Starlink ethernet adapter


Hazel123

Well-known member
Power User
VIP
Local time
9:38 AM
Posts
2,012
OS
Windows 11
As mentioned in another post, I just got Starlink. The router doesn't have any ports and they sell an ethernet adapter, which I've sent for. From what I can see it just has the one slot for one ethernet cable. So I'm just trying to work out the best way to connect a second router, plus an existing ethernet cable to a desktop.

I could link the second router via the ethernet adapter and run the desktop ethernet cable to the back of the second (Asus) router which already has ethernet points. Would that be the best way to do it?


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 14-ce3514sa
    CPU
    Core i5
    Memory
    16gb
    Hard Drives
    Samsung 970 evo plus 2TB
    Cooling
    Could be better
    Internet Speed
    200mbps Starlink
    Browser
    Firefox
    Other Info
    Originally installed with a 500gb H10 Optane ssd
My Wireless DSL PoE Modem has 2 Ethernet ports, one is the power/data cable out to the dish/antenna and the other is for a computer. For my network the computer-cable is plugged into the Uplink port on the Wireless Router then the computer plugs into one of the 4 ports on the Router.


My Computers

System One System Two

  • OS
    Win11 Pro RTM
    Computer type
    Laptop
    Manufacturer/Model
    Dell Vostro 3400
    CPU
    Intel Core i5 11th Gen. 2.40GHz
    Memory
    12GB
    Hard Drives
    256GB SSD NVMe
  • Operating System
    Windows 11 Pro RTM x64
    Computer type
    PC/Desktop
    Manufacturer/Model
    Dell Vostro 5890
    CPU
    Intel Core i5 10th Gen. 2.90GHz
    Memory
    16GB
    Graphics card(s)
    Onboard, no VGA, using a DisplayPort-to-VGA adapter
    Monitor(s) Displays
    24" Dell
    Hard Drives
    512GB SSD NVMe, 2TB WDC HDD
    Browser
    Firefox, Edge
    Antivirus
    Windows Defender/Microsoft Security
second router via the ethernet adapter and run the desktop ethernet cable to the back of the second (Asus) router which already has ethernet points. Would that be the best way to do it?
Yes, As long as old router is set up in access point mode.


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2 22631.3296
    Computer type
    PC/Desktop
    Manufacturer/Model
    Dell Optiplex 7080
    CPU
    i9-10900 10 core 20 threads
    Motherboard
    DELL 0J37VM
    Memory
    32 gb
    Graphics Card(s)
    none-Intel UHD Graphics 630
    Sound Card
    Integrated Realtek
    Monitor(s) Displays
    Benq 27
    Screen Resolution
    2560x1440
    Hard Drives
    1tb Solidigm m.2 +256gb ssd+512 gb usb m.2 sata
    PSU
    500w
    Case
    MT
    Cooling
    Dell Premium
    Keyboard
    Logitech wired
    Mouse
    Logitech wireless
    Internet Speed
    so slow I'm too embarrassed to tell
    Browser
    Firefox
    Antivirus
    Defender+MWB Premium
  • Operating System
    Windows 10 Pro 22H2 19045.3930
    Computer type
    PC/Desktop
    Manufacturer/Model
    Dell Optiplex 9020
    CPU
    i7-4770
    Memory
    24 gb
    Monitor(s) Displays
    Benq 27
    Screen Resolution
    2560x1440
    Hard Drives
    256 gb Toshiba BG4 M.2 NVE SSB and 1 tb hdd
    PSU
    500w
    Case
    MT
    Cooling
    Dell factory
    Mouse
    Logitech wireless
    Keyboard
    Logitech wired
    Internet Speed
    still not telling
    Browser
    Firefox
    Antivirus
    Defender+MWB Premium
Not sure how to do that. Is that the same as bypass mode? Ie so second router becomes the main router.


