Solved New Build Can't accept Windows 11


F

friendlyphil

Member
Local time
10:16 AM
Posts
20
Visit site
OS
Windows11
First of all, I lack expertise is this stuff. But I have put together a new computer with Gigabyte Z590 UD motherboard, 32GB RAM, and Intel Core i7 10700 and a WD 2TB SSD as the only drive.
I am trying to install an OEM version of Windows 11. But it tells me I don't meet the requirements for Windows 11.

I formatted the SSD on another computer and the BIOS in the new computer recognizes it, but that's apparently not good enough for Win 11.

What should I do to get this installed?


My Computer

System One

  • OS
    Windows11
    Computer type
    PC/Desktop
    CPU
    Intel Core i7 - 10700
    Motherboard
    Gigabyte Z590 UD
    Memory
    G.Skil 32 GB Ripjaws V series DDR PC4-25600 3200Mhz for Intel Z170
    Graphics Card(s)
    Onboard
    Sound Card
    none
    Hard Drives
    WD 2TB SSD
    Case
    Cooler Master
Bree

Bree

Well-known member
Guru
VIP
Local time
3:16 PM
Posts
9,144
Location
S/E England, UK
Visit site
OS
Windows 11 Home
friendlyphil said:
I am trying to install an OEM version of Windows 11. But it tells me I don't meet the requirements for Windows 11.
Click to expand...
Welcome to Eleven Forum.

On paper that seems to meet all the specs, but there may be some things that are turned off in the bios that prevent you installing windows 11. In particular it must be capable of Secure boot and TPM 2.0 must be enabled.

Enable TPM 2.0 on your PC - Microsoft Support

Learn how to check if your PC is capable of running TPM 2.0 or how to enable TPM 2.0 to upgrade to Windows 11.
support.microsoft.com support.microsoft.com


My Computers

System One System Two

  • OS
    Windows 11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Acer Aspire 3 A315-23
    CPU
    AMD Athlon Silver 3050U
    Memory
    8GB
    Graphics Card(s)
    Radeon Graphics
    Monitor(s) Displays
    laptop screen
    Screen Resolution
    1366x768 native resolution, up to 2560x1440 with Radeon Virtual Super Resolution
    Hard Drives
    1TB Samsung EVO 870 SSD
    Internet Speed
    50 Mbps
    Browser
    Edge, Firefox
    Antivirus
    Defender
    Other Info
    fully 'Windows 11 ready' laptop. Windows 10 C: partition migrated from my old unsupported 'main machine' then upgraded to 11. A test migration ran Insider builds for 2 months. When 11 was released on 5th October it was re-imaged back to 10 and was offered the upgrade in Windows Update on 20th October. Windows Update offered the 22H2 Feature Update on 20th September 2022.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
  • Operating System
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Dell Lattitude E4310
    CPU
    i5 M 520
    Motherboard
    0T6M8G
    Memory
    8GB
    Screen Resolution
    1366x768
    Hard Drives
    500GB HDD
    Browser
    Firefox, Edge
    Antivirus
    Defender
    Other Info
    unsupported machine: Legacy bios, MBR, TPM 1.2, upgraded from W10 to W11 using W10/W11 hybrid install media workaround. In-place upgrade to 22H2 using ISO and a workaround.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
DigitalGoat

DigitalGoat

Well-known member
Power User
VIP
Local time
3:16 PM
Posts
500
Location
United Kingdom
Visit site
OS
Windows 11 Pro 22H2, build: 22621.521
A default Windows 11 install requires both secure boot and TPM2.0 to be enabled for the install to proceed.
These options can normally be found in the BIOS (UEFI) accessed when the PC is first turned on or restarted by pressing DEL or F2 or similar, the motherboard manual should tell you the default key or it should display at startup with the message 'Press key to enter setup'.
The disk you install Windows to should ideally be blank, unallocated space, Windows will create the partitions it requires. If you have prepared the disk already it is possible it is initialised as MBR and not GPT as Windows 11 expects.


