Issues upgrading from 10 Pro to 11 Pro


Oaklands

Member
Local time
1:28 PM
Posts
1
OS
Windows 10 Pro
I'm having issues trying to upgrade to Windows 11 Pro. At first I received errors that TPM 2.0 wasn't activated and Secure Boot was not on. I turned these items on and then could not boot when I turned on Secure Boot. I turned CSM off and Secure boot on.

Next I did some reading on the subject and found that when I first installed the computer I did not use UEFI. I then used EaseUS Partition Manager and changed my SSD from MBR to GPT. This did not help at all. I have tried several different things but I can only boot from a flash drive. The install will not work this way either as it still sees my Secure Boot not turned on.

I think part of the problem is how my drives are setup. The secondary Toshiba HDD is listed as drive 0 with 500 MB FAT32 partition and remaining 2 GB as NTFS.

My Samsung SSD has 3 partitions all showing as NTFS (screenshot attached)Screenshot 2022-06-09 153214.jpg

This is my work computer and I don't want to have to install fresh as there are many emails, apps and such. Does anyone have any ideas on how I can get around formatting and doing a fresh install? I'm thinking there is another step I need to do concerning the C: drive. Any suggestions are welcome.


My Computer

System One

  • OS
    Windows 10 Pro
    Computer type
    PC/Desktop
    Manufacturer/Model
    Generic
    CPU
    Intel Core i5-8500 6 core
    Motherboard
    Gigabyte B360M DS3H
    Memory
    16Gb
    Graphics Card(s)
    Intel UHD Graphics 630
    Sound Card
    Realtek High Definition Audio
    Monitor(s) Displays
    2 displays
    Screen Resolution
    1920 x 1080
    Hard Drives
    Samung EVO-970 512Gb SSD, Toshiba 2TB HD
    PSU
    600 Watt
    Case
    ThermalTake
    Cooling
    unknown
    Keyboard
    logitech wireless
    Mouse
    logitech wireless
    Internet Speed
    400Mb down 20Mb up
    Browser
    Opera, Edge, Firefox
    Antivirus
    Windows Defender

Samuria

Member
VIP
Local time
6:28 PM
Posts
32
OS
win 10
Welcome to the forum. As you have changed thing around thats why it cant boot. Your solutions if get a boot free disk clone boot from that make an image of windows. Then disconect second disk and swap cables so c: is drive 0 and the second drive will be 1 but dont leave it connected. Then setup bios correctley tmp, secure boot ,uefi then boot 11 install and during it delete all partitions let windows create correct ones. It should install ok and activate. You can then connect second drive and get back any data you want as you can mount the image as a drive


My Computer

System One

  • OS
    win 10

NavyLCDR

Well-known member
Power User
VIP
Local time
10:28 AM
Posts
999
OS
Windows 11
First, please post the results of:
Code:
diskpart
list disk

Here is mine:
Code:
Microsoft Windows [Version 10.0.22621.1]
(c) Microsoft Corporation. All rights reserved.

C:\Windows\System32>diskpart

Microsoft DiskPart version 10.0.22621.1

Copyright (C) Microsoft Corporation.
On computer: RAIDER

DISKPART> list disk

  Disk ###  Status         Size     Free     Dyn  Gpt
  --------  -------------  -------  -------  ---  ---
  Disk 0    Online          953 GB      0 B        *
  Disk 1    Online          465 GB  1024 KB        *

DISKPART>


My Computers

System One System Two

  • OS
    Windows 11
    Computer type
    PC/Desktop
    Manufacturer/Model
    Homebuilt
    CPU
    AMD Ryzen 7 3800XT
    Motherboard
    ASUS ROG Crosshair VII Hero (WiFi)
    Memory
    32GB
    Graphics Card(s)
    EVGA GeForce GTX 1080 Ti
  • Operating System
    Windows 11 Education
    Computer type
    Laptop
    Manufacturer/Model
    Dell Inspiron 7773
    CPU
    Intel i7-8550U
    Memory
    32GB
    Graphics card(s)
    Nvidia Geforce MX150
    Sound Card
    Realtek
    Monitor(s) Displays
    17"
    Screen Resolution
    1920 x 1080
    Hard Drives
    Toshiba 512GB NVMe SSD
    SK Hynix 512GB SATA SSD
    Internet Speed
    Fast!

