Hi - I am getting random BSOD for last month or so. I have tried updating all my drivers with driver easy. The only one that wont update was NVIDIA A2000 driver. I removed the driver for the GPU and reinstalled from lenovo support . Also I have performed Windows Update today ( after the log collector).
Any ideas much appreciated.
Updated links to make public

Link to Win Debug iAnalyze

Link to log collector zip file on google drive

Last edited:

My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    CPU
    Intel(R) Xeon(R) W-11955M CPU @ 2.60GHz 2.61 GHz
    Motherboard
    LENOVO 20YUCTO1WW
    Memory
    128GB
    Graphics Card(s)
    NVIDIA RTX A2000 Laptop GPU
    Screen Resolution
    4K


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    CPU
    Intel(R) Xeon(R) W-11955M CPU @ 2.60GHz 2.61 GHz
    Motherboard
    LENOVO 20YUCTO1WW
    Memory
    128GB
    Graphics Card(s)
    NVIDIA RTX A2000 Laptop GPU
    Screen Resolution
    4K
Please perform the following steps:


1) Uninstall all drivers that were installed using third party software

(It's best to install drivers displayed on the Lenovo website)



2) If there is any uncertainty about the drivers installed by third party software then perform a system restore that predates the installation of the drivers and third party software



3) Run:

https://www.elevenforum.com/attachme...log-bat.36285/

Post a share link into this thread using one drive, drop box, or google drive.



4) Make a new restore point:




5) Run HD Tune (free or trial version) (all drives)

Post images or share links for results on these tabs:

a) Health
b) Benchmark
c) Full error scan



6) Run Sea Tools for Windows Long Generic test:



Post images or share links for results of the Sea Tools Long Generic tests.



7) Run Memtest86 (free version) overnight while sleeping


The computer has 4 RAM modules (32 GB each) = 128 GB

If you're unable to run Memtest86 continuously for several days then all RAM modules can be removed and labeled.

Then test one RAM module at a time in the same DIMM.

Take pictures > post images or share links into this thread using one drive, drop box, or google drive

Memtest86 has a feature to create text / html reports.

If possible, please include the reports with the images in the share links.



8) These steps / tests can run overnight while sleeping:

a) HD Tune full error scan
b) Sea Tools for Windows long generic test
c) Memtest86



9) Reinstall from the Lenovo website:

syntp.sys
Synaptics TouchPad HID Mini Driver


syntp Synaptics TouchPad HID Mini Driver c:\windows\system32\drivers\syntp.sys




Code:
139
1E
3
50
7E
A
FC
141
144
193
1A1

Last edited:

My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation

My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    CPU
    Intel(R) Xeon(R) W-11955M CPU @ 2.60GHz 2.61 GHz
    Motherboard
    LENOVO 20YUCTO1WW
    Memory
    128GB
    Graphics Card(s)
    NVIDIA RTX A2000 Laptop GPU
    Screen Resolution
    4K

My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    CPU
    Intel(R) Xeon(R) W-11955M CPU @ 2.60GHz 2.61 GHz
    Motherboard
    LENOVO 20YUCTO1WW
    Memory
    128GB
    Graphics Card(s)
    NVIDIA RTX A2000 Laptop GPU
    Screen Resolution
    4K
Tuneup plus results were OK.

The computer is now optimally configured for creating mini and memory dump files.

If there are any BSOD they are less likely to be missed as automatically restart was turned off.
BSOD should now display a window with error message and : ( until there is a manual restart.



First scannow:
Code:
Windows Resource Protection found corrupt files and successfully repaired them.

Scanhealth:
Code:
Error: 0x800f0827
DISM failed. No operation was performed.
Code:
0x800f0827 CBS_E_STACK_SHUTDOWN_REQUIRED servicing stack updated, aborting

Restorehealth:
Code:
The restore operation completed successfully.

Second scannow:
Code:
Windows Resource Protection did not find any integrity violations.

Chkdsk /scan
Code:
Windows has scanned the file system and found no problems.


My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
The drive tests were OK.

There is one additional drive test (runs instantaneously) later in this thread.

When available post images or share links of Memtest86 results.