My Computer

System One

  • OS
    Windows 11 Pro 22H2, build: 22621.521
    Computer type
    PC/Desktop
    Manufacturer/Model
    Scan 3XS Custom 1700
    CPU
    Intel i7-12700K 3.6GHz Base (5.0GHz Turbo)
    Motherboard
    Asus ProArt Creator B660 D4
    Memory
    64GB DDR 3600Mhz
    Graphics Card(s)
    Asus Tuff RTX 3080 10GB OC
    Sound Card
    Onboard Realtek
    Monitor(s) Displays
    Gigabyte G32QC 32inch 16:9 curved @2560 x 1440p 165Hz Freesync Premium Pro/ Dell SE2422H 24inch 16:9 1920 x 1080p 75Hz Freesync
    Screen Resolution
    2560 x 1440p & 1920 x 1080p
    Hard Drives
    WD SN570 1TB NVME (Boot), Samsung 870QVO 1TB (SSD), SanDisk 3D Ultra 500Gb (SSD) x2, Seagate 3Tb Expansion Desk (Ext HDD), 2x Toshiba 1Tb P300 (Ext HDD)
    PSU
    Corsair RM1000X Modular
    Case
    Corsair 4000D Airflow Desktop
    Cooling
    Corsair Hydro H150i RGB Pro XT 360mm Liquid Cooler, 3 x 120mm fans, 1x Exhaust
    Keyboard
    Microsoft Ergonomic
    Mouse
    Logitech G402
    Internet Speed
    800Mbs
    Browser
    Edge Chromium
    Antivirus
    Defender, Malwarebytes
Bree

Bree

Well-known member
Guru
VIP
Local time
3:16 PM
Posts
9,144
Location
S/E England, UK
Visit site
OS
Windows 11 Home
DigitalGoat said:
The disk you install Windows to should ideally be blank, unallocated space, Windows will create the partitions it requires. If you have prepared the disk already it is possible it is initialised as MBR and not GPT as Windows 11 expects.
Click to expand...
Good point. GPT is not just expected, it is a requirement.


My Computers

System One System Two

  • OS
    Windows 11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Acer Aspire 3 A315-23
    CPU
    AMD Athlon Silver 3050U
    Memory
    8GB
    Graphics Card(s)
    Radeon Graphics
    Monitor(s) Displays
    laptop screen
    Screen Resolution
    1366x768 native resolution, up to 2560x1440 with Radeon Virtual Super Resolution
    Hard Drives
    1TB Samsung EVO 870 SSD
    Internet Speed
    50 Mbps
    Browser
    Edge, Firefox
    Antivirus
    Defender
    Other Info
    fully 'Windows 11 ready' laptop. Windows 10 C: partition migrated from my old unsupported 'main machine' then upgraded to 11. A test migration ran Insider builds for 2 months. When 11 was released on 5th October it was re-imaged back to 10 and was offered the upgrade in Windows Update on 20th October. Windows Update offered the 22H2 Feature Update on 20th September 2022.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
  • Operating System
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Dell Lattitude E4310
    CPU
    i5 M 520
    Motherboard
    0T6M8G
    Memory
    8GB
    Screen Resolution
    1366x768
    Hard Drives
    500GB HDD
    Browser
    Firefox, Edge
    Antivirus
    Defender
    Other Info
    unsupported machine: Legacy bios, MBR, TPM 1.2, upgraded from W10 to W11 using W10/W11 hybrid install media workaround. In-place upgrade to 22H2 using ISO and a workaround.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
DigitalGoat

DigitalGoat

Well-known member
Power User
VIP
Local time
3:16 PM
Posts
500
Location
United Kingdom
Visit site
OS
Windows 11 Pro 22H2, build: 22621.521
Yeah, sorry @Bree we both clicked post at the same time I think. :-)


My Computer

System One

  • OS
    Windows 11 Pro 22H2, build: 22621.521
    Computer type
    PC/Desktop
    Manufacturer/Model
    Scan 3XS Custom 1700
    CPU
    Intel i7-12700K 3.6GHz Base (5.0GHz Turbo)
    Motherboard
    Asus ProArt Creator B660 D4
    Memory
    64GB DDR 3600Mhz
    Graphics Card(s)
    Asus Tuff RTX 3080 10GB OC
    Sound Card
    Onboard Realtek
    Monitor(s) Displays
    Gigabyte G32QC 32inch 16:9 curved @2560 x 1440p 165Hz Freesync Premium Pro/ Dell SE2422H 24inch 16:9 1920 x 1080p 75Hz Freesync
    Screen Resolution
    2560 x 1440p & 1920 x 1080p
    Hard Drives
    WD SN570 1TB NVME (Boot), Samsung 870QVO 1TB (SSD), SanDisk 3D Ultra 500Gb (SSD) x2, Seagate 3Tb Expansion Desk (Ext HDD), 2x Toshiba 1Tb P300 (Ext HDD)
    PSU
    Corsair RM1000X Modular
    Case
    Corsair 4000D Airflow Desktop
    Cooling
    Corsair Hydro H150i RGB Pro XT 360mm Liquid Cooler, 3 x 120mm fans, 1x Exhaust
    Keyboard
    Microsoft Ergonomic
    Mouse
    Logitech G402
    Internet Speed
    800Mbs
    Browser
    Edge Chromium
    Antivirus
    Defender, Malwarebytes
F

friendlyphil

Member
Thread Starter
Local time
10:16 AM
Posts
20
Visit site
OS
Windows11
The disc is GPT. TPM is enabled in BIOS, but it does not specify 2.0. Secure Boot is also enabled. Still, Win11 will not load.


