Solved Severe Windows 11 Corruption on ASUS Vivobook K513EQ: In-Place Upgrade Fails, and Storage Invisible

C:\Users\User>diskpart

Microsoft DiskPart version 10.0.26100.1150

Copyright (C) Microsoft Corporation.
On computer: ASUS

DISKPART> sel dis 0

Disk 0 is now the selected disk.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> del par override

DiskPart successfully deleted the selected partition.

DISKPART> cre par pri size=1500

DiskPart succeeded in creating the specified partition.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> for fs=ntfs quick label=Recovery

    0 percent completed

DiskPart has encountered an error: The parameter is incorrect.
See the System Event Log for more information.

DISKPART> assign letter=R

DiskPart successfully assigned the drive letter or mount point.

DISKPART> exit

Leaving DiskPart...

diskpart
sel dis 0
sel par 4
del par override
cre par pri size=1500
sel par 4
set id=ebd0a0a2-b9e5-4433-87c0-68b6b72699c7
assign letter=R
exit

format R: /fs:ntfs /q /v:Recovery

C:\Users\User>diskpart

Microsoft DiskPart version 10.0.26100.1150

Copyright (C) Microsoft Corporation.
On computer: ASUS

DISKPART> sel dis 0

Disk 0 is now the selected disk.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> del par override

DiskPart successfully deleted the selected partition.

DISKPART> cre par pri size=1500

DiskPart succeeded in creating the specified partition.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> set id=ebd0a0a2-b9e5-4433-87c0-68b6b72699c7

DiskPart successfully set the partition ID.

DISKPART> assign letter=R

DiskPart successfully assigned the drive letter or mount point.

DISKPART> exit

Leaving DiskPart...

C:\Users\User>format R: /fs:ntfs /q /v:Recovery
The type of the file system is RAW.
The new file system is NTFS.

WARNING, ALL DATA ON NON-REMOVABLE DISK
DRIVE R: WILL BE LOST!
Proceed with Format (Y/N)? Y
QuickFormatting 1,5 GB
Creating file system structures.
Format complete.
       1,5 GB total disk space.
       1,5 GB are available.

diskpart
sel dis 0
sel par 4
set id=de94bba4-06d1-4d40-a16a-bfd50179d6ac
gpt attributes=0x8000000000000001
exit

C:\Users\User>diskpart

Microsoft DiskPart version 10.0.26100.1150

Copyright (C) Microsoft Corporation.
On computer: ASUS

DISKPART> sel dis 0

Disk 0 is now the selected disk.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> set id=de94bba4-06d1-4d40-a16a-bfd50179d6ac

DiskPart successfully set the partition ID.

DISKPART> gpt attributes=0x8000000000000001

DiskPart successfully assigned the attributes to the selected GPT partition.

DISKPART> exit

Leaving DiskPart...

reagentc /disable
dir R:
mkdir R:\Recovery\WindowsRE
robocopy C:\Recovery\WindowsRE R:\Recovery\WindowsRE Winre.wim boot.sdi ReAgent.xml
reagentc /disable
reagentc /setreimage /path R:\Recovery\WindowsRE
reagentc /enable
reagentc /info

C:\Users\User>reagentc /disable
REAGENTC.EXE: Windows RE is already disabled.


C:\Users\User>dir R:
 Volume in drive R is Recovery
 Volume Serial Number is 4E25-DF96

 Directory of R:\

File Not Found

C:\Users\User>mkdir R:\Recovery\WindowsRE

C:\Users\User>robocopy C:\Recovery\WindowsRE R:\Recovery\WindowsRE Winre.wim boot.sdi ReAgent.xml

-------------------------------------------------------------------------------
   ROBOCOPY     ::     Robust File Copy for Windows
-------------------------------------------------------------------------------

  Started : 16 липня 2026 р. 19:43:03
   Source : C:\Recovery\WindowsRE\
     Dest : R:\Recovery\WindowsRE\

    Files : Winre.wim
            boot.sdi
            ReAgent.xml

  Options : /DCOPY:DA /COPY:DAT /R:1000000 /W:30

------------------------------------------------------------------------------

                           0    C:\Recovery\WindowsRE\

------------------------------------------------------------------------------

               Total    Copied   Skipped  Mismatch    FAILED    Extras
    Dirs :         1         0         1         0         0         0
   Files :         0         0         0         0         0         0
   Bytes :         0         0         0         0         0         0
   Times :   0:00:00   0:00:00                       0:00:00   0:00:00
   Ended : 16 липня 2026 р. 19:43:03


C:\Users\User>reagentc /disable
REAGENTC.EXE: Windows RE is already disabled.


