Solved How to set DNS over HTTPS via command prompt?


Genshii

Member
Local time
5:31 PM
Posts
5
OS
Windows 11
Is there a way to set DNS over HTTPS via netsh or wmic? I know you can add additional DoH templates via netsh, and I know you can set DNS, but I can't figure out if there's a way to actually set DNS + activate DoH without going into settings.

In other words, I'd like to do this via command prompt:


Thank you in advance.

Last edited:

My Computer

System One

  • OS
    Windows 11
I did it for Windows 11, but did not check. Not yet Windows 11.

# Cloudflare. +Block malware and adult content
$PrimaryDNS = '1.0.0.3'
$SecondaryDNS = '1.1.1.3'

# DNS server registration with DOH support
Add-DnsClientDohServerAddress -ServerAddress $PrimaryDNS -DohTemplate 'https://family.cloudflare-dns.com/dns-query' -AllowFallbackToUdp $False -AutoUpgrade $True
Add-DnsClientDohServerAddress -ServerAddress $SecondaryDNS -DohTemplate 'https://family.cloudflare-dns.com/dns-query' -AllowFallbackToUdp $False -AutoUpgrade $True
# All network adapters
$PhysAdapter = Get-NetAdapter -Physical
$PhysAdapter | Get-DnsClientServerAddress -AddressFamily IPv4 | Set-DnsClientServerAddress -ServerAddresses ($PrimaryDNS, $SecondaryDNS)


My Computer

System One

  • OS
    Microsoft Windows 11 Home
    Computer type
    PC/Desktop
    Manufacturer/Model
    MSI MS-7D98
    CPU
    Intel Core i5-13490F
    Motherboard
    MSI B760 GAMING PLUS WIFI
    Memory
    2 x 16 Patriot Memory (PDP Systems) PSD516G560081
    Graphics Card(s)
    GIGABYTE GeForce RTX 4070 WINDFORCE OC 12G (GV-N4070WF3OC-12GD)
    Sound Card
    Bluetooth Аудио
    Monitor(s) Displays
    INNOCN 15K1F
    Screen Resolution
    1920 x 1080
    Hard Drives
    WD_BLACK SN770 250GB
    KINGSTON SNV2S1000G (ELFK0S.6)
    PSU
    Thermaltake Toughpower GF3 1000W
    Case
    CG560 - DeepCool
    Cooling
    ID-COOLING SE-224-XTS / 2 x 140Mm Fan - rear and top; 3 x 120Mm - front
    Keyboard
    Corsair K70 RGB TKL
    Mouse
    Corsair KATAR PRO XT
    Internet Speed
    100 Mbps
    Browser
    Firefox
    Antivirus
    Microsoft Defender Antivirus
    Other Info
    https://www.userbenchmark.com/UserRun/66553205
Unfortunately that doesn't actually enable DoH. It sets the primary/secondary DNS as expected, but I still have to go into settings and manually toggle on DoH.


My Computer

System One

  • OS
    Windows 11
Does it work ?

Once you know your Windows install has our DoH client, we need to activate it. You can do that by:

Opening the Registry Editor
Navigate to the HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\Dnscache\Parameters registry key
Create a new DWORD value named “EnableAutoDoh”
Set its value to 2