My Computer

System One

  • OS
    Windows11
    Computer type
    PC/Desktop
    CPU
    Intel Core i7 - 10700
    Motherboard
    Gigabyte Z590 UD
    Memory
    G.Skil 32 GB Ripjaws V series DDR PC4-25600 3200Mhz for Intel Z170
    Graphics Card(s)
    Onboard
    Sound Card
    none
    Hard Drives
    WD 2TB SSD
    Case
    Cooler Master
Bree

Bree

Well-known member
Guru
VIP
Local time
3:16 PM
Posts
9,144
Location
S/E England, UK
Visit site
OS
Windows 11 Home
DigitalGoat said:
Yeah, sorry @Bree we both clicked post at the same time I think. :-)
Click to expand...
No need to be sorry, you added a point I had missed. Anyway, two posts making the same points should reassure the OP that this should be solvable. :wink:


My Computers

System One System Two

  • OS
    Windows 11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Acer Aspire 3 A315-23
    CPU
    AMD Athlon Silver 3050U
    Memory
    8GB
    Graphics Card(s)
    Radeon Graphics
    Monitor(s) Displays
    laptop screen
    Screen Resolution
    1366x768 native resolution, up to 2560x1440 with Radeon Virtual Super Resolution
    Hard Drives
    1TB Samsung EVO 870 SSD
    Internet Speed
    50 Mbps
    Browser
    Edge, Firefox
    Antivirus
    Defender
    Other Info
    fully 'Windows 11 ready' laptop. Windows 10 C: partition migrated from my old unsupported 'main machine' then upgraded to 11. A test migration ran Insider builds for 2 months. When 11 was released on 5th October it was re-imaged back to 10 and was offered the upgrade in Windows Update on 20th October. Windows Update offered the 22H2 Feature Update on 20th September 2022.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
  • Operating System
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Dell Lattitude E4310
    CPU
    i5 M 520
    Motherboard
    0T6M8G
    Memory
    8GB
    Screen Resolution
    1366x768
    Hard Drives
    500GB HDD
    Browser
    Firefox, Edge
    Antivirus
    Defender
    Other Info
    unsupported machine: Legacy bios, MBR, TPM 1.2, upgraded from W10 to W11 using W10/W11 hybrid install media workaround. In-place upgrade to 22H2 using ISO and a workaround.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
Bree

Bree

Well-known member
Guru
VIP
Local time
3:16 PM
Posts
9,144
Location
S/E England, UK
Visit site
OS
Windows 11 Home

My Computers

System One System Two

  • OS
    Windows 11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Acer Aspire 3 A315-23
    CPU
    AMD Athlon Silver 3050U
    Memory
    8GB
    Graphics Card(s)
    Radeon Graphics
    Monitor(s) Displays
    laptop screen
    Screen Resolution
    1366x768 native resolution, up to 2560x1440 with Radeon Virtual Super Resolution
    Hard Drives
    1TB Samsung EVO 870 SSD
    Internet Speed
    50 Mbps
    Browser
    Edge, Firefox
    Antivirus
    Defender
    Other Info
    fully 'Windows 11 ready' laptop. Windows 10 C: partition migrated from my old unsupported 'main machine' then upgraded to 11. A test migration ran Insider builds for 2 months. When 11 was released on 5th October it was re-imaged back to 10 and was offered the upgrade in Windows Update on 20th October. Windows Update offered the 22H2 Feature Update on 20th September 2022.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
  • Operating System
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Dell Lattitude E4310
    CPU
    i5 M 520
    Motherboard
    0T6M8G
    Memory
    8GB
    Screen Resolution
    1366x768
    Hard Drives
    500GB HDD
    Browser
    Firefox, Edge
    Antivirus
    Defender
    Other Info
    unsupported machine: Legacy bios, MBR, TPM 1.2, upgraded from W10 to W11 using W10/W11 hybrid install media workaround. In-place upgrade to 22H2 using ISO and a workaround.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
F

friendlyphil

Member
Thread Starter
Local time
10:16 AM
Posts
20
Visit site
OS
Windows11
It said the system does not meet the requirements for Win11. Nothing more.