C:\Users\User>reagentc /setreimage /path R:\Recovery\WindowsRE
REAGENTC.EXE: No valid image found in the specified path.


C:\Users\User>reagentc /enable
REAGENTC.EXE: The Windows RE image was not found.


C:\Users\User>reagentc /info
Windows Recovery Environment (Windows RE) and system reset configuration
Information:

    Windows RE status:         Disabled
    Windows RE location:
    Boot Configuration Data (BCD) identifier: 00000000-0000-0000-0000-000000000000
    Recovery image location:
    Recovery image index:      0
    Custom image location:
    Custom image index:        0
    Windows RE Version:        0.0.0.0

REAGENTC.EXE: Operation Successful.

dir C:\Recovery\WindowsRE /a
dir C:\Recovery /s /a

C:\Users\User>dir C:\Recovery\WindowsRE /a
 Volume in drive C is Windows
 Volume Serial Number is 18E5-DE43

 Directory of C:\Recovery\WindowsRE

16.07.2026  18:17    <DIR>          .
16.07.2026  17:52    <DIR>          ..
               0 File(s)              0 bytes
               2 Dir(s)  30 464 483 328 bytes free

C:\Users\User>dir C:\Recovery /s /a
 Volume in drive C is Windows
 Volume Serial Number is 18E5-DE43

 Directory of C:\Recovery

16.07.2026  17:52    <DIR>          .
16.07.2026  13:05    <DIR>          ..
15.07.2026  13:54    <DIR>          Logs
05.10.2022  18:00    <DIR>          OEM
16.07.2026  11:58             1 040 ReAgentOld.xml
16.07.2026  18:17    <DIR>          WindowsRE
               1 File(s)          1 040 bytes

 Directory of C:\Recovery\Logs

15.07.2026  13:54    <DIR>          .
16.07.2026  17:52    <DIR>          ..
               0 File(s)              0 bytes

 Directory of C:\Recovery\OEM

05.10.2022  18:00    <DIR>          .
16.07.2026  17:52    <DIR>          ..
               0 File(s)              0 bytes

 Directory of C:\Recovery\WindowsRE

16.07.2026  18:17    <DIR>          .
16.07.2026  17:52    <DIR>          ..
               0 File(s)              0 bytes

     Total Files Listed:
               1 File(s)          1 040 bytes
              11 Dir(s)  30 464 483 328 bytes free

dir C:\ /s /a Winre.wim

    Disk 0 : SSD. It has 5 partition(s). Model: NVMe WDC PC SN530 SDBPNPZ-256G-1002

    The script has found the above 1 storage device(s) in total.
=======================================================================

Microsoft DiskPart version 10.0.26100.1150

Copyright (C) Microsoft Corporation.
On computer: ASUS

  Disk ###  Status         Size     Free     Dyn  Gpt
  --------  -------------  -------  -------  ---  ---
  Disk 0    Online          238 GB   124 MB        *

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
  Volume 0     C   Windows      NTFS   Partition     98 GB  Healthy    Boot
  Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile
  Volume 2                      FAT32  Partition    100 MB  Healthy    System
  Volume 3     R   Recovery     NTFS   Partition   1500 MB  Healthy    Hidden

Disk 0 is now the selected disk.

NVMe WDC PC SN530 SDBPNPZ-256G-1002
Disk ID: {16BD3E62-96B8-45CE-9B7E-6438808227E2}
Type   : RAID
Status : Online
Path   : 3
Target : 0
LUN ID : 0
Location Path : PCIROOT(0)#PCI(0E00)#RAID(P03T00L00)
Current Read-only State : No
Read-only  : No
Boot Disk  : Yes
Pagefile Disk  : Yes
Hibernation File Disk  : No
Crashdump Disk  : Yes
Clustered Disk  : No

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
  Volume 0     C   Windows      NTFS   Partition     98 GB  Healthy    Boot
  Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile
  Volume 2                      FAT32  Partition    100 MB  Healthy    System
  Volume 3     R   Recovery     NTFS   Partition   1500 MB  Healthy    Hidden

  Partition ###  Type              Size     Offset
  -------------  ----------------  -------  -------
  Partition 1    System             100 MB  1024 KB
  Partition 2    Reserved            16 MB   101 MB
  Partition 3    Primary             98 GB   117 MB
  Partition 4    Recovery          1500 MB    99 GB
  Partition 5    Primary            137 GB   100 GB

Partition 1 is now the selected partition.