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 14-ce3514sa
    CPU
    Core i5
    Memory
    16gb
    Hard Drives
    Samsung 970 evo plus 2TB
    Cooling
    Could be better
    Internet Speed
    200mbps Starlink
    Browser
    Firefox
    Other Info
    Originally installed with a 500gb H10 Optane ssd
so second router becomes the main router
No. Your main router will continue to be your main router. You are seeking to accomplish 3 things.
1. Users to be able to login as "Guest" (Your new router does not have this option, but your old router does)
2. Be able to use ethernet ports as well as wireless.
3. Have stronger wireless signal in other parts of your home. (this is assuming your second router will be located in another room from your main router and you are able to use a longer ethernet cable to connect to it. If your cable length is limited and it's located in same room, chances are wireless signal strength will be the same so you will accomplish only 1 & 2)

I'm using mine as an example:
Router A=main router has ip of 192.168.0.1-assigned SSID Linda. It broadcasts the ssids Linda and Linda-5G
This router handles DHCP and assigns the ip addresses for all my devices no matter which router/ssid I choose in list of available networks.

Router B=secondary router wired with long cat6 cable located in my office at other end of house (thereby giving me a stronger wireless signal in my back yard) -I manually assigned its ip as 192.168.0.2 (a subset of my main router) Since my old router did not have an AP mode built in, I had to disable DHCP and port forwarding. This is done automatically IF your old router has an AP option to select. I assigned SSID Linda1 to this secondary router. It broadcasts ssids Linda1, Linda1-5G. Linda1-Guest and Linda1-Guest-5G.
(It is entirely up to you whether you want to broadcast each band or not, depending on how you option it. You may choose to use it as a Guest router only.The important thing is that it's assigned its own ssid)

My main computer in my office is wired to this router's ethernet port.

Know that since an AP uses a separate ssid from your main router, if you roam within your home using a wireless device, your wireless signal will NOT change from one router to the other since the ssids are different. Only a range extender retains its wireless signal throughout your home. However, your bandwith is cut in half by using range extenders.


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2 22631.3296
    Computer type
    PC/Desktop
    Manufacturer/Model
    Dell Optiplex 7080
    CPU
    i9-10900 10 core 20 threads
    Motherboard
    DELL 0J37VM
    Memory
    32 gb
    Graphics Card(s)
    none-Intel UHD Graphics 630
    Sound Card
    Integrated Realtek
    Monitor(s) Displays
    Benq 27
    Screen Resolution
    2560x1440
    Hard Drives
    1tb Solidigm m.2 +256gb ssd+512 gb usb m.2 sata
    PSU
    500w
    Case
    MT
    Cooling
    Dell Premium
    Keyboard
    Logitech wired
    Mouse
    Logitech wireless
    Internet Speed
    so slow I'm too embarrassed to tell
    Browser
    Firefox
    Antivirus
    Defender+MWB Premium
  • Operating System
    Windows 10 Pro 22H2 19045.3930
    Computer type
    PC/Desktop
    Manufacturer/Model
    Dell Optiplex 9020
    CPU
    i7-4770
    Memory
    24 gb
    Monitor(s) Displays
    Benq 27
    Screen Resolution
    2560x1440
    Hard Drives
    256 gb Toshiba BG4 M.2 NVE SSB and 1 tb hdd
    PSU
    500w
    Case
    MT
    Cooling
    Dell factory
    Mouse
    Logitech wireless
    Keyboard
    Logitech wired
    Internet Speed
    still not telling
    Browser
    Firefox
    Antivirus
    Defender+MWB Premium
Thanks. Yes I believe there are two options with the Starlink router. One is to bypass it so the second router becomes the main router (in which case presumably it's just a modem then). I was thinking of this option because then I won't need an extender and have the issue of bandwidth drop. The Asus router covers the whole area better than the Skylink router. The other option is to not bypass it and have the second router as an extender. So that's what I was trying to work out.

If the main router is the Asus one, bypassing the skylink one - presumably I can just do the ethernet for the desktop straight off the Asus one?


