No Extended option on Rufus for W11 installation without TPM?


D

ddiaconu21

Active member
Local time
10:44 AM
Posts
19
Visit site
OS
Windows 11
I've seen online that this option is available for installing via Rufus, but for the love of everything, I can't find this option when I'm running it.

Am I doing something wrong?


My Computer

System One

  • OS
    Windows 11
ddiaconu21 said:
I've seen online that this option is available for installing via Rufus, but for the love of everything, I can't find this option when I'm running it.

Am I doing something wrong?
Click to expand...
What do you mean by extended option?


My Computer

System One

  • OS
    Windows 11 Pro + Win11 Canary VM.
    Computer type
    Laptop
    Manufacturer/Model
    ASUS Zenbook 14
    CPU
    I9 13th gen i9-13900H 2.60 GHZ
    Motherboard
    Yep, Laptop has one.
    Memory
    16 GB soldered
    Graphics Card(s)
    Integrated Intel Iris XE
    Sound Card
    Realtek built in
    Monitor(s) Displays
    laptop OLED screen
    Screen Resolution
    2880x1800 touchscreen
    Hard Drives
    1 TB NVME SSD (only weakness is only one slot)
    PSU
    Internal + 65W thunderbolt USB4 charger
    Case
    Yep, got one
    Cooling
    Stella Artois (UK pint cans - 568 ml) - extra cost.
    Keyboard
    Built in UK keybd
    Mouse
    Bluetooth , wireless dongled, wired
    Internet Speed
    900 mbs (ethernet), wifi 6 typical 350-450 mb/s both up and down
    Browser
    Edge
    Antivirus
    Defender
    Other Info
    TPM 2.0, 2xUSB4 thunderbolt, 1xUsb3 (usb a), 1xUsb-c, hdmi out, 3.5 mm audio out/in combo, ASUS backlit trackpad (inc. switchable number pad)

    Macrium Reflect Home V8
    Office 365 Family (6 users each 1TB onedrive space)
    Hyper-V (a vm runs almost as fast as my older laptop)
Just follow the instructions as shown below:

rufus 1.png
rufus 2.png


My Computers

System One System Two

  • OS
    Windows 11 Pro 64-bits 24H2 26100.2454
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom self built
    CPU
    AMD Ryzen 3 2200G with Radeon Vega Graphics 3.50 GHz
    Motherboard
    MSI B350 PC MATE
    Memory
    16,00 GB TeamGroup DDR4-2667
    Graphics Card(s)
    Nvidia GeForce GT 730 & Radeon™ Vega 8 Graphics
    Sound Card
    nVIDIA GK208 HDMI/DP High Definition Audio Controller
    Monitor(s) Displays
    AOC 27"
    Screen Resolution
    3840x2160
    Hard Drives
    SSD Team Group T-Force Cardea Zero Z440 1TB Gen4 M.2 NVMe (5000/4400MB/s), SSD Team Group CX2 512GB SATA III (530/470MB/s) and 2x Seagate 1TB BarraCuda 64MB 7200rpm SATA III 3.5 - ST1000DM010
    PSU
    LC-Power 650W V2.3
    Case
    ATX Nox Hummer ZS
    Cooling
    No cooling
    Keyboard
    Logitech K220
    Mouse
    Logitech
    Internet Speed
    1000/200
    Browser
    Firefox 131.0.3
    Antivirus
    Windows Defender
    Other Info
    Optical Drive ASUS DRW-24D5MT
  • Operating System
    Windows 11 Pro 64-bits 24H2 26100.2454
    Computer type
    Laptop
    Manufacturer/Model
    Asus VivoBook Max X541NA
    CPU
    Intel Celeron N3350 @ 1.10GHz
    Motherboard
    ASUS X541NA
    Memory
    4 GB
    Graphics card(s)
    Intel Apollo Lake SoC - Graphics and Display Controller (12 EU) [B1] [ASUS]
    Sound Card
    Intel Apollo Lake SoC - High Definition Audio Controller
    Monitor(s) Displays
    NT156WHM-N42 15.6"
    Screen Resolution
    1366 x 768
    Hard Drives
    Seagate ST1000LM035-1RK172
    PSU
    Asus Battery
    Internet Speed
    1000 Mbps / 200 MBps
    Browser
    Firefox 131.0.3
    Antivirus
    Microsoft Windows Defender
cereberus said:
What do you mean by extended option?
Click to expand...