My Computer

System One

  • OS
    Windows11
    Computer type
    PC/Desktop
    CPU
    Intel Core i7 - 10700
    Motherboard
    Gigabyte Z590 UD
    Memory
    G.Skil 32 GB Ripjaws V series DDR PC4-25600 3200Mhz for Intel Z170
    Graphics Card(s)
    Onboard
    Sound Card
    none
    Hard Drives
    WD 2TB SSD
    Case
    Cooler Master
F

friendlyphil

Member
Thread Starter
Local time
10:16 AM
Posts
20
Visit site
OS
Windows11
What if I disable the HDD on the other PC, install the SSD from the new build and try to install Win11 there? The old PC is already running Win11. Is that worth a try?


My Computer

System One

  • OS
    Windows11
    Computer type
    PC/Desktop
    CPU
    Intel Core i7 - 10700
    Motherboard
    Gigabyte Z590 UD
    Memory
    G.Skil 32 GB Ripjaws V series DDR PC4-25600 3200Mhz for Intel Z170
    Graphics Card(s)
    Onboard
    Sound Card
    none
    Hard Drives
    WD 2TB SSD
    Case
    Cooler Master
Bree

Bree

Well-known member
Guru
VIP
Local time
3:16 PM
Posts
9,144
Location
S/E England, UK
Visit site
OS
Windows 11 Home
friendlyphil said:
It said the system does not meet the requirements for Win11. Nothing more.
Click to expand...
If you have any sort of Windows installed you could run WhyNotWin11 for a comprehensive list of what does (and does not) meet the requirements.

github.com

GitHub - rcmaehl/WhyNotWin11: Detection Script to help identify why your PC is not Windows 11 Release Ready. Now Supporting Update Checks!

Detection Script to help identify why your PC is not Windows 11 Release Ready. Now Supporting Update Checks! - GitHub - rcmaehl/WhyNotWin11: Detection Script to help identify why your PC is not Win...
github.com github.com


My Computers

System One System Two

  • OS
    Windows 11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Acer Aspire 3 A315-23
    CPU
    AMD Athlon Silver 3050U
    Memory
    8GB
    Graphics Card(s)
    Radeon Graphics
    Monitor(s) Displays
    laptop screen
    Screen Resolution
    1366x768 native resolution, up to 2560x1440 with Radeon Virtual Super Resolution
    Hard Drives
    1TB Samsung EVO 870 SSD
    Internet Speed
    50 Mbps
    Browser
    Edge, Firefox
    Antivirus
    Defender
    Other Info
    fully 'Windows 11 ready' laptop. Windows 10 C: partition migrated from my old unsupported 'main machine' then upgraded to 11. A test migration ran Insider builds for 2 months. When 11 was released on 5th October it was re-imaged back to 10 and was offered the upgrade in Windows Update on 20th October. Windows Update offered the 22H2 Feature Update on 20th September 2022.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
  • Operating System
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Dell Lattitude E4310
    CPU
    i5 M 520
    Motherboard
    0T6M8G
    Memory
    8GB
    Screen Resolution
    1366x768
    Hard Drives
    500GB HDD
    Browser
    Firefox, Edge
    Antivirus
    Defender
    Other Info
    unsupported machine: Legacy bios, MBR, TPM 1.2, upgraded from W10 to W11 using W10/W11 hybrid install media workaround. In-place upgrade to 22H2 using ISO and a workaround.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
F

friendlyphil

Member
Thread Starter
Local time
10:16 AM
Posts
20
Visit site
OS
Windows11
Nothing is installed in the new build. It is clean.


My Computer

System One

  • OS
    Windows11
    Computer type
    PC/Desktop
    CPU
    Intel Core i7 - 10700
    Motherboard
    Gigabyte Z590 UD
    Memory
    G.Skil 32 GB Ripjaws V series DDR PC4-25600 3200Mhz for Intel Z170
    Graphics Card(s)
    Onboard
    Sound Card
    none
    Hard Drives
    WD 2TB SSD
    Case
    Cooler Master
hsehestedt

hsehestedt

Well-known member
Power User
VIP
Local time
10:16 AM
Posts
1,444
Location
Texas, USA
Visit site
OS
Win11 Pro 22H2, Moment 2
friendlyphil said:
What if I disable the HDD on the other PC, install the SSD from the new build and try to install Win11 there? The old PC is already running Win11. Is that worth a try?
Click to expand...
You are making it more difficult than it needs to be at that point. Just check the TPM. In your case, since you likely don't have a physical TPM, you simply need to enable the firmware TPM and Windows 11 should be happy.