My Computer

System One

  • OS
    Microsoft Windows 11 Home
    Computer type
    PC/Desktop
    Manufacturer/Model
    MSI MS-7D98
    CPU
    Intel Core i5-13490F
    Motherboard
    MSI B760 GAMING PLUS WIFI
    Memory
    2 x 16 Patriot Memory (PDP Systems) PSD516G560081
    Graphics Card(s)
    GIGABYTE GeForce RTX 4070 WINDFORCE OC 12G (GV-N4070WF3OC-12GD)
    Sound Card
    Bluetooth Аудио
    Monitor(s) Displays
    INNOCN 15K1F
    Screen Resolution
    1920 x 1080
    Hard Drives
    WD_BLACK SN770 250GB
    KINGSTON SNV2S1000G (ELFK0S.6)
    PSU
    Thermaltake Toughpower GF3 1000W
    Case
    CG560 - DeepCool
    Cooling
    ID-COOLING SE-224-XTS / 2 x 140Mm Fan - rear and top; 3 x 120Mm - front
    Keyboard
    Corsair K70 RGB TKL
    Mouse
    Corsair KATAR PRO XT
    Internet Speed
    100 Mbps
    Browser
    Firefox
    Antivirus
    Microsoft Defender Antivirus
    Other Info
    https://www.userbenchmark.com/UserRun/66553205
You need to know network adapter's ID, but that is randomly assigned, so maybe via a script? :think:

Code:
rem Allow DoH
reg add "HKLM\System\CurrentControlSet\Services\Dnscache\Parameters" /v "EnableAutoDoh" /t REG_DWORD /d "2" /f

rem Add custom DNS
netsh dns add encryption server=94.140.14.15 dohtemplate=https://dns-family.adguard.com/dns-query autoupgrade=yes udpfallback=no
netsh dns add encryption server=94.140.15.16 dohtemplate=https://dns-family.adguard.com/dns-query autoupgrade=yes udpfallback=no

rem Set DNS on DHCP or on a static IP based on MAC address
wmic nicconfig where DHCPEnabled=TRUE call SetDNSServerSearchOrder ("94.140.14.15","94.140.15.16")
wmic nicconfig where macaddress="00:D8:61:6E:E8:C5" call SetDNSServerSearchOrder ("94.140.14.15","94.140.15.16")

rem Enable DoH
reg add "HKLM\System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\{0bd56988-9769-4d69-9e1b-9c15fc223590}\DohInterfaceSettings\Doh\94.140.14.15" /v "DohFlags" /t REG_QWORD /d "1" /f
reg add "HKLM\System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\{0bd56988-9769-4d69-9e1b-9c15fc223590}\DohInterfaceSettings\Doh\94.140.15.16" /v "DohFlags" /t REG_QWORD /d "1" /f
This worked for me (bypassing UAC), when I entered mine ID.



My Computer

System One

  • OS
    Windows 11 Home
    Computer type
    PC/Desktop
    CPU
    AMD Ryzen 5 3600 & No fTPM (07/19)
    Motherboard
    MSI B450 TOMAHAWK 7C02v1E & IFX TPM (07/19)
    Memory
    4x 8GB ADATA XPG GAMMIX D10 DDR4 3200MHz CL16
    Graphics Card(s)
    MSI Radeon RX 580 ARMOR 8G OC @48FPS (08/19)
    Sound Card
    Creative Sound Blaster Z (11/16)
    Monitor(s) Displays
    24" AOC G2460VQ6 (01/19)
    Screen Resolution
    1920×1080@75Hz & FreeSync (DisplayPort)
    Hard Drives
    ADATA XPG GAMMIX S11 Pro SSD 512GB (07/19)
    PSU
    Seasonic M12II-520 80 Plus Bronze (11/16)
    Case
    Lian Li PC-7NB & 3x Noctua NF-S12A FLX@700rpm (11/16)
    Cooling
    CPU Cooler Noctua NH-U12S@700rpm (07/19)
    Keyboard
    HP Wired Desktop 320K + Rabalux 76017 Parker (01/24)
    Mouse
    Logitech M330 Silent Plus (04/23)
    Internet Speed
    400/40 Mbps via RouterOS (05/21) & TCP Optimizer
    Browser
    Edge with Brave (No FB/Google) & Brave for YouTube & LibreWolf for FB
    Antivirus
    NoAV & Binisoft WFC & NextDNS
    Other Info
    Headphones: Sennheiser RS170 (09/10)
Appreciate the help. I was able to write a batch script that automatically sets given DNS servers and enables DoH on every relevant network interface for both IPv4 and IPv6. We can get the interface IDs and indexes from wmic nic and use that to set DNS with netsh. For my use case, I just want to use the default Cloudflare DNS servers, so it assumes that your selected DNS servers already have the proper DoH templates added.