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 14-ce3514sa
    CPU
    Core i5
    Memory
    16gb
    Hard Drives
    Samsung 970 evo plus 2TB
    Cooling
    Could be better
    Internet Speed
    200mbps Starlink
    Browser
    Firefox
    Other Info
    Originally installed with a 500gb H10 Optane ssd
Sure. If there is an option in the Starlink to turn routing function off, do that, connect it to your own router that works the way you want it to, and test it. You will know right quick if that's what bypass option actually does.


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2 22631.3296
    Computer type
    PC/Desktop
    Manufacturer/Model
    Dell Optiplex 7080
    CPU
    i9-10900 10 core 20 threads
    Motherboard
    DELL 0J37VM
    Memory
    32 gb
    Graphics Card(s)
    none-Intel UHD Graphics 630
    Sound Card
    Integrated Realtek
    Monitor(s) Displays
    Benq 27
    Screen Resolution
    2560x1440
    Hard Drives
    1tb Solidigm m.2 +256gb ssd+512 gb usb m.2 sata
    PSU
    500w
    Case
    MT
    Cooling
    Dell Premium
    Keyboard
    Logitech wired
    Mouse
    Logitech wireless
    Internet Speed
    so slow I'm too embarrassed to tell
    Browser
    Firefox
    Antivirus
    Defender+MWB Premium
  • Operating System
    Windows 10 Pro 22H2 19045.3930
    Computer type
    PC/Desktop
    Manufacturer/Model
    Dell Optiplex 9020
    CPU
    i7-4770
    Memory
    24 gb
    Monitor(s) Displays
    Benq 27
    Screen Resolution
    2560x1440
    Hard Drives
    256 gb Toshiba BG4 M.2 NVE SSB and 1 tb hdd
    PSU
    500w
    Case
    MT
    Cooling
    Dell factory
    Mouse
    Logitech wireless
    Keyboard
    Logitech wired
    Internet Speed
    still not telling
    Browser
    Firefox
    Antivirus
    Defender+MWB Premium
Thanks - I kind of worked out what I meant after reading your post :-) Apparently it's an option to bypass and have the other router as the main router. I'll have to see if that works.

So basically I only need the ethernet adapter to connect the routers. And connect the desktop ethernet to the Asus router - as I did before.


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 14-ce3514sa
    CPU
    Core i5
    Memory
    16gb
    Hard Drives
    Samsung 970 evo plus 2TB
    Cooling
    Could be better
    Internet Speed
    200mbps Starlink
    Browser
    Firefox
    Other Info
    Originally installed with a 500gb H10 Optane ssd
@Hazel123, Are you still happy with the speed you're getting?


My Computers

System One System Two

  • OS
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Dell XPS 15 9510 OLED
    CPU
    11th Gen i9 -11900H
    Memory
    32 GB 3200 MHz DDR4
    Graphics Card(s)
    NVIDIA® GeForce® RTX 3050Ti
    Monitor(s) Displays
    15.6" OLED Infinity Edge Touch
    Screen Resolution
    16:10 Aspect Ratio (3456 x 2160)
    Hard Drives
    1 Terabyte M.2 PCIe NVMe SSD
    2 Thunderbolt™ 4 (USB Type-C™)
    1 USB 3.2 Gen 2 (USB Type-C™)
    SD Card Reader (SD, SDHC, SDXC)
    Internet Speed
    900 Mbps Netgear Orbi + 2 Satellites
    Browser
    Microsoft Edge (Chromium) + Bing
    Antivirus
    Microsoft Windows Security (Defender)
    Other Info
    Microsoft 365 subscription
    Microsoft OneDrive 1TB Cloud
    Microsoft Outlook
    Microsoft OneNote
    Microsoft PowerToys
    Microsoft Visual Studio
    Microsoft Visual Studio Code
    Macrium Reflect
    Dell Support Assist
    Dell Command | Update
    LastPass Password Manager
    Amazon Kindle
    Interactive Brokers Trader Workstation
    Lightroom/Photoshop subscription
  • Operating System
    Windows 11 Pro
    Computer type
    Tablet
    Manufacturer/Model
    Microsoft Surface Pro 7
    CPU
    i5
    Memory
    8 GB
    Hard Drives
    256GB SSD
    Internet Speed
    900 Mbps Netgear Orbi + 2 Satellites
    Browser
    Microsoft Edge (Chromium) + Bing
    Antivirus
    Microsoft Windows Security (Defender)
    Other Info
    Microsoft 365 subscription (Office)
    Microsoft OneDrive 1TB Cloud
    Microsoft Outlook
    Microsoft OneNote
    Microsoft Visual Studio
    Amazon Kindle
    Interactive Brokers Trader Workstation
    Lightroom/Photoshop subscription
Absolutely. The speeds vary. At one point they were over 200mbps when they're only advertised up to 160mbps :-) . However the wifi strength (and speeds) drop off, the further you are from the router. So the router is in the computer room with the fastest speeds. In other parts of the house it's only 30mbps when it's 80 to 150 in the computer room. But I'm not complaining. "Only 30mbps" is still a lot more than we had before lol.