Partition 1
Type    : c12a7328-f81f-11d2-ba4b-00a0c93ec93b
Hidden  : Yes
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 1048576

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 2                      FAT32  Partition    100 MB  Healthy    System

Partition 2 is now the selected partition.

Partition 2
Type    : e3c9e316-0b5c-4db8-817d-f92df00215ae
Hidden  : Yes
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 105906176

There is no volume associated with this partition.

Partition 3 is now the selected partition.

Partition 3
Type    : ebd0a0a2-b9e5-4433-87c0-68b6b72699c7
Hidden  : No
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 122683392

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 0     C   Windows      NTFS   Partition     98 GB  Healthy    Boot

Partition 4 is now the selected partition.

Partition 4
Type    : de94bba4-06d1-4d40-a16a-bfd50179d6ac
Hidden  : Yes
Required: Yes
Attrib  : 0X8000000000000001
Offset in Bytes: 106301489152

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 3     R   Recovery     NTFS   Partition   1500 MB  Healthy    Hidden

Partition 5 is now the selected partition.

Partition 5
Type    : ebd0a0a2-b9e5-4433-87c0-68b6b72699c7
Hidden  : No
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 108004376576

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile

===============================================================================

Windows Recovery Environment (Windows RE) and system reset configuration
Information:

    Windows RE status:         Disabled
    Windows RE location:
    Boot Configuration Data (BCD) identifier: 00000000-0000-0000-0000-000000000000
    Recovery image location:
    Recovery image index:      0
    Custom image location:
    Custom image index:        0
    Windows RE Version:        0.0.0.0

REAGENTC.EXE: Operation Successful.

===============================================================================

Firmware Boot Manager
---------------------
identifier              {fwbootmgr}
displayorder            {bootmgr}
timeout                 1

Windows Boot Manager
--------------------
identifier              {bootmgr}
device                  partition=\Device\HarddiskVolume1
path                    \EFI\Microsoft\Boot\bootmgfw.efi
description             Windows Boot Manager
locale                  ru-RU
inherit                 {globalsettings}
default                 {current}
resumeobject            {a59f096c-7e91-11f1-92fc-38fc98805952}
displayorder            {current}
toolsdisplayorder       {memdiag}
timeout                 5

Windows Boot Loader
-------------------
identifier              {23fff7ec-ed80-11ec-883d-c6208a87c835}
device                  ramdisk=[unknown]\Recovery\WindowsRE\Winre.wim,{23fff7ed-ed80-11ec-883d-c6208a87c835}
path                    \windows\system32\winload.efi
description             Windows Recovery Environment
locale                  ru-RU
inherit                 {bootloadersettings}
displaymessage          Recovery
osdevice                ramdisk=[unknown]\Recovery\WindowsRE\Winre.wim,{23fff7ed-ed80-11ec-883d-c6208a87c835}
systemroot              \windows
nx                      OptIn
bootmenupolicy          Standard
winpe                   Yes

Windows Boot Loader
-------------------
identifier              {current}
device                  partition=C:
path                    \WINDOWS\system32\winload.efi
description             Windows 11
locale                  ru-RU
inherit                 {bootloadersettings}
displaymessageoverride  Recovery
recoveryenabled         No
isolatedcontext         Yes
allowedinmemorysettings 0x15000075
osdevice                partition=C:
systemroot              \WINDOWS
resumeobject            {a59f096c-7e91-11f1-92fc-38fc98805952}
nx                      OptIn
bootmenupolicy          Standard
hypervisorlaunchtype    Auto

Resume from Hibernate
---------------------
identifier              {a59f096c-7e91-11f1-92fc-38fc98805952}
device                  partition=C:
path                    \WINDOWS\system32\winresume.efi
description             Windows Resume Application
locale                  ru-RU
inherit                 {resumeloadersettings}
recoveryenabled         No
isolatedcontext         Yes
allowedinmemorysettings 0x15000075
filedevice              partition=C:
custom:21000026         partition=C:
filepath                \hiberfil.sys
bootmenupolicy          Standard
debugoptionenabled      No