My Computers

System One System Two

  • OS
    Win11 Pro 22H2, Moment 2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Home Built
    CPU
    Intel i7-11700K
    Motherboard
    ASUS Prime Z590-A
    Memory
    128GB Crucial Ballistix 3200MHz DRAM
    Graphics Card(s)
    No GPU - CPU graphics only (for now)
    Sound Card
    Realtek (on motherboard)
    Monitor(s) Displays
    HP Envy 32
    Screen Resolution
    2560 x 1440
    Hard Drives
    1 x 1TB NVMe Gen 4 x 4 SSD
    1 x 2TB NVMe Gen 3 x 4 SSD
    2 x 512GB 2.5" SSDs
    2 x 8TB HD
    PSU
    Corsair HX850i
    Case
    Corsair iCue 5000X RGB
    Cooling
    Noctua NH-D15 chromax.black cooler + 10 case fans
    Keyboard
    CODE backlit mechanical keyboard
    Mouse
    Logitech MX Master 3
    Internet Speed
    1Gb Up / 1 Gb Down
    Browser
    Chromium Edge
    Antivirus
    Windows Defender
    Other Info
    Additional options installed:
    WiFi 6E PCIe adapter
    ASUS ThunderboltEX 4 PCIe adapter
  • Operating System
    Win11 Pro 22H2, Moment 2
    Computer type
    Laptop
    Manufacturer/Model
    HP Spectre x360 15-BL012DX
    CPU
    Intel i7-7500U
    Memory
    32GB
    Graphics card(s)
    Dual Intel HD 620 and Nvidia GeForce 940MX
    Sound Card
    Built-in Realtek HD Audio
    Monitor(s) Displays
    4k 15-inch
    Screen Resolution
    4k (3840 x 2160)
    Hard Drives
    1TB Seagate FireCuda 510 NVMe SSD
    Internet Speed
    1Gb Up / 1Gb Down
    Browser
    Chromium Edge
    Antivirus
    Windows Defender
    Other Info
    RAM Upgraded from 16GB to 32GB WiFi Upgraded from WiFi 5 to WiFi 6 SSD upgraded from 512GB NVMe SSD to 1TB Seagate FireCuda 510 NVMe SSD
Bree

Bree

Well-known member
Guru
VIP
Local time
3:16 PM
Posts
9,144
Location
S/E England, UK
Visit site
OS
Windows 11 Home
friendlyphil said:
Nothing is installed in the new build. It is clean.
Click to expand...
WhyNotWin11 can run while booted from the install USB. At the 'Install now' screen press Shift+F10 to get a command prompt. You can run it from there. When I tested this just now I put a copy of WhyNotWin11.exe on my install usb before booting from it, it was available as the D: drive.


My Computers

System One System Two

  • OS
    Windows 11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Acer Aspire 3 A315-23
    CPU
    AMD Athlon Silver 3050U
    Memory
    8GB
    Graphics Card(s)
    Radeon Graphics
    Monitor(s) Displays
    laptop screen
    Screen Resolution
    1366x768 native resolution, up to 2560x1440 with Radeon Virtual Super Resolution
    Hard Drives
    1TB Samsung EVO 870 SSD
    Internet Speed
    50 Mbps
    Browser
    Edge, Firefox
    Antivirus
    Defender
    Other Info
    fully 'Windows 11 ready' laptop. Windows 10 C: partition migrated from my old unsupported 'main machine' then upgraded to 11. A test migration ran Insider builds for 2 months. When 11 was released on 5th October it was re-imaged back to 10 and was offered the upgrade in Windows Update on 20th October. Windows Update offered the 22H2 Feature Update on 20th September 2022.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
  • Operating System
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Dell Lattitude E4310
    CPU
    i5 M 520
    Motherboard
    0T6M8G
    Memory
    8GB
    Screen Resolution
    1366x768
    Hard Drives
    500GB HDD
    Browser
    Firefox, Edge
    Antivirus
    Defender
    Other Info
    unsupported machine: Legacy bios, MBR, TPM 1.2, upgraded from W10 to W11 using W10/W11 hybrid install media workaround. In-place upgrade to 22H2 using ISO and a workaround.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB ssd, supported device running Windows 11 Pro.