My Computer

System One

  • OS
    Windows 11
Rufus 3.18
rufus 3.png


My Computers

System One System Two

  • OS
    Windows 11 Pro 64-bits 24H2 26100.2454
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom self built
    CPU
    AMD Ryzen 3 2200G with Radeon Vega Graphics 3.50 GHz
    Motherboard
    MSI B350 PC MATE
    Memory
    16,00 GB TeamGroup DDR4-2667
    Graphics Card(s)
    Nvidia GeForce GT 730 & Radeon™ Vega 8 Graphics
    Sound Card
    nVIDIA GK208 HDMI/DP High Definition Audio Controller
    Monitor(s) Displays
    AOC 27"
    Screen Resolution
    3840x2160
    Hard Drives
    SSD Team Group T-Force Cardea Zero Z440 1TB Gen4 M.2 NVMe (5000/4400MB/s), SSD Team Group CX2 512GB SATA III (530/470MB/s) and 2x Seagate 1TB BarraCuda 64MB 7200rpm SATA III 3.5 - ST1000DM010
    PSU
    LC-Power 650W V2.3
    Case
    ATX Nox Hummer ZS
    Cooling
    No cooling
    Keyboard
    Logitech K220
    Mouse
    Logitech
    Internet Speed
    1000/200
    Browser
    Firefox 131.0.3
    Antivirus
    Windows Defender
    Other Info
    Optical Drive ASUS DRW-24D5MT
  • Operating System
    Windows 11 Pro 64-bits 24H2 26100.2454
    Computer type
    Laptop
    Manufacturer/Model
    Asus VivoBook Max X541NA
    CPU
    Intel Celeron N3350 @ 1.10GHz
    Motherboard
    ASUS X541NA
    Memory
    4 GB
    Graphics card(s)
    Intel Apollo Lake SoC - Graphics and Display Controller (12 EU) [B1] [ASUS]
    Sound Card
    Intel Apollo Lake SoC - High Definition Audio Controller
    Monitor(s) Displays
    NT156WHM-N42 15.6"
    Screen Resolution
    1366 x 768
    Hard Drives
    Seagate ST1000LM035-1RK172
    PSU
    Asus Battery
    Internet Speed
    1000 Mbps / 200 MBps
    Browser
    Firefox 131.0.3
    Antivirus
    Microsoft Windows Defender
I used version 3.20 to make an ISO and the option didn't show until I started making the ISO.


My Computers

System One System Two

  • OS
    Windows 11 Canary Channel
    Computer type
    PC/Desktop
    Manufacturer/Model
    PowerSpec B746
    CPU
    Intel Core i7-10700K
    Motherboard
    ASRock Z490 Phantom Gaming 4/ax
    Memory
    16GB (8GB PC4-19200 DDR4 SDRAM x2)
    Graphics Card(s)
    NVIDIA GeForce GTX 1050 TI
    Sound Card
    Realtek Audio
    Monitor(s) Displays
    Samsung SAM0A87 Samsung SAM0D32
    Screen Resolution
    1920 x 1080
    Hard Drives
    NVMe WDC WDS100T2B0C-00PXH0 1TB
    Samsung SSD 860 EVO 1TB
    PSU
    750 Watts (62.5A)
    Case
    PowerSpec/Lian Li ATX 205
    Keyboard
    Logitech K270
    Mouse
    Logitech M185
    Browser
    Microsoft Edge and Firefox
    Antivirus
    ESET Internet Security
  • Operating System
    Windows 11 Canary Channel
    Computer type
    PC/Desktop
    Manufacturer/Model
    PowerSpec G156
    CPU
    Intel Core i5-8400 CPU @ 2.80GHz
    Motherboard
    AsusTeK Prime B360M-S
    Memory
    16 MB DDR 4-2666
    Monitor(s) Displays
    23" Speptre HDMI 75Hz
    Screen Resolution
    1920x1080
    Hard Drives
    Samsung 970 EVO 500GB NVMe
    Mouse
    Logitek M185
    Keyboard
    Logitek K270
    Browser
    Firefox, Edge and Edge Canary
    Antivirus
    Windows Defender
The option for "no TPM / no Secure Boot) was added as a selection in "Image option" starting with Rufus 3.16.
The option for "no TPM / no Secure Boot) was moved to a new Windows User Experience dialog starting with Rufus 3.19. This dialog is only available if a Windows 11 ISO is selected and is not shown until after the Start button is clicked.