Resume from Hibernate
---------------------
identifier              {e50f941c-95c9-11ef-bfe0-a3425c97b477}
device                  partition=C:
path                    \$WINDOWS.~BT\NewOS\WINDOWS\system32\winresume.efi
description             Windows Resume Application
locale                  ru-RU
inherit                 {resumeloadersettings}
isolatedcontext         Yes
allowedinmemorysettings 0x15000075
filepath                \hiberfil.sys
bootmenupolicy          Standard

Windows Memory Tester
---------------------
identifier              {memdiag}
device                  partition=\Device\HarddiskVolume1
path                    \EFI\Microsoft\Boot\memtest.efi
description                    ⨪
locale                  ru-RU
inherit                 {globalsettings}
badmemoryaccess         Yes

EMS Settings
------------
identifier              {emssettings}
bootems                 No

Debugger Settings
-----------------
identifier              {dbgsettings}
debugtype               Local

RAM Defects
-----------
identifier              {badmemory}

Global Settings
---------------
identifier              {globalsettings}
inherit                 {dbgsettings}
                        {emssettings}
                        {badmemory}

Boot Loader Settings
--------------------
identifier              {bootloadersettings}
inherit                 {globalsettings}
                        {hypervisorsettings}

Hypervisor Settings
-------------------
identifier              {hypervisorsettings}
hypervisordebugtype     Serial
hypervisordebugport     1
hypervisorbaudrate      115200

Resume Loader Settings
----------------------
identifier              {resumeloadersettings}
inherit                 {globalsettings}

diskpart
sel dis 0
sel par 4
del par override
cre par pri size=1500
sel par 4
format fs=ntfs quick label=Recovery
set id=de94bba4-06d1-4d40-a16a-bfd50179d6ac
gpt attributes=0x8000000000000001
lis vol
lis par
exit

C:\Users\User>diskpart

Microsoft DiskPart version 10.0.26100.1150

Copyright (C) Microsoft Corporation.
On computer: ASUS

DISKPART> sel dis 0

Disk 0 is now the selected disk.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> del par override

DiskPart successfully deleted the selected partition.

DISKPART> cre par pri size=1500

DiskPart succeeded in creating the specified partition.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> format fs=ntfs quick label=Recovery

    0 percent completed

DiskPart has encountered an error: The parameter is incorrect.
See the System Event Log for more information.

DISKPART> set id=de94bba4-06d1-4d40-a16a-bfd50179d6ac

DiskPart successfully set the partition ID.

DISKPART> gpt attributes=0x8000000000000001

DiskPart successfully assigned the attributes to the selected GPT partition.

DISKPART> lis vol

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
  Volume 0     C   Windows      NTFS   Partition     98 GB  Healthy    Boot
  Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile
  Volume 2                      FAT32  Partition    100 MB  Healthy    System
* Volume 3                      RAW    Partition   1500 MB  Healthy    Hidden

DISKPART> lis par

  Partition ###  Type              Size     Offset
  -------------  ----------------  -------  -------
  Partition 1    System             100 MB  1024 KB
  Partition 2    Reserved            16 MB   101 MB
  Partition 3    Primary             98 GB   117 MB
* Partition 4    Recovery          1500 MB    99 GB
  Partition 5    Primary            137 GB   100 GB

DISKPART> exit

Leaving DiskPart...

diskpart
sel dis 0
sel par 4
del par override
cre par pri size=1500
sel par 4
set id=ebd0a0a2-b9e5-4433-87c0-68b6b72699c7
assign letter=R
exit


format R: /fs:ntfs /q /v:Recovery


diskpart
sel dis 0
sel par 4
set id=de94bba4-06d1-4d40-a16a-bfd50179d6ac
gpt attributes=0x8000000000000001
remove letter=R
lis par
lis vol
exit

C:\Users\User>diskpart

Microsoft DiskPart version 10.0.26100.1150

Copyright (C) Microsoft Corporation.
On computer: ASUS

DISKPART> sel dis 0

Disk 0 is now the selected disk.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> del par override

DiskPart successfully deleted the selected partition.