Megahertz

Wish to be flying
Member
VIP
Local time
2:28 PM
Posts
131
Location
Brazil
OS
Windows 7 HP 64 - Windows 11 Pro - Lubuntu
Your drives are a big mess. The EFI Fat32 partition is on the drive 0. It should be on same drive as the OS, drive 1. It seems it is booting from drive 0 and then transferring the boot sequence to drive 1. This happens when you install on a new drive without disconnecting the others.
This is quite easy to fix.
As already asked, post the results of diskpart - List disk


My Computers

System One System Two

  • OS
    Windows 7 HP 64 - Windows 11 Pro - Lubuntu
    Computer type
    PC/Desktop
    Manufacturer/Model
    custom build
    CPU
    i5 6600K - 800MHz to 4400MHz
    Motherboard
    GA-Z170-HD3P
    Memory
    4+4G GSkill DDR4 3000
    Graphics Card(s)
    IG - Intel 530
    Monitor(s) Displays
    Samsung 226BW
    Screen Resolution
    1680x1050
    Hard Drives
    (1) -1 SM951 – 128GB M.2 AHCI PCIe SSD drive for Windows 7 and Lubuntu
    (2) -1 WD SATA 3 - 1T for Data
    (3) -1 WD SATA 3 - 1T for backup
    (4) -1 BX500 SSD - 128G for Win 10
    PSU
    Thermaltake 450W TR2 gold
    Keyboard
    Old and good Chicony mechanical keyboard
    Mouse
    Logitech mX performance - 9 buttons (had to disable some)
    Internet Speed
    350 Mb/s
    Browser
    Firefox 64
  • Operating System
    Windows 7 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Asus Q550LF
    CPU
    i7-4500U 800- 3000MHz
    Motherboard
    Asus Q550LF
    Memory
    (4+4)G DDR3 1600
    Graphics card(s)
    IG intel 4400 + NVIDIA GeForce GT 745M
    Sound Card
    Realtek
    Monitor(s) Displays
    LG Display LP156WF4-SPH1
    Screen Resolution
    1920 x 1080
    Hard Drives
    BX500 120G SSD for Windows and programs
    & 1T HDD for data
    Internet Speed
    350 Mb/s
    Browser
    Firefox 64

AddRAM

R.I.P.
Power User
VIP
Local time
1:28 PM
Posts
689
Location
Mandalore
OS
Windows 11 Pro
Clean install 11 and use your MS Account to activate 11.
On a brand new Samsung 870 EVO 500GB or 1TB


And of course you have to set your Bios correctly this time.



My Computers

System One System Two

  • OS
    Windows 11 Pro
    Computer type
    PC/Desktop
    Manufacturer/Model
    Skylake Special X299
    CPU
    Intel Core i9 9900X
    Motherboard
    Asus ROG Strix X299-E Gaming II
    Memory
    GSkill Trident Z RGB 32GB 3600 16-16-16-36 (F4-3600C16Q-32GTZR)
    Graphics Card(s)
    EVGA RTX 3080 12GB FTW3 Ultra Gaming (12G-P5-4877-KL)
    Sound Card
    Supreme FX
    Monitor(s) Displays
    Asus PG279Q
    Screen Resolution
    2560 x 1440 165Hz
    Hard Drives
    Samsung 980 Pro 500GB x2, Seagate Barracuda 4TB x2, Western Digital Black 4TB x1
    PSU
    EVGA 1200 P2, EVGA Black Custom Braided Cables
    Case
    Thermaltake View 31 Tempered Glass Limited Edition
    Cooling
    Corsair H115i, Thermal Grizzly Kryonaut
    Keyboard
    Logitech G910 Orion Spark
    Mouse
    Logitech G700s, Asus ROG GX860 Buzzard
    Internet Speed
    Verizon Fios Quantum Gateway 75/75
    Browser
    Edge
    Antivirus
    Windows Defender, Malwarebytes 4.5.2
    Other Info
    Thermaltake Riing Duo 14 x3, Thermaltake Riing Plus 14 x2, Corsair HS70 Pro Wireless Headset
  • Operating System
    Windows 10 Pro
    Computer type
    PC/Desktop
    Manufacturer/Model
    Skylake Special Z170
    CPU
    Intel Core i7 6700K
    Motherboard
    Asus Sabertooth Z170 Mark 1
    Memory
    GSkill Trident Z RGB 16GB 3600 16-16-16-36 (F4-3600C16D-16GTZR)
    Graphics card(s)
    EVGA GTX 980 Ti SC x2, EVGA Pro SLI Bridge
    Sound Card
    Realtek High Definition
    Monitor(s) Displays
    AOC G2460PG
    Screen Resolution
    1920 x 1080 144Hz
    Hard Drives
    Samsung 870 Evo 500GB, Seagate Barracuda 4TB x2
    PSU
    EVGA 1000 P2, EVGA White Custom Braided Cables
    Case
    Corsair Vengeance C70 Gunmetal Black
    Cooling
    Corsair H100i v2, Corsair ML120 x2, Thermal Grizzly Kryonaut
    Mouse
    Logitech G500s
    Keyboard
    Logitech G910 Orion Spectrum
    Internet Speed
    Verizon Fios Quantum Gateway 75/75
    Browser
    Edge
    Antivirus
    Windows Defender, Malwarebytes 4.5.2
    Other Info
    Corsair SP120 x4, LG Blu-ray Drive, Durabrand HT-395 100 Watt Dolby Digital Amp

AddRAM

R.I.P.
Power User
VIP
Local time
1:28 PM
Posts
689
Location
Mandalore
OS
Windows 11 Pro
But seeing it`s a work PC, there is no reason to upgrade it to 11.
You are wasting your time.