It's ideal for open countryside. Really didn't expect it to work and still getting over the shock.


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 14-ce3514sa
    CPU
    Core i5
    Memory
    16gb
    Hard Drives
    Samsung 970 evo plus 2TB
    Cooling
    Could be better
    Internet Speed
    200mbps Starlink
    Browser
    Firefox
    Other Info
    Originally installed with a 500gb H10 Optane ssd
All of this is explained by following these links:





My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2
    Computer type
    Laptop
    Manufacturer/Model
    ASUS TUF Gaming A15 (2022)
    CPU
    AMD Ryzen 7 6800H with Radeon 680M GPU (486MB RAM)
    Memory
    Micron DDR5-4800 (2400MHz) 16GB (2 x 8GB)
    Graphics Card(s)
    NVIDIA RTX 3060 Laptop (6GB RAM)
    Sound Card
    n/a
    Monitor(s) Displays
    15.6-inch
    Screen Resolution
    1920x1080 300Hz
    Hard Drives
    2 x Samsung 980 (1TB M.2 NVME SSD)
    PSU
    n/a
    Mouse
    Wireless Mouse M510
    Internet Speed
    1200Mbps/250Mbps
    Browser
    Firefox
    Antivirus
    Malwarebytes
  • Operating System
    Windows 11 Pro 23H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom build
    CPU
    AMD Ryzen 7 3700X
    Motherboard
    ASUS PRIME X370-PRO
    Memory
    G.SKILL Flare X 32GB (2x16GB) DDR4
    Graphics card(s)
    ASUS ROG-STRIX-RTX3060TI-08G-V2-GAMING (RTX 3060-Ti, 8GB RAM)
    Monitor(s) Displays
    Samsung S23A300B (23-in LED)
    Screen Resolution
    1080p 60Hz
    Hard Drives
    2TB XPG SX8200 Pro (M2. PCIe SSD) || 2TB Intel 660P (M2. PCIe SSD) ||
    PSU
    Corsair RM750x (750 watts)
    Case
    Cooler Master MasterCase 5
    Cooling
    Corsair H60 AIO water cooler
    Mouse
    Logitech K350 (wireless)
    Keyboard
    Logitech M510 (wireless)
    Internet Speed
    1200 Mbps down / 200 Mbps up
    Browser
    Firefox, Edge, Chrome
    Antivirus
    Malwarebytes (Premium)
    Other Info
    ASUS Blu-ray Burner BW-16D1HT (SATA) || Western Digital Elements 12TB USB 3.0 external hard drive used with Acronis True Image backup software || HP OfficeJet Pro 6975 Printer/Scanner
Ok so wondering if I need a modem as well - my Asus router usually needs a separate modem. I'm guessing the starlink router would act as the modem - but not entirely sure about that working as a modem if wifi is disabled via the bypass option.