DISKPART> cre par pri size=1500

DiskPart succeeded in creating the specified partition.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> set id=ebd0a0a2-b9e5-4433-87c0-68b6b72699c7

DiskPart successfully set the partition ID.

DISKPART> assign letter=R

DiskPart successfully assigned the drive letter or mount point.

DISKPART> exit

Leaving DiskPart...

C:\Users\User>
C:\Users\User>
C:\Users\User>format R: /fs:ntfs /q /v:Recovery
The type of the file system is NTFS.

WARNING, ALL DATA ON NON-REMOVABLE DISK
DRIVE R: WILL BE LOST!
Proceed with Format (Y/N)? y
QuickFormatting 1,5 GB
Creating file system structures.
Format complete.
       1,5 GB total disk space.
       1,5 GB are available.

C:\Users\User>diskpart

Microsoft DiskPart version 10.0.26100.1150

Copyright (C) Microsoft Corporation.
On computer: ASUS

DISKPART> sel dis 0

Disk 0 is now the selected disk.

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> set id=de94bba4-06d1-4d40-a16a-bfd50179d6ac

DiskPart successfully set the partition ID.

DISKPART> gpt attributes=0x8000000000000001

DiskPart successfully assigned the attributes to the selected GPT partition.

DISKPART> remove letter=R

DiskPart successfully removed the drive letter or mount point.

DISKPART> lis par

  Partition ###  Type              Size     Offset
  -------------  ----------------  -------  -------
  Partition 1    System             100 MB  1024 KB
  Partition 2    Reserved            16 MB   101 MB
  Partition 3    Primary             98 GB   117 MB
* Partition 4    Recovery          1500 MB    99 GB
  Partition 5    Primary            137 GB   100 GB

DISKPART> lis vol

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
  Volume 0     C   Windows      NTFS   Partition     98 GB  Healthy    Boot
* Volume 1         Recovery     NTFS   Partition   1500 MB  Healthy    Hidden
  Volume 2     D                NTFS   Partition    137 GB  Healthy    Pagefile
  Volume 3                      FAT32  Partition    100 MB  Healthy    System

DISKPART> exit

Leaving DiskPart...

    Disk 0 : SSD. It has 5 partition(s). Model: NVMe WDC PC SN530 SDBPNPZ-256G-1002

    The script has found the above 1 storage device(s) in total.
=======================================================================

Microsoft DiskPart version 10.0.26100.1150

Copyright (C) Microsoft Corporation.
On computer: ASUS

  Disk ###  Status         Size     Free     Dyn  Gpt
  --------  -------------  -------  -------  ---  ---
  Disk 0    Online          238 GB   124 MB        *

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
  Volume 0     C   Windows      NTFS   Partition     98 GB  Healthy    Boot
  Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile
  Volume 2                      FAT32  Partition    100 MB  Healthy    System
  Volume 3         Recovery     NTFS   Partition   1500 MB  Healthy    Hidden

Disk 0 is now the selected disk.

NVMe WDC PC SN530 SDBPNPZ-256G-1002
Disk ID: {16BD3E62-96B8-45CE-9B7E-6438808227E2}
Type   : RAID
Status : Online
Path   : 3
Target : 0
LUN ID : 0
Location Path : PCIROOT(0)#PCI(0E00)#RAID(P03T00L00)
Current Read-only State : No
Read-only  : No
Boot Disk  : Yes
Pagefile Disk  : Yes
Hibernation File Disk  : No
Crashdump Disk  : Yes
Clustered Disk  : No

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
  Volume 0     C   Windows      NTFS   Partition     98 GB  Healthy    Boot
  Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile
  Volume 2                      FAT32  Partition    100 MB  Healthy    System
  Volume 3         Recovery     NTFS   Partition   1500 MB  Healthy    Hidden

  Partition ###  Type              Size     Offset
  -------------  ----------------  -------  -------
  Partition 1    System             100 MB  1024 KB
  Partition 2    Reserved            16 MB   101 MB
  Partition 3    Primary             98 GB   117 MB
  Partition 4    Recovery          1500 MB    99 GB
  Partition 5    Primary            137 GB   100 GB

Partition 1 is now the selected partition.

Partition 1
Type    : c12a7328-f81f-11d2-ba4b-00a0c93ec93b
Hidden  : Yes
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 1048576

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 2                      FAT32  Partition    100 MB  Healthy    System

Partition 2 is now the selected partition.

