Solved After clean install, two Recovery Partitions


My Computers

System One System Two

  • OS
    Win7
    Computer type
    PC/Desktop
    CPU
    i5-8400
    Motherboard
    gigabyte b365m ds3h
    Memory
    2x8gb 3200mhz
    Monitor(s) Displays
    benq gw2480
    PSU
    bequiet pure power 11 400CM
    Cooling
    cryorig m9i
  • Operating System
    win7
    Computer type
    PC/Desktop
    CPU
    pentium g5400
    Motherboard
    gigabyte b365m ds3h
    Memory
    1x8gb 2400
    PSU
    xfx pro 450
I tried this:

dism /image:h:\driverdl\winre4.wim /get-wiminfo

It told me:

The /Image option cannot be used in this context.
For more information, refer to the help by running DISM.exe /?.

Error: 87

That file on my H partition is one of the wims I copied from the recovery partition using Disk Genius. Do I have to operate on the wim file in the recovery partition directly? I would expect I could work on this copy.


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
The /Image option cannot be used in this context.

/WimFile

dism /Get-WimInfo /WimFile:h:\driverdl\winre4.wim /index:1


My Computers

System One System Two

  • OS
    Win7
    Computer type
    PC/Desktop
    CPU
    i5-8400
    Motherboard
    gigabyte b365m ds3h
    Memory
    2x8gb 3200mhz
    Monitor(s) Displays
    benq gw2480
    PSU
    bequiet pure power 11 400CM
    Cooling
    cryorig m9i
  • Operating System
    win7
    Computer type
    PC/Desktop
    CPU
    pentium g5400
    Motherboard
    gigabyte b365m ds3h
    Memory
    1x8gb 2400
    PSU
    xfx pro 450
I was on the right track. And in case you're wondering, yes I am in an elevated command prompt to do this.

----------------------------------------------------------------
C:\Windows\System32>dism /get-wiminfo /wimfile:h:\driverdl\winre4.wim

Deployment Image Servicing and Management tool
Version: 10.0.22621.2792

Details for image : h:\driverdl\winre4.wim

Index : 1
Name : Microsoft Windows Recovery Environment (amd64)
Description : Microsoft Windows Recover Environment (amd64)
Size : 2,988,444,981 bytes

The operation completed successfully.

C:\Windows\System32>dism /get-wiminfo /wimfile:h:\driverdl\winre5.wim

Deployment Image Servicing and Management tool
Version: 10.0.22621.2792

Details for image : h:\driverdl\winre5.wim

Index : 1
Name : Microsoft Windows Recovery Environment (amd64)
Description : Microsoft Windows Recover Environment (amd64)
Size : 2,752,197,069 bytes

The operation completed successfully.

----------------------------------------------------------------

That 10.0.etc number is the version number of DISM itself, isn't it? This doesn't seem to be displaying version information on the wim file.


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
In case this is relevant:

Device name WildWilly-PC
Processor 13th Gen Intel(R) Core(TM) i9-13900K 3.00 GHz
Installed RAM 128 GB (128 GB usable)
Device ID <not sure if this is sensitive but I'm hiding it anyway>
Product ID <more redaction>
System type 64-bit operating system, x64-based processor
Pen and touch No pen or touch input is available for this display

Edition Windows 11 Pro
Version 23H2
Installed on ‎12/‎4/‎2023
OS build 22631.2861
Experience Windows Feature Experience Pack 1000.22681.1000.0


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
dism /get-imageinfo generates the exact same information as /get-wiminfo.


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
This doesn't seem to be displaying version information on the wim
my post #23

dism /get-wiminfo /wimfile:h:\driverdl\winre4.wim /index:1


My Computers

System One System Two

  • OS
    Win7
    Computer type
    PC/Desktop
    CPU
    i5-8400
    Motherboard
    gigabyte b365m ds3h
    Memory
    2x8gb 3200mhz
    Monitor(s) Displays
    benq gw2480
    PSU
    bequiet pure power 11 400CM
    Cooling
    cryorig m9i
  • Operating System
    win7
    Computer type
    PC/Desktop
    CPU
    pentium g5400
    Motherboard
    gigabyte b365m ds3h
    Memory
    1x8gb 2400
    PSU
    xfx pro 450
My bad.