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 4GB RAM, 128GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro 22H2 Insider Beta as a native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 4GB RAM, 128GB NVMe ssd, supported device running Windows 11 Pro.
hsehestedt

hsehestedt

Well-known member
Power User
VIP
Local time
10:16 AM
Posts
1,444
Location
Texas, USA
Visit site
OS
Win11 Pro 22H2, Moment 2
I just looked up the documentation for your motherboard. I would suggest making sure that you are on the latest BIOS. First, one of the BIOS updates fixed what Gigabyte calls a major security vulnerability, and also, they tweaked some settings for better compatibility with Windows 11. The main change is that the firmware TPM (Intel PTT or Platform Trust Technology) is now enabled by default to meet Windows 11 requirements.

If you did not purchase a physical TPM for your motherboard, then make sure to disable TPM in the BIOS and enable the Intel PTT (that is the firmware TPM).


My Computers

System One System Two

  • OS
    Win11 Pro 22H2, Moment 2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Home Built
    CPU
    Intel i7-11700K
    Motherboard
    ASUS Prime Z590-A
    Memory
    128GB Crucial Ballistix 3200MHz DRAM
    Graphics Card(s)
    No GPU - CPU graphics only (for now)
    Sound Card
    Realtek (on motherboard)
    Monitor(s) Displays
    HP Envy 32
    Screen Resolution
    2560 x 1440
    Hard Drives
    1 x 1TB NVMe Gen 4 x 4 SSD
    1 x 2TB NVMe Gen 3 x 4 SSD
    2 x 512GB 2.5" SSDs
    2 x 8TB HD
    PSU
    Corsair HX850i
    Case
    Corsair iCue 5000X RGB
    Cooling
    Noctua NH-D15 chromax.black cooler + 10 case fans
    Keyboard
    CODE backlit mechanical keyboard
    Mouse
    Logitech MX Master 3
    Internet Speed
    1Gb Up / 1 Gb Down
    Browser
    Chromium Edge
    Antivirus
    Windows Defender
    Other Info
    Additional options installed:
    WiFi 6E PCIe adapter
    ASUS ThunderboltEX 4 PCIe adapter
  • Operating System
    Win11 Pro 22H2, Moment 2
    Computer type
    Laptop
    Manufacturer/Model
    HP Spectre x360 15-BL012DX
    CPU
    Intel i7-7500U
    Memory
    32GB
    Graphics card(s)
    Dual Intel HD 620 and Nvidia GeForce 940MX
    Sound Card
    Built-in Realtek HD Audio
    Monitor(s) Displays
    4k 15-inch
    Screen Resolution
    4k (3840 x 2160)
    Hard Drives
    1TB Seagate FireCuda 510 NVMe SSD
    Internet Speed
    1Gb Up / 1Gb Down
    Browser
    Chromium Edge
    Antivirus
    Windows Defender
    Other Info
    RAM Upgraded from 16GB to 32GB WiFi Upgraded from WiFi 5 to WiFi 6 SSD upgraded from 512GB NVMe SSD to 1TB Seagate FireCuda 510 NVMe SSD
hsehestedt

hsehestedt

Well-known member
Power User
VIP
Local time
10:16 AM
Posts
1,444
Location
Texas, USA
Visit site
OS
Win11 Pro 22H2, Moment 2

