Personalization Add or Remove Drive Space Indicator Bar in Windows 11


  • Staff

The drive space indicator bar gives you a visual display of available free space for each drive shown on This PC in File Explorer.

The drive space indicator bar is blue until free space gets below 10%, then the bar turns red to help let you know the drive is low on free space.

If wanted, you can remove the drive space indicator bar to no longer show on drive tiles.

This tutorial will show you how to add or remove the drive space indicator bar for all users in Windows 10 and Windows 11.


You must be signed in as an administrator to add or remove the drive space indicator bar for all drives.

The drive space indicator bar will only show while using either the Tiles or Content layout view in This PC.



EXAMPLE: Add and remove drive space indicator bar




Here's How:

1 Do step 2 (add) or step 3 (remove) below for what you would like to do.

2 Add Drive Space Indicator Bar for All Drives

This is the default setting.


A) Click/tap on the Download button below to download the file below, and go to step 4 below.​

Add_drive_space_indicator_bar.reg


(Contents of REG file for reference)
Code:
Windows Registry Editor Version 5.00

[HKEY_LOCAL_MACHINE\SOFTWARE\Classes\Drive]
"TileInfo"="prop:*System.PercentFull;System.Computer.DecoratedFreeSpace;System.Volume.FileSystem"

3 Remove Drive Space Indicator Bar for All Drives

A) Click/tap on the Download button below to download the file below, and go to step 4 below.​

Remove_drive_space_indicator_bar.reg


(Contents of REG file for reference)
Code:
Windows Registry Editor Version 5.00

[HKEY_LOCAL_MACHINE\SOFTWARE\Classes\Drive]
"TileInfo"="prop:*System.Computer.DecoratedFreeSpace;System.Volume.FileSystem"

4 Save the .reg file to your desktop.

5 Double click/tap on the downloaded .reg file to merge it.

6 When prompted, click/tap on Run, Yes (UAC), Yes, and OK to approve the merge.

7 If File Explorer is currently open, then close and reopen File Explorer to apply.

8 You can now delete the downloaded .reg file if you like.


That's it,
Shawn Brink


Attachments

  • Drive.png
    2.7 KB · Views: 14
  • Add_drive_space_indicator_bar.reg
    702 bytes · Views: 25
  • Remove_drive_space_indicator_bar.reg
    664 bytes · Views: 28
Last edited:

Bug locker

Active member
VIP
Local time
11:53 AM
Posts
119
Location
Athens
Visit site
OS
Windows 11 Pro
Hi.
In both cases i dont see the drive space indicator bar.:(
Any idea how to fix that ?
I am running Win 11 pro 22H2 22621.819
Thanks.:-)


My Computer

System One

  • OS
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 17 cd2205nw
    CPU
    Intel 113700H
    Memory
    16GB
    Graphics Card(s)
    NVIDIA RTX 3050 ti
    Screen Resolution
    1980x1020
    Hard Drives
    Micron 512GB
    Mouse
    Logitech
    Internet Speed
    100Mbs
    Browser
    Vivaldi , Edge
    Antivirus
    Norton Plus

Brink

Administrator
Staff member
MVP
Thread Starter
Local time
3:53 AM
Posts
7,424
Visit site
OS
Windows 11 Pro for Workstations
Hi.
In both cases i dont see the drive space indicator bar.:(
Any idea how to fix that ?
I am running Win 11 pro 22H2 22621.819
Thanks.:-)

Hello mate, :-)

Do you have the This PC window set to show in tile view?

If you do, then go ahead and post a screenshot showing what you see to see if anything may stand out.