C:\Windows\System32>dism /get-wiminfo /wimfile:h:\driverdl\winre4.wim /index:1

Deployment Image Servicing and Management tool
Version: 10.0.22621.2792

Details for image : h:\driverdl\winre4.wim

Index : 1
Name : Microsoft Windows Recovery Environment (amd64)
Description : Microsoft Windows Recover Environment (amd64)
Size : 2,988,444,981 bytes
WIM Bootable : No
Architecture : x64
Hal : <undefined>
Version : 10.0.22621
ServicePack Build : 2494
ServicePack Level : 0
Edition : WindowsPE
Installation : WindowsPE
ProductType : WinNT
ProductSuite :
System Root : WINDOWS
Directories : 5357
Files : 20885
Created : 5/7/2022 - 0:53:32
Modified : 12/4/2023 - 16:58:12
Languages :
en-US (Default)

The operation completed successfully.

C:\Windows\System32>dism /get-wiminfo /wimfile:h:\driverdl\winre5.wim /index:1

Deployment Image Servicing and Management tool
Version: 10.0.22621.2792

Details for image : h:\driverdl\winre5.wim

Index : 1
Name : Microsoft Windows Recovery Environment (amd64)
Description : Microsoft Windows Recover Environment (amd64)
Size : 2,752,197,069 bytes
WIM Bootable : No
Architecture : x64
Hal : <undefined>
Version : 10.0.22621
ServicePack Build : 1702
ServicePack Level : 0
Edition : WindowsPE
Installation : WindowsPE
ProductType : WinNT
ProductSuite :
System Root : WINDOWS
Directories : 5083
Files : 20042
Created : 5/7/2022 - 0:53:32
Modified : 5/5/2023 - 7:38:11
Languages :
en-US (Default)

The operation completed successfully.

---------------------------------------------------

The one created by the Repair Install has a higher ServicePack Build number: 2494 vs 1702. I've had a big update pushed out since I did the Repair Install so I imagine if I created another recovery partition now, it would have a higher build number. Which makes me ask another question. Does the recovery partition get updated when FixPacks come out for the main system?

In any case, what does this version information tell you?


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
Interesting that in contradiction to diskpart, Disk Genius numbers the partitions from 0. So partition 3 in Disk Genius is partition 4 in diskpart, & partition 4 in Disk Genius is partition 5 in diskpart. Are we confused enough yet?
Not quite confused enough yet. If you want to get really confused, look at Disk Management. That will show one less partition than Disk Genius or Diskpart - it deliberately hides the 16MB MSR partition :lmao:


My Computers

System One System Two

  • OS
    Windows 11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Acer Aspire 3 A315-23
    CPU
    AMD Athlon Silver 3050U
    Memory
    8GB
    Graphics Card(s)
    Radeon Graphics
    Monitor(s) Displays
    laptop screen
    Screen Resolution
    1366x768 native resolution, up to 2560x1440 with Radeon Virtual Super Resolution
    Hard Drives
    1TB Samsung EVO 870 SSD
    Internet Speed
    50 Mbps
    Browser
    Edge, Firefox
    Antivirus
    Defender
    Other Info
    fully 'Windows 11 ready' laptop. Windows 10 C: partition migrated from my old unsupported 'main machine' then upgraded to 11. A test migration ran Insider builds for 2 months. When 11 was released on 5th October 2021 it was re-imaged back to 10 and was offered the upgrade in Windows Update on 20th October. Windows Update offered the 22H2 Feature Update on 20th September 2022. It got the 23H2 Feature Update on 4th November 2023 through Windows Update, and 24H2 on 3rd October through Windows Update by setting the Target Release Version for 24H2.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB NVMe ssd, supported device running Windows 11 Pro (and all my Hyper-V VMs).

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 8GB RAM, 256GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro RTM and Insider Dev, Beta, and RP 24H2 as native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 8GB RAM, 512GB NVMe ssd, supported device running Windows 11 Pro, plus the Insider Beta, Dev, Canary, and Release Preview builds as a native boot .vhdx.
  • Operating System
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Dell Latitude E4310
    CPU
    Intel® Core™ i5-520M
    Motherboard
    0T6M8G
    Memory
    8GB
    Graphics card(s)
    (integrated graphics) Intel HD Graphics
    Screen Resolution
    1366x768
    Hard Drives
    500GB Crucial MX500 SSD
    Browser
    Firefox, Edge
    Antivirus
    Defender
    Other Info
    unsupported machine: Legacy bios, MBR, TPM 1.2, upgraded from W10 to W11 using W10/W11 hybrid install media workaround. In-place upgrade to 22H2 using ISO and a workaround. Feature Update to 23H2 by manually installing the Enablement Package. In-place upgrade to 24H2 using hybrid 23H2/24H2 install media. Also running Insider Beta, Dev, and Canary builds as a native boot .vhdx.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB NVMe ssd, supported device running Windows 11 Pro (and all my Hyper-V VMs).