All this is documented in the Rufus Changelog.

Excerpts from Rufus Changelog

Version 3.16 (2021.10.13)
...
Add Windows 11 "Extended" installation support (Disables TPM/Secure Boot requirements)
...

Version 3.19 (2022.07.01)
Add a new selection dialog for Windows 11 setup customization:
- Secure Boot and TPM bypass have now been moved to this dialog
- Also allows to bypass the mandatory requirement for a Microsoft account on Windows 11 22H2
(NB: Network *MUST* be temporarily disabled for the local account creation to be proposed)
- Also add an option to skip all collection questions (Sets all answers to "Don't allow")
- Also add an option for setting internal drives offline for Windows To Go
Note: These customization options are only proposed when using a Windows 11 image.




My Computers

System One System Two

  • OS
    Windows 11 Pro 24H2
    Computer type
    Laptop
    Manufacturer/Model
    ASUS TUF Gaming A15 (2022)
    CPU
    AMD Ryzen 7 6800H with Radeon 680M GPU (486MB RAM)
    Memory
    Crucial DDR5-4800 (2400MHz) 32GB (2 x 16GB)
    Graphics Card(s)
    NVIDIA RTX 3060 Laptop (6GB RAM)
    Sound Card
    n/a
    Monitor(s) Displays
    15.6-inch
    Screen Resolution
    1920x1080 300Hz
    Hard Drives
    2 x Samsung 980 (1TB M.2 NVME SSD)
    PSU
    n/a
    Mouse
    Wireless Mouse M510
    Internet Speed
    2000Mbps/300Mbps
    Browser
    Firefox
    Antivirus
    Malwarebytes
  • Operating System
    Windows 11 Pro 23H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom build
    CPU
    AMD Ryzen 7 3700X
    Motherboard
    ASUS PRIME X370-PRO
    Memory
    G.SKILL Flare X 32GB (2x16GB) DDR4
    Graphics card(s)
    ASUS ROG-STRIX-RTX3060TI-08G-V2-GAMING (RTX 3060-Ti, 8GB RAM)
    Monitor(s) Displays
    Samsung S23A300B (23-in LED)
    Screen Resolution
    1080p 60Hz
    Hard Drives
    2TB XPG SX8200 Pro (M2. PCIe SSD) || 2TB Intel 660P (M2. PCIe SSD) ||
    PSU
    Corsair RM750x (750 watts)
    Case
    Cooler Master MasterCase 5
    Cooling
    Corsair H60 AIO water cooler
    Mouse
    Logitech K350 (wireless)
    Keyboard
    Logitech M510 (wireless)
    Internet Speed
    2000 Mbps down / 300 Mbps up
    Browser
    Firefox, Edge, Chrome
    Antivirus
    Malwarebytes (Premium)
    Other Info
    ASUS Blu-ray Burner BW-16D1HT (SATA) || Western Digital Elements 12TB USB 3.0 external hard drive used with Acronis True Image backup software || HP OfficeJet Pro 6975 Printer/Scanner
What's your OS?