Partition 2
Type    : e3c9e316-0b5c-4db8-817d-f92df00215ae
Hidden  : Yes
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 105906176

There is no volume associated with this partition.

Partition 3 is now the selected partition.

Partition 3
Type    : ebd0a0a2-b9e5-4433-87c0-68b6b72699c7
Hidden  : No
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 122683392

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 0     C   Windows      NTFS   Partition     98 GB  Healthy    Boot

Partition 4 is now the selected partition.

Partition 4
Type    : de94bba4-06d1-4d40-a16a-bfd50179d6ac
Hidden  : Yes
Required: Yes
Attrib  : 0X8000000000000001
Offset in Bytes: 106301489152

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 3         Recovery     NTFS   Partition   1500 MB  Healthy    Hidden

Partition 5 is now the selected partition.

Partition 5
Type    : ebd0a0a2-b9e5-4433-87c0-68b6b72699c7
Hidden  : No
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 108004376576

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile

===============================================================================

Windows Recovery Environment (Windows RE) and system reset configuration
Information:

    Windows RE status:         Disabled
    Windows RE location:
    Boot Configuration Data (BCD) identifier: 00000000-0000-0000-0000-000000000000
    Recovery image location:
    Recovery image index:      0
    Custom image location:
    Custom image index:        0
    Windows RE Version:        0.0.0.0

REAGENTC.EXE: Operation Successful.

===============================================================================

Firmware Boot Manager
---------------------
identifier              {fwbootmgr}
displayorder            {bootmgr}
timeout                 1

Windows Boot Manager
--------------------
identifier              {bootmgr}
device                  partition=\Device\HarddiskVolume1
path                    \EFI\Microsoft\Boot\bootmgfw.efi
description             Windows Boot Manager
locale                  ru-RU
inherit                 {globalsettings}
default                 {current}
resumeobject            {a59f096c-7e91-11f1-92fc-38fc98805952}
displayorder            {current}
toolsdisplayorder       {memdiag}
timeout                 5

Windows Boot Loader
-------------------
identifier              {23fff7ec-ed80-11ec-883d-c6208a87c835}
device                  ramdisk=[unknown]\Recovery\WindowsRE\Winre.wim,{23fff7ed-ed80-11ec-883d-c6208a87c835}
path                    \windows\system32\winload.efi
description             Windows Recovery Environment
locale                  ru-RU
inherit                 {bootloadersettings}
displaymessage          Recovery
osdevice                ramdisk=[unknown]\Recovery\WindowsRE\Winre.wim,{23fff7ed-ed80-11ec-883d-c6208a87c835}
systemroot              \windows
nx                      OptIn
bootmenupolicy          Standard
winpe                   Yes

Windows Boot Loader
-------------------
identifier              {current}
device                  partition=C:
path                    \WINDOWS\system32\winload.efi
description             Windows 11
locale                  ru-RU
inherit                 {bootloadersettings}
displaymessageoverride  Recovery
recoveryenabled         No
isolatedcontext         Yes
allowedinmemorysettings 0x15000075
osdevice                partition=C:
systemroot              \WINDOWS
resumeobject            {a59f096c-7e91-11f1-92fc-38fc98805952}
nx                      OptIn
bootmenupolicy          Standard
hypervisorlaunchtype    Auto

Resume from Hibernate
---------------------
identifier              {a59f096c-7e91-11f1-92fc-38fc98805952}
device                  partition=C:
path                    \WINDOWS\system32\winresume.efi
description             Windows Resume Application
locale                  ru-RU
inherit                 {resumeloadersettings}
recoveryenabled         No
isolatedcontext         Yes
allowedinmemorysettings 0x15000075
filedevice              partition=C:
custom:21000026         partition=C:
filepath                \hiberfil.sys
bootmenupolicy          Standard
debugoptionenabled      No

Resume from Hibernate
---------------------
identifier              {e50f941c-95c9-11ef-bfe0-a3425c97b477}
device                  partition=C:
path                    \$WINDOWS.~BT\NewOS\WINDOWS\system32\winresume.efi
description             Windows Resume Application
locale                  ru-RU
inherit                 {resumeloadersettings}
isolatedcontext         Yes
allowedinmemorysettings 0x15000075
filepath                \hiberfil.sys
bootmenupolicy          Standard