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 8GB RAM, 256GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro RTM and Insider Dev, Beta, and RP 24H2 as native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 8GB RAM, 512GB NVMe ssd, supported device running Windows 11 Pro, plus the Insider Beta, Dev, Canary, and Release Preview builds as a native boot .vhdx.
Yeah, I mentioned that one upthread. What is that one for, anyway?


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11

My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
At least Macrium Reflect sees everything:

Boot Drive.png

I wonder why the active recovery partition, numbered 4 here (another numbering scheme), is shown in red. I'll have to hunt that one down.


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
Yeah, I mentioned that one upthread. What is that one for, anyway?
On old MBR formatted drives there were some hidden sectors reserved for certain software to use. The GPT format doesn't allow such hidden sectors, so the MSR partition takes its place. Virtually nothing uses it these days, which is why its so small now.



My Computers

System One System Two

  • OS
    Windows 11 Home
    Computer type
    Laptop
    Manufacturer/Model
    Acer Aspire 3 A315-23
    CPU
    AMD Athlon Silver 3050U
    Memory
    8GB
    Graphics Card(s)
    Radeon Graphics
    Monitor(s) Displays
    laptop screen
    Screen Resolution
    1366x768 native resolution, up to 2560x1440 with Radeon Virtual Super Resolution
    Hard Drives
    1TB Samsung EVO 870 SSD
    Internet Speed
    50 Mbps
    Browser
    Edge, Firefox
    Antivirus
    Defender
    Other Info
    fully 'Windows 11 ready' laptop. Windows 10 C: partition migrated from my old unsupported 'main machine' then upgraded to 11. A test migration ran Insider builds for 2 months. When 11 was released on 5th October 2021 it was re-imaged back to 10 and was offered the upgrade in Windows Update on 20th October. Windows Update offered the 22H2 Feature Update on 20th September 2022. It got the 23H2 Feature Update on 4th November 2023 through Windows Update, and 24H2 on 3rd October through Windows Update by setting the Target Release Version for 24H2.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB NVMe ssd, supported device running Windows 11 Pro (and all my Hyper-V VMs).

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 8GB RAM, 256GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro RTM and Insider Dev, Beta, and RP 24H2 as native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 8GB RAM, 512GB NVMe ssd, supported device running Windows 11 Pro, plus the Insider Beta, Dev, Canary, and Release Preview builds as a native boot .vhdx.
  • Operating System
    Windows 11 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Dell Latitude E4310
    CPU
    Intel® Core™ i5-520M
    Motherboard
    0T6M8G
    Memory
    8GB
    Graphics card(s)
    (integrated graphics) Intel HD Graphics
    Screen Resolution
    1366x768
    Hard Drives
    500GB Crucial MX500 SSD
    Browser
    Firefox, Edge
    Antivirus
    Defender
    Other Info
    unsupported machine: Legacy bios, MBR, TPM 1.2, upgraded from W10 to W11 using W10/W11 hybrid install media workaround. In-place upgrade to 22H2 using ISO and a workaround. Feature Update to 23H2 by manually installing the Enablement Package. In-place upgrade to 24H2 using hybrid 23H2/24H2 install media. Also running Insider Beta, Dev, and Canary builds as a native boot .vhdx.

    My SYSTEM THREE is a Dell Latitude 5410, i7-10610U, 32GB RAM, 512GB NVMe ssd, supported device running Windows 11 Pro (and all my Hyper-V VMs).

    My SYSTEM FOUR is a 2-in-1 convertible Lenovo Yoga 11e 20DA, Celeron N2930, 8GB RAM, 256GB ssd. Unsupported device: currently running Win10 Pro, plus Win11 Pro RTM and Insider Dev, Beta, and RP 24H2 as native boot vhdx.

    My SYSTEM FIVE is a Dell Latitude 3190 2-in-1, Pentium Silver N5030, 8GB RAM, 512GB NVMe ssd, supported device running Windows 11 Pro, plus the Insider Beta, Dev, Canary, and Release Preview builds as a native boot .vhdx.
Oh yes. Be mysterious. Hide things. Users are too stupid to be allowed to see everything. Such is life in Microsoftland.


