Devices Change Pen Double-tap Speed in Windows 11


  • Staff

You can pair a pen via Bluetooth to connect the pen with your Windows 11 PC and use with the pen menu.

You can adjust how quickly you tap the screen when you double-tab with your pen.

This tutorial will show you how to change the pen double-tap speed for your account in Windows 10 and Windows 11.


Contents

  • Option One: Change Pen Double-tap Speed in Control Panel
  • Option Two: Change Pen Double-tap Speed in Registry Editor




Option One

Change Pen Double-tap Speed in Control Panel


1 Open the Control Panel (icons view), and click/tap on the Pen and Touch icon.

2 Perform the following actions: (see screenshot below)
  1. Click/tap on the Pen Options tab.
  2. Select Double-tab.
  3. Click/tap on Settings.

3 Adjust the Speed slider left (slow) or right (fast) to the speed you want, and click/tap on OK. (see screenshot below)

You can double-tap on the door graphic under Test settings to test the current double-tap speed.



4 Click/tap on OK. (see screenshot below)


5 You can now close the Control Panel if you like.




Option Two

Change Pen Double-tap Speed in Registry Editor


1 Open Registry Editor (regedit.exe).

2 Navigate to the key below in the left pane of Registry Editor. (see screenshot below)

HKEY_CURRENT_USER\Software\Microsoft\Wisp\Pen\SysEventParameters


3 In the right pane of the SysEventParameters key, double click/tap on the DblTime DWORD value to modify it. (see screenshot above)

4 Click/tap on Decimal, type a number between 100 (fast) to 2000 (slow) for the double-tap speed you want, and click/tap on OK. (see screenshot below)

The default double-tap speed is 300.



5 Close Registry Editor when finished.

6 Either sign out and sign in or restart the computer to apply.


That's it,
Shawn Brink
