    Other Info
    Silent PC for music writing/producing/mixing.
Please run admin PS > post share link

get-tpm > C:\TPM.txt


Possible bypass option:







My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
I'm willing to try, but the description of that file says I must first be on 22H2. I'm not even on that one yet. Where do I go to manually install the 22H2 update first?

Thank you!

Ah ok, sorry I missed that at the bottom

Do an in-place upgrade from 21H2 to 23H2

I still have the 23H2 ISO on my server, let me know and I’ll PM you a link

Use Option Two



My Computers

System One System Two

  • OS
    Windows Pro 23H2 Build 22631.4249
    Computer type
    PC/Desktop
    Manufacturer/Model
    Sin-built
    CPU
    Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (4th Gen?)
    Motherboard
    ASUS ROG Maximus VI Formula
    Memory
    32.0 GB of I forget and the box is in storage.
    Graphics Card(s)
    Gigabyte nVidia GeForce GTX 1660 Super OC 6GB
    Sound Card
    Onboard
    Monitor(s) Displays
    4 x LG 23MP75 - 2 x 24MK430H-B - 1 x Wacom Pro 22" Tablet
    Screen Resolution
    All over the place
    Hard Drives
    Too many to list.
    OS on Samsung 1TB 870 QVO SATA
    PSU
    Silverstone 1500
    Case
    NZXT Phantom 820 Full-Tower Case
    Cooling
    Noctua NH-D15 Elite Class Dual Tower CPU Cooler / 6 x EziDIY 120mm / 2 x Corsair 140mm somethings / 1 x 140mm Thermaltake something / 2 x 200mm Corsair.
    Keyboard
    Corsair K95 / Logitech diNovo Edge Wireless
    Mouse
    Logitech G402 / G502 / Mx Masters / MX Air Cordless
    Internet Speed
    100/40Mbps
    Browser
    All sorts
    Antivirus
    Kaspersky Premium
    Other Info
    I’m on a horse.
  • Operating System
    Windows 11 Pro 23H2 Build: 22631.4249
    Computer type
    Laptop
    Manufacturer/Model
    LENOVO Yoga 7i EVO OLED 14" Touchscreen i5 12 Core 16GB/512GB
    CPU
    Intel Core 12th Gen i5-1240P Processor (1.7 - 4.4GHz)
    Memory
    16GB LPDDR5 RAM
    Graphics card(s)
    Intel Iris Xe Graphics Processor
    Sound Card
    Optimized with Dolby Atmos®
    Screen Resolution
    QHD 2880 x 1800 OLED
    Hard Drives
    M.2 512GB
    Other Info
    …still on a horse.
If it fails, do it again but this time create the install media using the 23H2 ISO and Rufus 4.6
Then just run setup.exe from within Windows File Explorer. It should be that simple.

In fact, just do it that way to start with.

Have you used Rufus before?


My Computers

System One System Two

  • OS
    Windows Pro 23H2 Build 22631.4249
    Computer type
    PC/Desktop
    Manufacturer/Model
    Sin-built
    CPU
    Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (4th Gen?)
    Motherboard
    ASUS ROG Maximus VI Formula
    Memory
    32.0 GB of I forget and the box is in storage.
    Graphics Card(s)
    Gigabyte nVidia GeForce GTX 1660 Super OC 6GB
    Sound Card
    Onboard
    Monitor(s) Displays
    4 x LG 23MP75 - 2 x 24MK430H-B - 1 x Wacom Pro 22" Tablet
    Screen Resolution
    All over the place
    Hard Drives
    Too many to list.
    OS on Samsung 1TB 870 QVO SATA
    PSU
    Silverstone 1500
    Case
    NZXT Phantom 820 Full-Tower Case
    Cooling
    Noctua NH-D15 Elite Class Dual Tower CPU Cooler / 6 x EziDIY 120mm / 2 x Corsair 140mm somethings / 1 x 140mm Thermaltake something / 2 x 200mm Corsair.
    Keyboard
    Corsair K95 / Logitech diNovo Edge Wireless
    Mouse
    Logitech G402 / G502 / Mx Masters / MX Air Cordless
    Internet Speed
    100/40Mbps
    Browser
    All sorts
    Antivirus
    Kaspersky Premium
    Other Info
    I’m on a horse.
  • Operating System
    Windows 11 Pro 23H2 Build: 22631.4249
    Computer type
    Laptop
    Manufacturer/Model
    LENOVO Yoga 7i EVO OLED 14" Touchscreen i5 12 Core 16GB/512GB
    CPU
    Intel Core 12th Gen i5-1240P Processor (1.7 - 4.4GHz)
    Memory
    16GB LPDDR5 RAM
    Graphics card(s)
    Intel Iris Xe Graphics Processor
    Sound Card
    Optimized with Dolby Atmos®
    Screen Resolution
    QHD 2880 x 1800 OLED
    Hard Drives
    M.2 512GB
    Other Info
    …still on a horse.
Please run admin PS > post share link