My Computers

System One System Two

  • OS
    Windows 11 Pro
    Computer type
    PC/Desktop
    Manufacturer/Model
    Skylake Special X299
    CPU
    Intel Core i9 9900X
    Motherboard
    Asus ROG Strix X299-E Gaming II
    Memory
    GSkill Trident Z RGB 32GB 3600 16-16-16-36 (F4-3600C16Q-32GTZR)
    Graphics Card(s)
    EVGA RTX 3080 12GB FTW3 Ultra Gaming (12G-P5-4877-KL)
    Sound Card
    Supreme FX
    Monitor(s) Displays
    Asus PG279Q
    Screen Resolution
    2560 x 1440 165Hz
    Hard Drives
    Samsung 980 Pro 500GB x2, Seagate Barracuda 4TB x2, Western Digital Black 4TB x1
    PSU
    EVGA 1200 P2, EVGA Black Custom Braided Cables
    Case
    Thermaltake View 31 Tempered Glass Limited Edition
    Cooling
    Corsair H115i, Thermal Grizzly Kryonaut
    Keyboard
    Logitech G910 Orion Spark
    Mouse
    Logitech G700s, Asus ROG GX860 Buzzard
    Internet Speed
    Verizon Fios Quantum Gateway 75/75
    Browser
    Edge
    Antivirus
    Windows Defender, Malwarebytes 4.5.2
    Other Info
    Thermaltake Riing Duo 14 x3, Thermaltake Riing Plus 14 x2, Corsair HS70 Pro Wireless Headset
  • Operating System
    Windows 10 Pro
    Computer type
    PC/Desktop
    Manufacturer/Model
    Skylake Special Z170
    CPU
    Intel Core i7 6700K
    Motherboard
    Asus Sabertooth Z170 Mark 1
    Memory
    GSkill Trident Z RGB 16GB 3600 16-16-16-36 (F4-3600C16D-16GTZR)
    Graphics card(s)
    EVGA GTX 980 Ti SC x2, EVGA Pro SLI Bridge
    Sound Card
    Realtek High Definition
    Monitor(s) Displays
    AOC G2460PG
    Screen Resolution
    1920 x 1080 144Hz
    Hard Drives
    Samsung 870 Evo 500GB, Seagate Barracuda 4TB x2
    PSU
    EVGA 1000 P2, EVGA White Custom Braided Cables
    Case
    Corsair Vengeance C70 Gunmetal Black
    Cooling
    Corsair H100i v2, Corsair ML120 x2, Thermal Grizzly Kryonaut
    Mouse
    Logitech G500s
    Keyboard
    Logitech G910 Orion Spectrum
    Internet Speed
    Verizon Fios Quantum Gateway 75/75
    Browser
    Edge
    Antivirus
    Windows Defender, Malwarebytes 4.5.2
    Other Info
    Corsair SP120 x4, LG Blu-ray Drive, Durabrand HT-395 100 Watt Dolby Digital Amp

cereberus

Well-known member
Pro User
VIP
Local time
6:28 PM
Posts
2,521
OS
Windows 10 Pro + others in VHDs
Easiest way to fix this is to move efi partition to drive 1 but you will need to shrink C drive first. You will need to use a 3rd party partition manager like Easeus Partiton Manager.


My Computer

System One

  • OS
    Windows 10 Pro + others in VHDs
    Computer type
    Laptop
    Manufacturer/Model
    ASUS Vivobook 14
    CPU
    I7
    Motherboard
    Yep, Laptop has one.
    Memory
    16 GB
    Graphics Card(s)
    Integrated Intel Iris XE
    Sound Card
    Realtek built in
    Monitor(s) Displays
    N/A
    Screen Resolution
    1920x1080
    Hard Drives
    1 TB Optane NVME SSD, 1 TB NVME SSD
    PSU
    Yep, got one
    Case
    Yep, got one
    Cooling
    Stella Artois
    Keyboard
    Built in
    Mouse
    Bluetooth , wired
    Internet Speed
    72 Mb/s :-(
    Browser
    Edge mostly
    Antivirus
    Defender
    Other Info
    TPM 2.0
Top Bottom