Also, I didn't end up needing to add EnableAutoDoh to registry. I don't have that key at all and DoH works fine.

Code:
@echo off

rem Set the DNS servers to be applied to each interface.
set IPv4PrimaryDNS=1.1.1.1
set IPv4SecondaryDNS=1.0.0.1
set IPv6PrimaryDNS=2606:4700:4700::1111
set IPv6SecondaryDNS=2606:4700:4700::1001

rem Checks for administrative permissions.
net.exe session 1>NUL 2>NUL || (echo This script requires administrative permissions. Please run as administrator. & pause & exit /B 1)

echo Using the following DNS servers:
echo IPv4:
echo Primary - %IPv4PrimaryDNS%
echo Secondary - %IPv4SecondaryDNS%
echo/
echo IPv6:
echo Primary - %IPv6PrimaryDNS%
echo Secondary - %IPv6SecondaryDNS%
echo/

rem Clears existing DoH settings.
reg delete "HKLM\System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters" /f 1>NUL
echo Cleared any existing DoH settings.
echo/

rem The following for loops get a given interface's InterfaceIndex and GUID. We use the InterfaceIndex to set DNS, and the GUID to set DoH in the registry.
rem We only care about network interfaces that have a GUID.
for /f %%X in ('wmic nic where "GUID!=NULL" Get InterfaceIndex /value') do (
    rem We have to use a second for loop to remove the extra carrige returns from wmic output.
    rem InterfaceIndex is stored at %%I.
    for /f "tokens=1* delims==" %%H in ("%%X") do (
        for /f %%X in ('wmic nic where "InterfaceIndex=%%I" Get GUID /value') do (
            rem GUID is stored at %%G.
            for /f "tokens=1* delims==" %%F in ("%%X") do (

                rem Prints the name of the interface being modified.
                for  /f "tokens=*" %%X in ('wmic nic where "InterfaceIndex=%%I" Get NetConnectionID /value') do (
                    for /f "tokens=1* delims==" %%B in ("%%X") do (
                        for  /f "tokens=*" %%X in ('wmic nic where "InterfaceIndex=%%I" Get Name /value') do (
                            for /f "tokens=1* delims==" %%M in ("%%X") do echo %%C ^(%%N^):
                        )
                    )
                )
                echo/

                rem Clears existing DNS servers.
                netsh interface ipv4 set dnsservers %%I dhcp 1>NUL
                echo Cleared any existing IPv4 DNS servers.
                netsh interface ipv6 set dnsservers %%I dhcp 1>NUL
                echo Cleared any existing IPv6 DNS servers.
                echo/

                netsh interface ipv4 set dnsservers %%I static %IPv4PrimaryDNS% primary no 1>NUL
                echo Set primary IPv4 DNS server to: %IPv4PrimaryDNS%
                netsh interface ipv4 add dnsservers %%I %IPv4SecondaryDNS% index=2 no 1>NUL
                echo Set secondary IPv4 DNS server to: %IPv4SecondaryDNS%
                echo/

                netsh interface ipv6 set dnsservers %%I static %IPv6PrimaryDNS% primary no 1>NUL
                echo Set primary IPv6 DNS server to: %IPv6PrimaryDNS%
                netsh interface ipv6 add dnsservers %%I %IPv6SecondaryDNS% index=2 no 1>NUL
                echo Set secondary IPv6 DNS server to: %IPv6SecondaryDNS%
                echo/

                reg add "HKLM\System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\%%G\DohInterfaceSettings\Doh\%IPv4PrimaryDNS%" /v "DohFlags" /t REG_QWORD /d "1" /f 1>NUL
                reg add "HKLM\System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\%%G\DohInterfaceSettings\Doh\%IPv4SecondaryDNS%" /v "DohFlags" /t REG_QWORD /d "1" /f 1>NUL
                echo Enabled DoH for IPv4.