get-tpm > C:\TPM.txt
Here's what I get:
----------------------------------------------------
TpmPresent : True
TpmReady : True
TpmEnabled : True
TpmActivated : True
TpmOwned : True
RestartPending : True
ManufacturerId : 1229870147
ManufacturerIdTxt : INTC
ManufacturerVersion : 402.1.0.0
ManufacturerVersionFull20 : 402.1.0.0

ManagedAuthLevel : Full
OwnerAuth : ZBYDace4NxxlrHOQcZhTGvOVb/o=
OwnerClearDisabled : False
AutoProvisioning : Enabled
LockedOut : False
LockoutHealTime : 10 minutes
LockoutCount : 0
LockoutMax : 31
SelfTest : {}


My Computer

System One

  • OS
    Windows 11
    Computer type
    PC/Desktop
    Manufacturer/Model
    Home built
    CPU
    Intel Core i9 9th Gen - Core i9-9900K Coffee Lake 8-Cor
    Motherboard
    ASRock Z390 Taichi
    Memory
    G.SKILL TridentZ Series 32GB (2 x 16GB) DDR4 2800 (PC4 22400) Desktop Memory Model F4-2800C14D-32GTZ
    Graphics Card(s)
    Intel UHD Graphics 630
    Sound Card
    RME Fireface UFX external soundcard
    Monitor(s) Displays
    Dell U2412M
    Screen Resolution
    1920x1200
    Hard Drives
    SAMSUNG 970 EVO M.2, SAMSUNG 860 EVO Series 2.5", WD hard drives
    PSU
    Seasonic Flagship PRIME 600 Titanium Fanless SSR-600TL 600W 80+ Titanium Full Modular ATX12V & EPS12V
    Case
    Fractal Design Define R5 Blackout Silent ATX Mid Tower
    Cooling
    Noctua NH-D15, Premium CPU Cooler with 2x NF-A15 PWM 140mm Fans
    Keyboard
    Editor Keys for Studio One
    Mouse
    wired MS mouse
    Internet Speed
    400Mbps
    Browser
    Brave
    Antivirus
    Windows Defender
    Other Info
    Silent PC for music writing/producing/mixing.
Please run > post share link



My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
If it fails, do it again but this time create the install media using the 23H2 ISO and Rufus 4.6
Then just run setup.exe from within Windows File Explorer. It should be that simple.

In fact, just do it that way to start with.

Have you used Rufus before?
I know nothing about Rufus. I'll have to do some research on that.


My Computer

System One

  • OS
    Windows 11
    Computer type
    PC/Desktop
    Manufacturer/Model
    Home built
    CPU
    Intel Core i9 9th Gen - Core i9-9900K Coffee Lake 8-Cor
    Motherboard
    ASRock Z390 Taichi
    Memory
    G.SKILL TridentZ Series 32GB (2 x 16GB) DDR4 2800 (PC4 22400) Desktop Memory Model F4-2800C14D-32GTZ
    Graphics Card(s)
    Intel UHD Graphics 630
    Sound Card
    RME Fireface UFX external soundcard
    Monitor(s) Displays
    Dell U2412M
    Screen Resolution
    1920x1200
    Hard Drives
    SAMSUNG 970 EVO M.2, SAMSUNG 860 EVO Series 2.5", WD hard drives
    PSU
    Seasonic Flagship PRIME 600 Titanium Fanless SSR-600TL 600W 80+ Titanium Full Modular ATX12V & EPS12V
    Case
    Fractal Design Define R5 Blackout Silent ATX Mid Tower
    Cooling
    Noctua NH-D15, Premium CPU Cooler with 2x NF-A15 PWM 140mm Fans
    Keyboard
    Editor Keys for Studio One
    Mouse
    wired MS mouse
    Internet Speed
    400Mbps
    Browser
    Brave
    Antivirus
    Windows Defender
    Other Info
    Silent PC for music writing/producing/mixing.
  • Download Rufus
  • Download the 23H2 ISO (sent you a link already)
  • Get at least an 8GB USB
  • Plug the USB in
  • Start Rufus
(Example image

  • Point it to the ISO
  • Press Start
  • After you press start, select what options you want

(Example image)


  • Click OK
  • When complete, run setup.exe from the USB
  • Follow Option 2 in the in-place tutorial I posted above.