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
What do you think? Will you be ready to do the final step within one week?
Make sure that you update the firmware of your SAMSUNG as well. It's old!
The safest way to do this, is to use UNetbootin to flash. :-)


My Computer

System One

  • OS
    Windows 10
    Computer type
    Laptop
    Manufacturer/Model
    HP ZBook
    CPU
    Intel 6700HQ
    Motherboard
    HP
    Memory
    24
    Graphics Card(s)
    AMD FirePro 5170M
    Hard Drives
    Samsung SSD 860 Pro
    Keyboard
    yes
    Mouse
    yes
    Other Info
    19045.3803
    some Red Hat workhorses
At least Macrium Reflect sees everything:

View attachment 81393

I wonder why the active recovery partition, numbered 4 here (another numbering scheme), is shown in red. I'll have to hunt that one down.
There is very little free space on that partition so it is shown red


My Computers

System One System Two

  • OS
    Win7
    Computer type
    PC/Desktop
    CPU
    i5-8400
    Motherboard
    gigabyte b365m ds3h
    Memory
    2x8gb 3200mhz
    Monitor(s) Displays
    benq gw2480
    PSU
    bequiet pure power 11 400CM
    Cooling
    cryorig m9i
  • Operating System
    win7
    Computer type
    PC/Desktop
    CPU
    pentium g5400
    Motherboard
    gigabyte b365m ds3h
    Memory
    1x8gb 2400
    PSU
    xfx pro 450
Oh, is that all? I was worried it was something serious, like maybe some sort of corruption. They should show the unallocated part in red. That would be more intuitive. Thanks for the answer. Meanwhile, what did the version numbers in the wims tell you?


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
From the Diskpart list partition you can see that drive 0 has 5 partitions (Windows Disk Manager doesn't show the MS reserved partition)
diskpart-png.81373


From reagentc / info your recovery partition is number 4 and partition number 5 was the old one.
reagentc-png.81372


This is quite normal to happen. Windows creates a recovery partition at the end of the drive. Then, latter, it is requested a bigger recovery partition. Instead of disabling the old (reagenc /disable) deleting the partition and then creating a new and bigger recovery partition, windows just shrinks the C: partition and create a new and bigger Recovery partition leaving the old one without use.
To avoid this I normally create a big recovery partition (1G) at the end of the C: partition.

You can delete the last partition (5) and then enlarge the 4th partition (786+674) resulting a 1460M recovery partition.

What you want to do?

Last edited:

My Computers

System One System Two

  • OS
    Windows 7 HP 64 - Windows 11 Pro - Lubuntu
    Computer type
    PC/Desktop
    Manufacturer/Model
    custom build
    CPU
    i5 6600K - 800MHz to 4400MHz
    Motherboard
    GA-Z170-HD3P
    Memory
    4+4G GSkill DDR4 3000
    Graphics Card(s)
    IG - Intel 530
    Monitor(s) Displays
    Samsung 226BW
    Screen Resolution
    1680x1050
    Hard Drives
    (1) -1 SM951 – 128GB M.2 AHCI PCIe SSD drive for Win 11
    (2) -1 WD SATA 3 - 1T for Data
    (3) -1 WD SATA 3 - 1T for backup
    (4) -1 BX500 SSD - 128G for Windows 7 and Lubuntu
    PSU
    Thermaltake 450W TR2 gold
    Keyboard
    Old and good Chicony mechanical keyboard
    Mouse
    Logitech mX performance - 9 buttons (had to disable some)
    Internet Speed
    500 Mb/s
    Browser
    Firefox 64
  • Operating System
    Windows 7 Pro
    Computer type
    Laptop
    Manufacturer/Model
    Asus Q550LF
    CPU
    i7-4500U 800- 3000MHz
    Motherboard
    Asus Q550LF
    Memory
    (4+4)G DDR3 1600
    Graphics card(s)
    IG intel 4400 + NVIDIA GeForce GT 745M
    Sound Card
    Realtek
    Monitor(s) Displays
    LG Display LP156WF4-SPH1
    Screen Resolution
    1920 x 1080
    Hard Drives
    BX500 120G SSD for Windows and programs
    & 1T HDD for data
    Internet Speed
    350 Mb/s
    Browser
    Firefox 64
@Megahertz Of course! I should have thought of that myself. I mean, a 2G partition at the back of a 2T SSD is a drop in the bucket. (Remember when 2G was considered a jaw-dropping amount of disk space? My, how times have changed . . .) That so neatly solves the problem of multiple Recovery Partitions forever. I love the idea. That's what I'm going to do when I get around to cleaning this up. This exercise is not so much about squeezing every last byte of useful space out of the drive. It's more about eliminating the complexity of useless multiple Recovery Partitions.