My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
Hi Memory test in this folder - they seemed ok.
I did get anther BSOD yesterday (CLOCK_WATCHDOG_TIMEOUT)



My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    CPU
    Intel(R) Xeon(R) W-11955M CPU @ 2.60GHz 2.61 GHz
    Motherboard
    LENOVO 20YUCTO1WW
    Memory
    128GB
    Graphics Card(s)
    NVIDIA RTX A2000 Laptop GPU
    Screen Resolution
    4K
When using Memtest86 please take pictures and post images or share links into this thread using one drive, drop box, or google drive.

If text / html reports are available, please include them with the images in the share links.



Please post a new V2 share link into the newest post.



Open administrative command prompt and copy and paste:

PowerShell $D=(New-Object -ComObject Wscript.Shell).SpecialFolders(4);Compress-Archive "%WinDir%\MEMORY.DMP" "$D\Memory_dmp"

Post a separate share link with only the compressed memory dump into the newest post.


My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation

My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    CPU
    Intel(R) Xeon(R) W-11955M CPU @ 2.60GHz 2.61 GHz
    Motherboard
    LENOVO 20YUCTO1WW
    Memory
    128GB
    Graphics Card(s)
    NVIDIA RTX A2000 Laptop GPU
    Screen Resolution
    4K
Hi - The MEMORY.dmp file appears to be from November 2022 - so I assume you were after a more recent one? Also its 5GB


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    CPU
    Intel(R) Xeon(R) W-11955M CPU @ 2.60GHz 2.61 GHz
    Motherboard
    LENOVO 20YUCTO1WW
    Memory
    128GB
    Graphics Card(s)
    NVIDIA RTX A2000 Laptop GPU
    Screen Resolution
    4K
The reports posted were not the typical images or reports posted into the forum.

How many RAM modules were tested simultaneously?
Where is the image of the final test result?




My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
Hi - I used the Pro Version and I think I saved all the outputs to file . I can try and run again over the weekend to see if I can get anything different out. There were more files but they appeared to be duplicated (i have uploaded those too). There are 4 modules of 32GB each.


My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    CPU
    Intel(R) Xeon(R) W-11955M CPU @ 2.60GHz 2.61 GHz
    Motherboard
    LENOVO 20YUCTO1WW
    Memory
    128GB
    Graphics Card(s)
    NVIDIA RTX A2000 Laptop GPU
    Screen Resolution
    4K
Rarely are members using the pro version.
What was the test run time for the four 32 GB RAM modules and how many passes were performed?
The report appeared to have only four passes?
Doesn't the pro version perform eight passes?

Please post a new V2 share link into the newest post.

Open the Lenovo website > enter the computers serial number > click diagnostics > custom > select each box > run overnight > take pictures displaying the test performed with results > post images or share links into this thread

Last edited:

My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation

My Computer

System One

  • OS
    Windows 11
    Computer type
    Laptop
    Manufacturer/Model
    Lenovo
    CPU
    Intel(R) Xeon(R) W-11955M CPU @ 2.60GHz 2.61 GHz
    Motherboard
    LENOVO 20YUCTO1WW
    Memory
    128GB
    Graphics Card(s)
    NVIDIA RTX A2000 Laptop GPU
    Screen Resolution
    4K
This is another thread where a Memtest86 image result was posted.
See if you can produce a similar image.


Post a new V2 share link into the newest post:


Run HD Sentinel (free or trial version) (all drives)
Post images or share links for results on these tabs:
a) Overview
b) Temperature
c) SMART

Last edited:

My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP
    CPU
    Intel(R) Core(TM) i7-4800MQ CPU @ 2.70GHz
    Motherboard
    Product : 190A Version : KBC Version 94.56
    Memory
    16 GB Total: Manufacturer : Samsung MemoryType : DDR3 FormFactor : SODIMM Capacity : 8GB Speed : 1600
    Graphics Card(s)
    NVIDIA Quadro K3100M; Intel(R) HD Graphics 4600
    Sound Card
    IDT High Definition Audio CODEC; PNP Device ID HDAUDIO\FUNC_01&VEN_111D&DEV_76E0
    Hard Drives
    Model Hitachi HTS727575A9E364
    Antivirus
    Microsoft Defender
    Other Info
    Mobile Workstation