If Windows 7, no, you cannot see the options. If you need to use it on Windows 7, read below,

If Windows 11/10, the options will be seen. can be selected. When you made it, you can use it on any OS system. During my Windows 7 upgrade, I did this way, made ISO copy on a Windows 10 computer, then run it to upgrade Windows 7.


ddiaconu21 said:
I've seen online that this option is available for installing via Rufus, but for the love of everything, I can't find this option when I'm running it.

Am I doing something wrong?
Click to expand...


My Computer

System One

  • OS
    Windows 7/11
    Computer type
    PC/Desktop
    Manufacturer/Model
    HP/Lenovo/Asus
    CPU
    Intel i7-11800H
    Motherboard
    Lenovo Legion 5i Pro Gen 6
    Memory
    32GB DDR4 3200MHz
    Graphics Card(s)
    NVIDIA GeForce RTX 3070
    Hard Drives
    1TB PCIe SSD
Hi there

@ddiaconu21

just install via dism /Apply-Image. This method doesn't check for the appropriate hardware - get the relevant ISO you want from UUPDUMP.

Buenos Tardes. !!

Cheers
jimbo


My Computer

System One

  • OS
    Windows XP,7,10,11 Linux Arch Linux
    Computer type
    PC/Desktop
    CPU
    2 X Intel i7
jimbo45 said:
Hi there

@ddiaconu21

just install via dism /Apply-Image. This method doesn't check for the appropriate hardware - get the relevant ISO you want from UUPDUMP.

Buenos Tardes. !!

Cheers
jimbo
Click to expand...
Command line with no GUI! Only an old school engineer would suggest that. (That's the way I would do it too, BTW.)


My Computers

System One System Two

  • OS
    Windows 11
    Computer type
    PC/Desktop
    Manufacturer/Model
    Homebuilt
    CPU
    AMD Ryzen 7 3800XT
    Motherboard
    ASUS ROG Crosshair VII Hero (WiFi)
    Memory
    32GB
    Graphics Card(s)
    EVGA GeForce GTX 1080 Ti
  • Operating System
    Windows 11 Education
    Computer type
    Laptop
    Manufacturer/Model
    Dell Inspiron 7773
    CPU
    Intel i7-8550U
    Memory
    32GB
    Graphics card(s)
    Nvidia Geforce MX150
    Sound Card
    Realtek
    Monitor(s) Displays
    17"
    Screen Resolution
    1920 x 1080
    Hard Drives
    Toshiba 512GB NVMe SSD
    SK Hynix 512GB SATA SSD
    Internet Speed
    Fast!
jimbo45 said:
Hi there

@ddiaconu21

just install via dism /Apply-Image. This method doesn't check for the appropriate hardware - get the relevant ISO you want from UUPDUMP.

Buenos Tardes. !!

Cheers
jimbo
Click to expand...
You do know that not everyone is as computer savy as you?


My Computers

System One System Two

  • OS
    Windows 11 Canary Channel
    Computer type
    PC/Desktop
    Manufacturer/Model
    PowerSpec B746
    CPU
    Intel Core i7-10700K
    Motherboard
    ASRock Z490 Phantom Gaming 4/ax
    Memory
    16GB (8GB PC4-19200 DDR4 SDRAM x2)
    Graphics Card(s)
    NVIDIA GeForce GTX 1050 TI
    Sound Card
    Realtek Audio
    Monitor(s) Displays
    Samsung SAM0A87 Samsung SAM0D32
    Screen Resolution
    1920 x 1080
    Hard Drives
    NVMe WDC WDS100T2B0C-00PXH0 1TB
    Samsung SSD 860 EVO 1TB
    PSU
    750 Watts (62.5A)
    Case
    PowerSpec/Lian Li ATX 205
    Keyboard
    Logitech K270
    Mouse
    Logitech M185
    Browser
    Microsoft Edge and Firefox
    Antivirus
    ESET Internet Security
  • Operating System
    Windows 11 Canary Channel
    Computer type
    PC/Desktop
    Manufacturer/Model
    PowerSpec G156
    CPU
    Intel Core i5-8400 CPU @ 2.80GHz
    Motherboard
    AsusTeK Prime B360M-S
    Memory
    16 MB DDR 4-2666
    Monitor(s) Displays
    23" Speptre HDMI 75Hz
    Screen Resolution
    1920x1080
    Hard Drives
    Samsung 970 EVO 500GB NVMe
    Mouse
    Logitek M185
    Keyboard
    Logitek K270
    Browser
    Firefox, Edge and Edge Canary
    Antivirus
    Windows Defender
MisterEd said:
The option for "no TPM / no Secure Boot) was added as a selection in "Image option" starting with Rufus 3.16.
The option for "no TPM / no Secure Boot) was moved to a new Windows User Experience dialog starting with Rufus 3.19. This dialog is only available if a Windows 11 ISO is selected and is not shown until after the Start button is clicked.