I'm going to go with a 2G partition for W11 to mess around with Recovery Partitions in. As you can see from my image above, the current active Recovery Partition is already on the order of 0.75G. It's not too much of a leap to assume it's going to cross the 1G threshold at some point. But 2G really ought to be enough to hold the line forever. Hah. Forever. Haven't we all heard that one before? Still, 2G should be good enough for a long time.


My Computer

System One

  • OS
    Windows 11 Pro 64-bit 24H2
    Computer type
    PC/Desktop
    Manufacturer/Model
    Self build
    CPU
    Intel Core i9-13900K
    Motherboard
    ASUS Z790-Plus WiFi TUF Gaming
    Memory
    4x32G Teamgroup TForce Vulcan DDR5 6000 DIMMs
    Graphics Card(s)
    MSI/NVidia GeForce RTX 4070 Gaming X Trio 12G GDDR6X + built into motherboard Intel UHD Graphics
    Sound Card
    Built into graphics card + built into motherboard Realtek Audio
    Monitor(s) Displays
    Both connected to the NVidia adapter - Primary: Dell SE2417HGX 23" diagonal connected via HDMI-to-DisplayPort dongle, Secondary: Toshiba TV 32" diagonal connected via HDMI through Onkyo TX-NR717 surround receiver
    Screen Resolution
    1920x1080 on each monitor
    Hard Drives
    Samsung 970 EVO Plus NVMe M.2 2T
    6xSATA-to-USB 3.0 Fideco external enclosures holding SATA drives of various brands & sizes 1x20T, 2x18T, 2x6T, 1x500G, all connected to a multi-port USB hub
    For backups: USB 3.0 HDDs of various brands & sizes 3x20T, 1x4T, 1x1T + SSDs of various brands & sizes 2x480G, 1x1T, all connected to another multi-port USB hub, powered on only while actually performing backups & (may it never happen) restores
    PSU
    MSI MPG A1000G PCIe5 1000W, TrippLite Smart1500TSU 1200W UPS for the main system, TrippLite ECO850LCD 850W UPS for the DASD & my Internet connectivity boxes (no reason to throw out legacy equipment that stil works fine)
    Case
    Fractal North
    Cooling
    DeepCool AK620 CPU cooler (air, 2 fans), 2 case fans, 1 fan in PSU, 3 fans in graphics adapter; 4xpersonal cooling fans strategically placed to cool the external HDDs
    Keyboard
    Cherry MX 11900 USB (wired)
    Mouse
    Touchpad built into the keyboard
    Internet Speed
    500Mbps via Spectrum cable TV/cell phone bundle
    Browser
    Firefox
    Antivirus
    Built into Windows 11
Hi,
Yeah those awesome tech guys at microsoft can't do anything right :zany:
I'd delete the old and extend the new one into that space with disk genus


I left 3gb in front of C for this silly recovery partition and got nothing than criticism and a ms history lessen and here ms is messing it up again because they are inept in reusing an existing recovery partition lol
Only SIW2 was really helpful out the gate on my thread with the same app here :thumbsup:
My favorite reply is it's normal don't worry about it lol


My Computer

System One

  • OS
    Win-7-10-11Pro's
    Computer type
    PC/Desktop
    Manufacturer/Model
    Acer 17" Nitro 7840sn/ 2x16gb 5600c40/ 4060/ stock 1tb-os/ 4tb sn850x
    CPU
    10900k & 9940x & 5930k
    Motherboard
    z490-Apex & x299-Apex & x99-Sabertooth
    Memory
    Trident-Z Royal 4000c16 2x16gb & Trident-Z 3600c16 4x8gb & 3200c14 4x8gb
    Graphics Card(s)
    Titan Xp & 1080ti FTW3 & evga 980ti gaming
    Sound Card
    Onboard Realtek x3
    Monitor(s) Displays
    1-AOC G2460PG 24"G-Sync 144Hz/ 2nd 1-ASUS VG248QE 24"/ 3rd LG 43" series
    Screen Resolution
    1920-1080 not sure what the t.v is besides 43" class scales from 1920-1080 perfectly
    Hard Drives
    2-WD-sn850x 4tb/ 970evo+500gb/ 980 pro 2tb.
    PSU
    1000p2 & 1200p2 & 850p2
    Case
    D450 x2 & 1 Test bench in cherry Entertainment center
    Cooling
    Custom water loops x3 with 2x mora 360mm rads only 980ti gaming air cooled
    Keyboard
    G710+x3
    Mouse
    Redragon x3
    Internet Speed
    xfinity gigabyte
    Browser
    Firefox
    Antivirus
    mbam pro

Latest Support Threads

Latest Tutorials

Back
Top Bottom