                reg add "HKLM\System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\%%G\DohInterfaceSettings\Doh6\%IPv6PrimaryDNS%" /v "DohFlags" /t REG_QWORD /d "1" /f 1>NUL
                reg add "HKLM\System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\%%G\DohInterfaceSettings\Doh6\%IPv6SecondaryDNS%" /v "DohFlags" /t REG_QWORD /d "1" /f 1>NUL
                echo Enabled DoH for IPv6.
                echo/
            )

        )
    )
)

ipconfig /flushdns 1>NUL
echo Flushed DNS.
echo/

pause

Last edited:

My Computer

System One

  • OS
    Windows 11
tomatically sets given DNS servers and enables DoH on every relevant network interface for both IPv4 and IPv6. We can get the interface IDs and indexes from wmic nic and use that to set DNS with netsh. For my use case, I just want to use the default Cloudflar

Hi there, I came across your useful script and wanted to ask - is this automatically applied to all network interfaces (Ethernet, WiFi networks) that I have without having to specify the network name if I'm just using cloudflare DNS?


My Computer

System One

  • OS
    Win 11
    Computer type
    PC/Desktop
    CPU
    Ryzen 3600
    Motherboard
    MSI B450 Tomahawk Max
    Memory
    GSkill RipJawz 16Gbx2
    Graphics Card(s)
    GTX960
    Screen Resolution
    2560x1440
    Hard Drives
    WD750 SSD 1TB
    PSU
    650w FSP
Hi there, I came across your useful script and wanted to ask - is this automatically applied to all network interfaces (Ethernet, WiFi networks) that I have without having to specify the network name if I'm just using cloudflare DNS?

Yeah, it's applied to all network interfaces regardless of the actual network you're connecting to.


My Computer

System One

  • OS
    Windows 11
Hello, using the script i have a problem, the DNS settings of my Bluetooth connection are changed.

I have converted it to powershell, that allow me to filter only Wireless and Wired networks adapters.


Powershell:
$i = Get-NetAdapter -Physical
$i | Get-DnsClientServerAddress -AddressFamily IPv4 | Set-DnsClientServerAddress -ServerAddresses '1.1.1.1', '8.8.8.8'
$i | Get-DnsClientServerAddress -AddressFamily IPv6 | Set-DnsClientServerAddress -ServerAddresses '2606:4700:4700::1111', '2001:4860:4860::8888'
$i | ForEach-Object {
$s1 = 'HKLM:System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\' + $_.InterfaceGuid + '\DohInterfaceSettings\Doh\1.1.1.1'; New-Item -Path $s1 -Force | New-ItemProperty -Name "DohFlags" -Value 1 -PropertyType Qword
$s2 = 'HKLM:System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\' + $_.InterfaceGuid + '\DohInterfaceSettings\Doh\8.8.8.8'; New-Item -Path $s2 -Force  | New-ItemProperty -Name "DohFlags" -Value 1 -PropertyType Qword
$s3 = 'HKLM:System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\' + $_.InterfaceGuid + '\DohInterfaceSettings\Doh6\2606:4700:4700::1111'; New-Item -Path $s3 -Force | New-ItemProperty -Name "DohFlags" -Value 1 -PropertyType Qword
$s4 = 'HKLM:System\CurrentControlSet\Services\Dnscache\InterfaceSpecificParameters\' + $_.InterfaceGuid + '\DohInterfaceSettings\Doh6\2001:4860:4860::8888'; New-Item -Path $s4 -Force  | New-ItemProperty -Name "DohFlags" -Value 1 -PropertyType Qword
}
Clear-DnsClientCache;


My Computer

System One

  • OS
    WIndows 11