All this is documented in the Rufus Changelog.

Excerpts from Rufus Changelog

Version 3.16 (2021.10.13)
...
Add Windows 11 "Extended" installation support (Disables TPM/Secure Boot requirements)
...

Version 3.19 (2022.07.01)
Add a new selection dialog for Windows 11 setup customization:
- Secure Boot and TPM bypass have now been moved to this dialog
- Also allows to bypass the mandatory requirement for a Microsoft account on Windows 11 22H2
(NB: Network *MUST* be temporarily disabled for the local account creation to be proposed)
- Also add an option to skip all collection questions (Sets all answers to "Don't allow")
- Also add an option for setting internal drives offline for Windows To Go
Note: These customization options are only proposed when using a Windows 11 image.


View attachment 44918
Click to expand...
Why from my win7 rufus 3.20 i don't see any of these options?


My Computer

System One

  • OS
    Windows 7 sp1
    Computer type
    PC/Desktop
    Browser
    Firefox
Gregory said:
Why from my win7 rufus 3.20 i don't see any of these options?
Click to expand...
If you read what you quoted from my post you will see "This dialog is only available if a Windows 11 ISO is selected and is not shown until after the Start button is clicked." Besides why would Rufus show an option that is not even relevant to Windows 7? If you have any more questions you need to ask the developer of Rufus.


My Computers

System One System Two

  • OS
    Windows 11 Pro 24H2
    Computer type
    Laptop
    Manufacturer/Model
    ASUS TUF Gaming A15 (2022)
    CPU
    AMD Ryzen 7 6800H with Radeon 680M GPU (486MB RAM)
    Memory
    Crucial DDR5-4800 (2400MHz) 32GB (2 x 16GB)
    Graphics Card(s)
    NVIDIA RTX 3060 Laptop (6GB RAM)
    Sound Card
    n/a
    Monitor(s) Displays
    15.6-inch
    Screen Resolution
    1920x1080 300Hz
    Hard Drives
    2 x Samsung 980 (1TB M.2 NVME SSD)
    PSU
    n/a
    Mouse
    Wireless Mouse M510
    Internet Speed
    2000Mbps/300Mbps
    Browser
    Firefox
    Antivirus
    Malwarebytes
  • Operating System
    Windows 11 Pro 23H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Custom build
    CPU
    AMD Ryzen 7 3700X
    Motherboard
    ASUS PRIME X370-PRO
    Memory
    G.SKILL Flare X 32GB (2x16GB) DDR4
    Graphics card(s)
    ASUS ROG-STRIX-RTX3060TI-08G-V2-GAMING (RTX 3060-Ti, 8GB RAM)
    Monitor(s) Displays
    Samsung S23A300B (23-in LED)
    Screen Resolution
    1080p 60Hz
    Hard Drives
    2TB XPG SX8200 Pro (M2. PCIe SSD) || 2TB Intel 660P (M2. PCIe SSD) ||
    PSU
    Corsair RM750x (750 watts)
    Case
    Cooler Master MasterCase 5
    Cooling
    Corsair H60 AIO water cooler
    Mouse
    Logitech K350 (wireless)
    Keyboard
    Logitech M510 (wireless)
    Internet Speed
    2000 Mbps down / 300 Mbps up
    Browser
    Firefox, Edge, Chrome
    Antivirus
    Malwarebytes (Premium)
    Other Info
    ASUS Blu-ray Burner BW-16D1HT (SATA) || Western Digital Elements 12TB USB 3.0 external hard drive used with Acronis True Image backup software || HP OfficeJet Pro 6975 Printer/Scanner
Winuser said:
You do know that not everyone is as computer savy as you?
Click to expand...
Hi there