My Computers

System One System Two

  • OS
    Windows 11 Pro for Workstations
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom self build
    CPU
    Intel i7-8700K 5 GHz
    Motherboard
    ASUS ROG Maximus XI Formula Z390
    Memory
    16 GB (8GBx2) G.SKILL TridentZ DDR4 3200 MHz
    Graphics Card(s)
    ASUS ROG-STRIX-GTX1080TI-O11G-GAMING
    Sound Card
    Integrated Digital Audio (S/PDIF)
    Monitor(s) Displays
    2 x Samsung Odyssey G75 27"
    Screen Resolution
    2560x1440
    Hard Drives
    1TB Samsung 990 PRO M.2,
    1TB Samsung 980 PRO M.2,
    6TB WD Black WD6001FZWX
    8TB WD MyCloudEX2Ultra NAS
    PSU
    Seasonic Prime Titanium 850W
    Case
    Thermaltake Core P3 wall mounted
    Cooling
    Corsair Hydro H115i
    Keyboard
    Logitech wireless K800
    Mouse
    Logitech MX Master 3
    Internet Speed
    1 Gbps Download and 35 Mbps Upload
    Browser
    Google Chrome
    Antivirus
    Microsoft Defender and Malwarebytes Premium
    Other Info
    Logitech Z625 speaker system,
    Logitech BRIO 4K Pro webcam,
    HP Color LaserJet Pro MFP M477fdn,
    Linksys EA9500 router,
    Motorola MB8611 cable modem,
    APC SMART-UPS RT 1000 XL - SURT1000XLI,
    Galaxy S20 Ultra 5G phone
  • Operating System
    Windows 11 Pro for Workstations
    Computer type
    Laptop
    Manufacturer/Model
    HP Spectre x360 2in1
    CPU
    i7-1065G7 3.9 GHz
    Memory
    16 GB LPDDR4-3200
    Graphics card(s)
    Intel Iris Plus
    Sound Card
    Intel SST
    Monitor(s) Displays
    13.3" 4K UWVA AMOLED multitouch
    Screen Resolution
    3840 x 2160
    Hard Drives
    512 GB PCIe NVMe M.2 SSD
    Browser
    Google Chrome
    Antivirus
    Windows Defender and Malwarebytes Premium

Bug locker

Active member
VIP
Local time
11:53 AM
Posts
119
Location
Athens
Visit site
OS
Windows 11 Pro
Hello mate, :-)

Do you have the This PC window set to show in tile view?

If you do, then go ahead and post a screenshot showing what you see to see if anything may stand out.


Yes, they were not tiles in the view. With the tiles it displays them correctly.
Thanks ! :thumbsup:


My Computer

System One

  • OS
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    HP Pavilion 17 cd2205nw
    CPU
    Intel 113700H
    Memory
    16GB
    Graphics Card(s)
    NVIDIA RTX 3050 ti
    Screen Resolution
    1980x1020
    Hard Drives
    Micron 512GB
    Mouse
    Logitech
    Internet Speed
    100Mbs
    Browser
    Vivaldi , Edge
    Antivirus
    Norton Plus

Brink

Administrator
Staff member
MVP
Thread Starter
Local time
3:53 AM
Posts
7,424
Visit site
OS
Windows 11 Pro for Workstations

My Computers

System One System Two

  • OS
    Windows 11 Pro for Workstations
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom self build
    CPU
    Intel i7-8700K 5 GHz
    Motherboard
    ASUS ROG Maximus XI Formula Z390
    Memory
    16 GB (8GBx2) G.SKILL TridentZ DDR4 3200 MHz
    Graphics Card(s)
    ASUS ROG-STRIX-GTX1080TI-O11G-GAMING
    Sound Card
    Integrated Digital Audio (S/PDIF)
    Monitor(s) Displays
    2 x Samsung Odyssey G75 27"
    Screen Resolution
    2560x1440
    Hard Drives
    1TB Samsung 990 PRO M.2,
    1TB Samsung 980 PRO M.2,
    6TB WD Black WD6001FZWX
    8TB WD MyCloudEX2Ultra NAS
    PSU
    Seasonic Prime Titanium 850W
    Case
    Thermaltake Core P3 wall mounted
    Cooling
    Corsair Hydro H115i
    Keyboard
    Logitech wireless K800
    Mouse
    Logitech MX Master 3
    Internet Speed
    1 Gbps Download and 35 Mbps Upload
    Browser
    Google Chrome
    Antivirus
    Microsoft Defender and Malwarebytes Premium
    Other Info
    Logitech Z625 speaker system,
    Logitech BRIO 4K Pro webcam,
    HP Color LaserJet Pro MFP M477fdn,
    Linksys EA9500 router,
    Motorola MB8611 cable modem,
    APC SMART-UPS RT 1000 XL - SURT1000XLI,
    Galaxy S20 Ultra 5G phone
  • Operating System
    Windows 11 Pro for Workstations
    Computer type
    Laptop
    Manufacturer/Model
    HP Spectre x360 2in1
    CPU
    i7-1065G7 3.9 GHz
    Memory
    16 GB LPDDR4-3200
    Graphics card(s)
    Intel Iris Plus
    Sound Card
    Intel SST
    Monitor(s) Displays
    13.3" 4K UWVA AMOLED multitouch
    Screen Resolution
    3840 x 2160
    Hard Drives
    512 GB PCIe NVMe M.2 SSD
    Browser
    Google Chrome
    Antivirus
    Windows Defender and Malwarebytes Premium

ThrashZone

Minor Threat
Power User
VIP
Local time
3:53 AM
Posts
1,267
Visit site
OS
Linux-Mint-Cinnamon-20.2 Win-7-10-11Pro's
Hi,
Nice to get rid of unnecessary icons that only take up to much space.