I actually have two Asus routers - one that needs a separate modem and one dsl one with built in modem. So not sure which one to use. Would it be "too much modem" if I had the asus router with the built in modem and the starlink router was also a modem? (As you can see I know nothing about modems other than that some routers need a separate one). Googling doesn't mention much about whether a 3rd party router needs a modem as well.


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 14-ce3514sa
    CPU
    Core i5
    Memory
    16gb
    Hard Drives
    Samsung 970 evo plus 2TB
    Cooling
    Could be better
    Internet Speed
    200mbps Starlink
    Browser
    Firefox
    Other Info
    Originally installed with a 500gb H10 Optane ssd
Apparently Starlink doesn't use a conventional modem. Its router contains a propropietaty modem like hardware that converts the signal from the antenna to Wi-Fi. To use your own router you need to connect the Starlink Ethernet adapter to the Starlink Router and connect your router to that. If your router also includes WiFi you can disable the Starlink router's internal WiFi and use your routers WiFi instead. To turn off the Starlink router's internal WiFi turn on ‘Bypass’ mode in the Starlink app.


My Computers

System One System Two

  • OS
    Windows 11 Pro 23H2
    Computer type
    Laptop
    Manufacturer/Model
    ASUS TUF Gaming A15 (2022)
    CPU
    AMD Ryzen 7 6800H with Radeon 680M GPU (486MB RAM)
    Memory
    Micron DDR5-4800 (2400MHz) 16GB (2 x 8GB)
    Graphics Card(s)
    NVIDIA RTX 3060 Laptop (6GB RAM)
    Sound Card
    n/a
    Monitor(s) Displays
    15.6-inch
    Screen Resolution
    1920x1080 300Hz
    Hard Drives
    2 x Samsung 980 (1TB M.2 NVME SSD)
    PSU
    n/a
    Mouse
    Wireless Mouse M510
    Internet Speed
    1200Mbps/250Mbps
    Browser
    Firefox
    Antivirus
    Malwarebytes
  • Operating System
    Windows 11 Pro 23H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom build
    CPU
    AMD Ryzen 7 3700X
    Motherboard
    ASUS PRIME X370-PRO
    Memory
    G.SKILL Flare X 32GB (2x16GB) DDR4
    Graphics card(s)
    ASUS ROG-STRIX-RTX3060TI-08G-V2-GAMING (RTX 3060-Ti, 8GB RAM)
    Monitor(s) Displays
    Samsung S23A300B (23-in LED)
    Screen Resolution
    1080p 60Hz
    Hard Drives
    2TB XPG SX8200 Pro (M2. PCIe SSD) || 2TB Intel 660P (M2. PCIe SSD) ||
    PSU
    Corsair RM750x (750 watts)
    Case
    Cooler Master MasterCase 5
    Cooling
    Corsair H60 AIO water cooler
    Mouse
    Logitech K350 (wireless)
    Keyboard
    Logitech M510 (wireless)
    Internet Speed
    1200 Mbps down / 200 Mbps up
    Browser
    Firefox, Edge, Chrome
    Antivirus
    Malwarebytes (Premium)
    Other Info
    ASUS Blu-ray Burner BW-16D1HT (SATA) || Western Digital Elements 12TB USB 3.0 external hard drive used with Acronis True Image backup software || HP OfficeJet Pro 6975 Printer/Scanner
Apparently Starlink doesn't use a conventional modem. Its router contains a propropietaty modem like hardware that converts the signal from the antenna to Wi-Fi. To use your own router you need to connect the Starlink Ethernet adapter to the Starlink Router and connect your router to that. If your router also includes WiFi you can disable the Starlink router's internal WiFi and use your routers WiFi instead. To turn off the Starlink router's internal WiFi turn on ‘Bypass’ mode in the Starlink app.
Thanks. So basically I don't need a modem? So many articles say about attaching your own router, but don't specify if a modem-less router would work better than a dsl router (or work at all). I guess I can try it out and see which works best.

That makes sense though - satellite is not dsl so you would think no dsl modem would be necessary. I will try with the Asus router (non dsl) and no modem.