Windows Memory Tester
---------------------
identifier              {memdiag}
device                  partition=\Device\HarddiskVolume1
path                    \EFI\Microsoft\Boot\memtest.efi
description                    ⨪
locale                  ru-RU
inherit                 {globalsettings}
badmemoryaccess         Yes

EMS Settings
------------
identifier              {emssettings}
bootems                 No

Debugger Settings
-----------------
identifier              {dbgsettings}
debugtype               Local

RAM Defects
-----------
identifier              {badmemory}

Global Settings
---------------
identifier              {globalsettings}
inherit                 {dbgsettings}
                        {emssettings}
                        {badmemory}

Boot Loader Settings
--------------------
identifier              {bootloadersettings}
inherit                 {globalsettings}
                        {hypervisorsettings}

Hypervisor Settings
-------------------
identifier              {hypervisorsettings}
hypervisordebugtype     Serial
hypervisordebugport     1
hypervisorbaudrate      115200

Resume Loader Settings
----------------------
identifier              {resumeloadersettings}
inherit                 {globalsettings}

DISKPART> sel par 4

Partition 4 is now the selected partition.

DISKPART> del par override

DiskPart successfully deleted the selected partition.

DISKPART> sel par 3

Partition 3 is now the selected partition.

DISKPART> extend

DiskPart successfully extended the volume.

    Disk 0 : SSD. It has 4 partition(s). Model: NVMe WDC PC SN530 SDBPNPZ-256G-1002

    The script has found the above 1 storage device(s) in total.
=======================================================================

Microsoft DiskPart version 10.0.26100.1150

Copyright (C) Microsoft Corporation.
On computer: ASUS

  Disk ###  Status         Size     Free     Dyn  Gpt
  --------  -------------  -------  -------  ---  ---
  Disk 0    Online          238 GB      0 B        *

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
  Volume 0     C   Windows      NTFS   Partition    100 GB  Healthy    Boot
  Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile
  Volume 2                      FAT32  Partition    100 MB  Healthy    System

Disk 0 is now the selected disk.

NVMe WDC PC SN530 SDBPNPZ-256G-1002
Disk ID: {16BD3E62-96B8-45CE-9B7E-6438808227E2}
Type   : RAID
Status : Online
Path   : 3
Target : 0
LUN ID : 0
Location Path : PCIROOT(0)#PCI(0E00)#RAID(P03T00L00)
Current Read-only State : No
Read-only  : No
Boot Disk  : Yes
Pagefile Disk  : Yes
Hibernation File Disk  : No
Crashdump Disk  : Yes
Clustered Disk  : No

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
  Volume 0     C   Windows      NTFS   Partition    100 GB  Healthy    Boot
  Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile
  Volume 2                      FAT32  Partition    100 MB  Healthy    System

  Partition ###  Type              Size     Offset
  -------------  ----------------  -------  -------
  Partition 1    System             100 MB  1024 KB
  Partition 2    Reserved            16 MB   101 MB
  Partition 3    Primary            100 GB   117 MB
  Partition 5    Primary            137 GB   100 GB

Partition 1 is now the selected partition.

Partition 1
Type    : c12a7328-f81f-11d2-ba4b-00a0c93ec93b
Hidden  : Yes
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 1048576

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 2                      FAT32  Partition    100 MB  Healthy    System

Partition 2 is now the selected partition.

Partition 2
Type    : e3c9e316-0b5c-4db8-817d-f92df00215ae
Hidden  : Yes
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 105906176

There is no volume associated with this partition.

Partition 3 is now the selected partition.

Partition 3
Type    : ebd0a0a2-b9e5-4433-87c0-68b6b72699c7
Hidden  : No
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 122683392

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 0     C   Windows      NTFS   Partition    100 GB  Healthy    Boot

Partition 5 is now the selected partition.

Partition 5
Type    : ebd0a0a2-b9e5-4433-87c0-68b6b72699c7
Hidden  : No
Required: No
Attrib  : 0X8000000000000000
Offset in Bytes: 108004376576

  Volume ###  Ltr  Label        Fs     Type        Size     Status     Info
  ----------  ---  -----------  -----  ----------  -------  ---------  --------
* Volume 1     D                NTFS   Partition    137 GB  Healthy    Pagefile

===============================================================================

Windows Recovery Environment (Windows RE) and system reset configuration
Information:

    Windows RE status:         Disabled
    Windows RE location:
    Boot Configuration Data (BCD) identifier: 00000000-0000-0000-0000-000000000000
    Recovery image location:
    Recovery image index:      0
    Custom image location:
    Custom image index:        0
    Windows RE Version:        0.0.0.0

REAGENTC.EXE: Operation Successful.