My Computers

System One System Two

  • OS
    Win11 Pro 22H2, Moment 2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Home Built
    CPU
    Intel i7-11700K
    Motherboard
    ASUS Prime Z590-A
    Memory
    128GB Crucial Ballistix 3200MHz DRAM
    Graphics Card(s)
    No GPU - CPU graphics only (for now)
    Sound Card
    Realtek (on motherboard)
    Monitor(s) Displays
    HP Envy 32
    Screen Resolution
    2560 x 1440
    Hard Drives
    1 x 1TB NVMe Gen 4 x 4 SSD
    1 x 2TB NVMe Gen 3 x 4 SSD
    2 x 512GB 2.5" SSDs
    2 x 8TB HD
    PSU
    Corsair HX850i
    Case
    Corsair iCue 5000X RGB
    Cooling
    Noctua NH-D15 chromax.black cooler + 10 case fans
    Keyboard
    CODE backlit mechanical keyboard
    Mouse
    Logitech MX Master 3
    Internet Speed
    1Gb Up / 1 Gb Down
    Browser
    Chromium Edge
    Antivirus
    Windows Defender
    Other Info
    Additional options installed:
    WiFi 6E PCIe adapter
    ASUS ThunderboltEX 4 PCIe adapter
  • Operating System
    Win11 Pro 22H2, Moment 2
    Computer type
    Laptop
    Manufacturer/Model
    HP Spectre x360 15-BL012DX
    CPU
    Intel i7-7500U
    Memory
    32GB
    Graphics card(s)
    Dual Intel HD 620 and Nvidia GeForce 940MX
    Sound Card
    Built-in Realtek HD Audio
    Monitor(s) Displays
    4k 15-inch
    Screen Resolution
    4k (3840 x 2160)
    Hard Drives
    1TB Seagate FireCuda 510 NVMe SSD
    Internet Speed
    1Gb Up / 1Gb Down
    Browser
    Chromium Edge
    Antivirus
    Windows Defender
    Other Info
    RAM Upgraded from 16GB to 32GB WiFi Upgraded from WiFi 5 to WiFi 6 SSD upgraded from 512GB NVMe SSD to 1TB Seagate FireCuda 510 NVMe SSD
S

ShamrockRig

R H Semi
Power User
Local time
3:16 PM
Posts
1,256
Location
Scotland/Eire
Visit site
OS
11
hsehestedt said:
Also found the following article linked to by the FAQ for your motherboard:

www.gigabyte.com

The BIOS of GIGABYTE Motherboards Features TPM 2.0 Function to Support Windows 11 Upgrade | News - GIGABYTE Global

July 2nd, 2021 – GIGABYTE TECHNOLOGY Co. Ltd, a leading manufacturer of motherboards, graphics cards, and hardware solutions, announced that the BIOS ...
www.gigabyte.com www.gigabyte.com

The screenshot should give you an idea of where to look.
Click to expand...
Yeah i have the same looking BIOS, I do remember it showing as tpm 1.2 actual and 2.0 via software, I did need to do something to get it going but i cannot for the life of me remember sadly as it about 18 months ago


My Computer

System One

  • OS
    11
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom
    CPU
    10700k@5.2
    Motherboard
    Gigabyte Gaming X Z490
    Memory
    Viper Steelseries 32gb@ 3600mhz
    Graphics Card(s)
    Gigabyte 2070 Super 8GB, +200 core + 600 memory
    Monitor(s) Displays
    ASUS 4k HDR, Two 1080p Benq and Samsung
    Screen Resolution
    3840x2160/2560x1440/1920x1080
    Hard Drives
    Adata XPG SX8200 PRO 1tb
    Samsung EVO 870 500GB
    PSU
    Corsair RX 650
    Case
    NZXT h510
    Cooling
    CM HYPER 212 RGB
    Keyboard
    Razer Ornata Chroma
    Mouse
    Steelseries Rival 710
hsehestedt

hsehestedt

Well-known member
Power User
VIP
Local time
10:16 AM
Posts
1,444
Location
Texas, USA
Visit site
OS
Win11 Pro 22H2, Moment 2
ShamrockRig said:
Yeah i have the same looking BIOS, I do remember it showing as tpm 1.2 actual and 2.0 via software, I did need to do something to get it going but i cannot for the life of me remember sadly as it about 18 months ago
Click to expand...
Okay, that makes sense. I'm not sure how the system will behave with a physical TPM 1.2 installed. It's possible that a physical TPM may block enabling of the firmware TPM. If you cannot seem to enable the firmware TPM (Intel PTT), then you may want to try physical removal of the older 1.2 TPM.

As a last resort, there are bypasses to allow Windows 11 to be installed with no TPM support whatsoever, but since you clearly have hardware capable of supporting Win 11, that would not be the route that I would suggest.