I've made several step by step easy methods on showing how this is done that most people could easily follow without needing a Doctorate in Computer Science !!!!.

It really isn't that hard -- and presumably that's why people logon to sites like these is to enhance their knowledge as well as trying to find solutions to problems.

Actually when it comes to Windows I'm still quite a novice. However I'm always up to trying new things. The secret as always is to have backup and recovery before starting as I'm sure we've all hosed up things big times before. !!!!

It's amazing even today how many still refuse to take even simple backups => there's so many FREE solutions available it's bonkers not to do it. It doesn't take long, use up much Disk space and can save hours of hassle and aggro afterwards if you need to recover things.

If you only have only ONE computer also it really doesn't make sense to try out various "Pre-release" new builds - especially if you rely on that machine and don't want to go through the hassle of re-installing Windows, getting serial numbers for other products too and their updates --especially when some of those companies have gone out of business.

This is where using a VM comes in useful in those cases as you can test new builds without compromising your running machine. It takes time learning this as well but there's plenty of help on the Forums.

Cheers
jimbo


My Computer

System One

  • OS
    Windows XP,7,10,11 Linux Arch Linux
    Computer type
    PC/Desktop
    CPU
    2 X Intel i7
jimbo45 said:
I've made several step by step easy methods on showing how this is done that most people could easily follow
Click to expand...
You do know that just that line alone backs up what I posted


My Computers

System One System Two

  • OS
    Windows 11 Canary Channel
    Computer type
    PC/Desktop
    Manufacturer/Model
    PowerSpec B746
    CPU
    Intel Core i7-10700K
    Motherboard
    ASRock Z490 Phantom Gaming 4/ax
    Memory
    16GB (8GB PC4-19200 DDR4 SDRAM x2)
    Graphics Card(s)
    NVIDIA GeForce GTX 1050 TI
    Sound Card
    Realtek Audio
    Monitor(s) Displays
    Samsung SAM0A87 Samsung SAM0D32
    Screen Resolution
    1920 x 1080
    Hard Drives
    NVMe WDC WDS100T2B0C-00PXH0 1TB
    Samsung SSD 860 EVO 1TB
    PSU
    750 Watts (62.5A)
    Case
    PowerSpec/Lian Li ATX 205
    Keyboard
    Logitech K270
    Mouse
    Logitech M185
    Browser
    Microsoft Edge and Firefox
    Antivirus
    ESET Internet Security
  • Operating System
    Windows 11 Canary Channel
    Computer type
    PC/Desktop
    Manufacturer/Model
    PowerSpec G156
    CPU
    Intel Core i5-8400 CPU @ 2.80GHz
    Motherboard
    AsusTeK Prime B360M-S
    Memory
    16 MB DDR 4-2666
    Monitor(s) Displays
    23" Speptre HDMI 75Hz
    Screen Resolution
    1920x1080
    Hard Drives
    Samsung 970 EVO 500GB NVMe
    Mouse
    Logitek M185
    Keyboard
    Logitek K270
    Browser
    Firefox, Edge and Edge Canary
    Antivirus
    Windows Defender
You must log in or register to reply here.

Similar threads

Easy way (no reg fix etc) to bypass hardware check for W11 installs
Replies
11
Views
3K
OldNavy
O

Latest Support Threads

Latest Tutorials

Back
Top Bottom