My Computers

System One System Two

  • OS
    Windows Pro 23H2 Build 22631.4249
    Computer type
    PC/Desktop
    Manufacturer/Model
    Sin-built
    CPU
    Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (4th Gen?)
    Motherboard
    ASUS ROG Maximus VI Formula
    Memory
    32.0 GB of I forget and the box is in storage.
    Graphics Card(s)
    Gigabyte nVidia GeForce GTX 1660 Super OC 6GB
    Sound Card
    Onboard
    Monitor(s) Displays
    4 x LG 23MP75 - 2 x 24MK430H-B - 1 x Wacom Pro 22" Tablet
    Screen Resolution
    All over the place
    Hard Drives
    Too many to list.
    OS on Samsung 1TB 870 QVO SATA
    PSU
    Silverstone 1500
    Case
    NZXT Phantom 820 Full-Tower Case
    Cooling
    Noctua NH-D15 Elite Class Dual Tower CPU Cooler / 6 x EziDIY 120mm / 2 x Corsair 140mm somethings / 1 x 140mm Thermaltake something / 2 x 200mm Corsair.
    Keyboard
    Corsair K95 / Logitech diNovo Edge Wireless
    Mouse
    Logitech G402 / G502 / Mx Masters / MX Air Cordless
    Internet Speed
    100/40Mbps
    Browser
    All sorts
    Antivirus
    Kaspersky Premium
    Other Info
    I’m on a horse.
  • Operating System
    Windows 11 Pro 23H2 Build: 22631.4249
    Computer type
    Laptop
    Manufacturer/Model
    LENOVO Yoga 7i EVO OLED 14" Touchscreen i5 12 Core 16GB/512GB
    CPU
    Intel Core 12th Gen i5-1240P Processor (1.7 - 4.4GHz)
    Memory
    16GB LPDDR5 RAM
    Graphics card(s)
    Intel Iris Xe Graphics Processor
    Sound Card
    Optimized with Dolby Atmos®
    Screen Resolution
    QHD 2880 x 1800 OLED
    Hard Drives
    M.2 512GB
    Other Info
    …still on a horse.
Also may be useful:



My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
Please see the motherboard FAQ for possible troubleshooting steps:


How do I check if a system supports TPM 2.0 and bitlocker?

TPM2.0 module is required in Windows 11 specification, does it need TPM2.0 hardware module?


My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
Well, after all this mucking around with TPM last night I woke up this morning with the 23H2 update waiting for me. It all seems to be working now! I guess we succeeded in getting Windows to re-scan the TPM. Thank you, everyone, for your help, suggestions, and input. I really appreciate this. Do I need to go back somehow and mark this thread SOLVED!


My Computer

System One

  • OS
    Windows 11
    Computer type
    PC/Desktop
    Manufacturer/Model
    Home built
    CPU
    Intel Core i9 9th Gen - Core i9-9900K Coffee Lake 8-Cor
    Motherboard
    ASRock Z390 Taichi
    Memory
    G.SKILL TridentZ Series 32GB (2 x 16GB) DDR4 2800 (PC4 22400) Desktop Memory Model F4-2800C14D-32GTZ
    Graphics Card(s)
    Intel UHD Graphics 630
    Sound Card
    RME Fireface UFX external soundcard
    Monitor(s) Displays
    Dell U2412M
    Screen Resolution
    1920x1200
    Hard Drives
    SAMSUNG 970 EVO M.2, SAMSUNG 860 EVO Series 2.5", WD hard drives
    PSU
    Seasonic Flagship PRIME 600 Titanium Fanless SSR-600TL 600W 80+ Titanium Full Modular ATX12V & EPS12V
    Case
    Fractal Design Define R5 Blackout Silent ATX Mid Tower
    Cooling
    Noctua NH-D15, Premium CPU Cooler with 2x NF-A15 PWM 140mm Fans
    Keyboard
    Editor Keys for Studio One
    Mouse
    wired MS mouse
    Internet Speed
    400Mbps
    Browser
    Brave
    Antivirus
    Windows Defender
    Other Info
    Silent PC for music writing/producing/mixing.
Back
Top Bottom