My Computers

System One System Two

  • OS
    Win11 Pro 22H2, Moment 2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Home Built
    CPU
    Intel i7-11700K
    Motherboard
    ASUS Prime Z590-A
    Memory
    128GB Crucial Ballistix 3200MHz DRAM
    Graphics Card(s)
    No GPU - CPU graphics only (for now)
    Sound Card
    Realtek (on motherboard)
    Monitor(s) Displays
    HP Envy 32
    Screen Resolution
    2560 x 1440
    Hard Drives
    1 x 1TB NVMe Gen 4 x 4 SSD
    1 x 2TB NVMe Gen 3 x 4 SSD
    2 x 512GB 2.5" SSDs
    2 x 8TB HD
    PSU
    Corsair HX850i
    Case
    Corsair iCue 5000X RGB
    Cooling
    Noctua NH-D15 chromax.black cooler + 10 case fans
    Keyboard
    CODE backlit mechanical keyboard
    Mouse
    Logitech MX Master 3
    Internet Speed
    1Gb Up / 1 Gb Down
    Browser
    Chromium Edge
    Antivirus
    Windows Defender
    Other Info
    Additional options installed:
    WiFi 6E PCIe adapter
    ASUS ThunderboltEX 4 PCIe adapter
  • Operating System
    Win11 Pro 22H2, Moment 2
    Computer type
    Laptop
    Manufacturer/Model
    HP Spectre x360 15-BL012DX
    CPU
    Intel i7-7500U
    Memory
    32GB
    Graphics card(s)
    Dual Intel HD 620 and Nvidia GeForce 940MX
    Sound Card
    Built-in Realtek HD Audio
    Monitor(s) Displays
    4k 15-inch
    Screen Resolution
    4k (3840 x 2160)
    Hard Drives
    1TB Seagate FireCuda 510 NVMe SSD
    Internet Speed
    1Gb Up / 1Gb Down
    Browser
    Chromium Edge
    Antivirus
    Windows Defender
    Other Info
    RAM Upgraded from 16GB to 32GB WiFi Upgraded from WiFi 5 to WiFi 6 SSD upgraded from 512GB NVMe SSD to 1TB Seagate FireCuda 510 NVMe SSD
PenPusher

PenPusher

Active member
VIP
Local time
3:16 PM
Posts
75
Location
Portsmouth, UK
Visit site
OS
Windows 11 Pro 22H2 (22621.963)
Intel Platform Trust Technology (PTT)? Enable... Sorry I see it's been well covered already ;-)


My Computer

System One

  • OS
    Windows 11 Pro 22H2 (22621.963)
    Computer type
    PC/Desktop
    Manufacturer/Model
    My Self
    CPU
    Intel Alder lake i7 12700K
    Motherboard
    Asus z690 Gaming WiFi D4, Bios Ver 2204
    Memory
    32 Gb Corsair Vengeance LPX DDR4 3200 XMP
    Graphics Card(s)
    EVGA 3070ti FTW3 Ultra Gaming
    Sound Card
    Via Display port
    Monitor(s) Displays
    Dell S2417DG
    Screen Resolution
    2560 x 1440 @ 165Hz G-Sync mode
    Hard Drives
    WD Black SN850 1Tb NVME
    Samsung 980 Pro with heatsink 1Tb NVME
    Samsung 870 Qvo 1Tb SSD,
    Seagate ST2000DM001 2Gb
    Pioneer DVD-RW DVR-219L
    PSU
    Corsair RM850
    Case
    Phanteks Enthoo Pro M Tempered Glass
    Cooling
    Be Quiet Shadow Rock 3
    Keyboard
    Logitech G Pro
    Mouse
    Logitech G903, Lightspeed + Powerplay Mat
    Internet Speed
    40Mb
    Browser
    Firefox
    Antivirus
    MS Defender
    Other Info
    Logitech C930e webcam
    Synology DS218 play 2 x 4Tb WD Red WD40EFAX
F

friendlyphil

Member
Thread Starter
Local time
10:16 AM
Posts
20
Visit site
OS
Windows11
I enabled the Intel PTT and disable the other. Still won't load.


My Computer

System One

  • OS
    Windows11
    Computer type
    PC/Desktop
    CPU
    Intel Core i7 - 10700
    Motherboard
    Gigabyte Z590 UD
    Memory
    G.Skil 32 GB Ripjaws V series DDR PC4-25600 3200Mhz for Intel Z170
    Graphics Card(s)
    Onboard
    Sound Card
    none
    Hard Drives
    WD 2TB SSD
    Case
    Cooler Master
You must log in or register to reply here.

Similar threads

Windows 11 Media Creation Tool
Replies
17
Views
356
johnlgalt
johnlgalt
Solved Installing Windows 11 Lite and later update to Windows 11 Pro/Home
2
Replies
35
Views
1K
spapakons
spapakons
Windows 11 Install On New SSD Help
Replies
16
Views
977
Skeet1983
S
I am so mad at windows 11
2
Replies
31
Views
697
Winuser
Winuser
Help moving win 10 to new win 11 computer
2
Replies
29
Views
886
Scannerman
Scannerman

Latest Tutorials

Latest Support Threads

Top Bottom