===============================================================================

Firmware Boot Manager
---------------------
identifier              {fwbootmgr}
displayorder            {bootmgr}
timeout                 1

Windows Boot Manager
--------------------
identifier              {bootmgr}
device                  partition=\Device\HarddiskVolume1
path                    \EFI\Microsoft\Boot\bootmgfw.efi
description             Windows Boot Manager
locale                  ru-RU
inherit                 {globalsettings}
default                 {current}
resumeobject            {a59f096c-7e91-11f1-92fc-38fc98805952}
displayorder            {current}
toolsdisplayorder       {memdiag}
timeout                 5

Windows Boot Loader
-------------------
identifier              {23fff7ec-ed80-11ec-883d-c6208a87c835}
device                  ramdisk=[unknown]\Recovery\WindowsRE\Winre.wim,{23fff7ed-ed80-11ec-883d-c6208a87c835}
path                    \windows\system32\winload.efi
description             Windows Recovery Environment
locale                  ru-RU
inherit                 {bootloadersettings}
displaymessage          Recovery
osdevice                ramdisk=[unknown]\Recovery\WindowsRE\Winre.wim,{23fff7ed-ed80-11ec-883d-c6208a87c835}
systemroot              \windows
nx                      OptIn
bootmenupolicy          Standard
winpe                   Yes

Windows Boot Loader
-------------------
identifier              {current}
device                  partition=C:
path                    \WINDOWS\system32\winload.efi
description             Windows 11
locale                  ru-RU
inherit                 {bootloadersettings}
displaymessageoverride  Recovery
recoveryenabled         No
isolatedcontext         Yes
allowedinmemorysettings 0x15000075
osdevice                partition=C:
systemroot              \WINDOWS
resumeobject            {a59f096c-7e91-11f1-92fc-38fc98805952}
nx                      OptIn
bootmenupolicy          Standard
hypervisorlaunchtype    Auto

Resume from Hibernate
---------------------
identifier              {a59f096c-7e91-11f1-92fc-38fc98805952}
device                  partition=C:
path                    \WINDOWS\system32\winresume.efi
description             Windows Resume Application
locale                  ru-RU
inherit                 {resumeloadersettings}
recoveryenabled         No
isolatedcontext         Yes
allowedinmemorysettings 0x15000075
filedevice              partition=C:
custom:21000026         partition=C:
filepath                \hiberfil.sys
bootmenupolicy          Standard
debugoptionenabled      No

Resume from Hibernate
---------------------
identifier              {e50f941c-95c9-11ef-bfe0-a3425c97b477}
device                  partition=C:
path                    \$WINDOWS.~BT\NewOS\WINDOWS\system32\winresume.efi
description             Windows Resume Application
locale                  ru-RU
inherit                 {resumeloadersettings}
isolatedcontext         Yes
allowedinmemorysettings 0x15000075
filepath                \hiberfil.sys
bootmenupolicy          Standard

Windows Memory Tester
---------------------
identifier              {memdiag}
device                  partition=\Device\HarddiskVolume1
path                    \EFI\Microsoft\Boot\memtest.efi
description                    ⨪
locale                  ru-RU
inherit                 {globalsettings}
badmemoryaccess         Yes

EMS Settings
------------
identifier              {emssettings}
bootems                 No

Debugger Settings
-----------------
identifier              {dbgsettings}
debugtype               Local

RAM Defects
-----------
identifier              {badmemory}

Global Settings
---------------
identifier              {globalsettings}
inherit                 {dbgsettings}
                        {emssettings}
                        {badmemory}

Boot Loader Settings
--------------------
identifier              {bootloadersettings}
inherit                 {globalsettings}
                        {hypervisorsettings}

Hypervisor Settings
-------------------
identifier              {hypervisorsettings}
hypervisordebugtype     Serial
hypervisordebugport     1
hypervisorbaudrate      115200

Resume Loader Settings
----------------------
identifier              {resumeloadersettings}
inherit                 {globalsettings}