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 14-ce3514sa
    CPU
    Core i5
    Memory
    16gb
    Hard Drives
    Samsung 970 evo plus 2TB
    Cooling
    Could be better
    Internet Speed
    200mbps Starlink
    Browser
    Firefox
    Other Info
    Originally installed with a 500gb H10 Optane ssd
Ok this seems to answer it also "A modem is not used with Starlink internet."


I find this interesting, as some people adding their own router might use one with a dsl built in modem without thinking. Although to be fair, I guess most people who would attach a third party router, have a good one that doesn't have dsl built in. Most Asus routers don't have a dsl modem and need a separate one.

But then some people might decide to use their BT Home hub or similar if the wifi range is better.

Just wondering what would happen if you used a dsl router when the modem isn't necessary? Slow downs? Or just wouldn't work?


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 14-ce3514sa
    CPU
    Core i5
    Memory
    16gb
    Hard Drives
    Samsung 970 evo plus 2TB
    Cooling
    Could be better
    Internet Speed
    200mbps Starlink
    Browser
    Firefox
    Other Info
    Originally installed with a 500gb H10 Optane ssd
Ok as an update, if anyone is interested or in a similar situation at some point. The modem is built into the satellite dish - so the Starlink router is just a router. Turning of "bypass" is done first. Then attaching another non dsl router, via ethernet to the 3rd party router WAN port. No particular settings needed other than setting up ssid and password. So fairly simple apparently. (I hope - haven't done it yet!).


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 14-ce3514sa
    CPU
    Core i5
    Memory
    16gb
    Hard Drives
    Samsung 970 evo plus 2TB
    Cooling
    Could be better
    Internet Speed
    200mbps Starlink
    Browser
    Firefox
    Other Info
    Originally installed with a 500gb H10 Optane ssd
Thanks. So basically I don't need a modem? So many articles say about attaching your own router, but don't specify if a modem-less router would work better than a dsl router (or work at all). I guess I can try it out and see which works best.

That makes sense though - satellite is not dsl so you would think no dsl modem would be necessary. I will try with the Asus router (non dsl) and no modem.
The Satellite uses radio frequencies so the modem has to convert the data before sending it to the router and vice versa.


My Computers

System One System Two

  • OS
    Windows 11 Canary Channel
    Computer type
    PC/Desktop
    Manufacturer/Model
    PowerSpec B746
    CPU
    Intel Core i7-10700K
    Motherboard
    ASRock Z490 Phantom Gaming 4/ax
    Memory
    16GB (8GB PC4-19200 DDR4 SDRAM x2)
    Graphics Card(s)
    NVIDIA GeForce GTX 1050 TI
    Sound Card
    Realtek Audio
    Monitor(s) Displays
    Samsung SAM0A87 Samsung SAM0D32
    Screen Resolution
    1920 x 1080
    Hard Drives
    NVMe WDC WDS100T2B0C-00PXH0 1TB
    Samsung SSD 860 EVO 1TB
    PSU
    750 Watts (62.5A)
    Case
    PowerSpec/Lian Li ATX 205
    Keyboard
    Logitech K270
    Mouse
    Logitech M185
    Browser
    Microsoft Edge and Firefox
    Antivirus
    ESET Internet Security
  • Operating System
    Windows 11 Canary Channel
    Computer type
    PC/Desktop
    Manufacturer/Model
    PowerSpec G156
    CPU
    Intel Core i5-8400 CPU @ 2.80GHz
    Motherboard
    AsusTeK Prime B360M-S
    Memory
    16 MB DDR 4-2666
    Monitor(s) Displays
    23" Speptre HDMI 75Hz
    Screen Resolution
    1920x1080
    Hard Drives
    Samsung 970 EVO 500GB NVMe
    Mouse
    Logitek M185
    Keyboard
    Logitek K270
    Browser
    Firefox, Edge and Edge Canary
    Antivirus
    Windows Defender

Latest Support Threads

Back
Top Bottom
